Evolution of Photoautotrophy Ecol 182 452005

1
Evolution of PhotoautotrophyEcol 182 4-5-2005
2
PLANT ECOLOGY UNDERGRAD RESEARCH POSITIONS

• Mix of lab and field work
• in labs of Dr. Travis Huxman Dr. Larry Venable
• 15-20 hrs/week during semester
• Up to 40 hrs/week in summer
• Contact 621-8220 or
• gregbg_at_email.arizona.edu

3
Ground rules

• Lecture notes will be posted the night before
  each lecture (182 portal link to my website)
• Figures and tables from the text MAY NOT ALWAYS
  be posted online
• Additional figures or pictures will ALWAYS be
  available
• Several questions (2-5) will be posted after each
  lecture (within 1-2 days) and study guides
  after a series of connected lectures is finished
• On email please put ECOL 182 in the subject
• I hold my office hours M 200-300, T 345-445

4
Big Questions

• What have been the important constraints and / or
  principles that have shaped the evolution of
  plants.
• Diversification
• Form and function
• How do organisms interact with their environment
• Community dynamics
• Ecosystem structure and function

5
Major Points for Today

• The nature of the physical environment
• Evolutionary history of photoautotrophy
• (structure and function of the photosynthetic
  apparatus)
• Modern view of photosynthesis in plants

6
What is the ultimate constraint facing most
plants?

• Salient qualities of the environment
• Temperature - range, extremes
• Humidity - evaporation, precipitation
• Wind
• Soils
• Biotic influences
• Radiation - quality and quantity

7
What is your favorite equation?
8
What is your favorite equation?

• Interconversion of mass and energy
• E mc2
• Hydrogen - Helium
• Maintains the surface of the sun at 5800K!
• Extremely high temperature results in radiation
  of energy (as light) into space
• 1360 W m-2 (solar constant) hits the outer
  atmosphere.
• Scattering in the atmosphere
• interception (Rayleigh) and diffusion (Mie)
  results in 420 Wm-2 global average (or up to
  840 Wm-2 at equator)

9

• Newton (1666) - light is made up of many things
  (prisim)
• Foucault (1850) - verification of wave theory
• Hertz (1887) - photoelectric effect
• wavelength dependent
• independent of total beam energy
• Planck (1901) - light can be particle-like
  (quanta)
• Einstein (1905) - explained photoelectric effect
• relative amount of energy in short - vs - long
  wave lengths

10
The Interactions of Light and Pigments

• Discrete packets of visible light called photons.
• Photons can be absorbed by receptive molecules.
• Photons have energy which can be converted to
  perform work

11
What is your favorite constant?
12
My favorite constant

• Plancks constant - h - conversion of a photon to
  energy
• El h v
• El h c / lvaccum
• El - energy of a particular wavelength
• v - frequency of oscillation
• l - wavelength
• c - speed of light

How much energy is in sunlight? 260 kJ
mol-1 Average daytime photosynthetic photon flux
density 1000 mmol m-2 s-1 100 seconds result
in a mole of light compare to ATP hydrolysis
yielding 40 to 50 kJ mol-1
13

• How do organisms take advantage of this free
  energy?
• Consider the evolutionary history of
  photoautotrophy
• Initial events NOT well understood
• Glycolysis had already evolved
• Photosynthetic apparatus co-opted from some other
  function (more specific on this later)

14
Evolution of Photoautotrophy

• Likely evolved from chemoautotrophs
• Fossils of photosynthetic Archean bacteria ( 3.6
  billion yrs old)
• Photosynthesis is found in both prokaryotes and
  eukaryotes
• Eukaryote distribution includes algae and
  embryophytes (for our purposes this is the
  definition of a plant note this is different
  than your text!)
• Prokaryotes distribution is throughout Bacteria
  and Archea

15
Phylogenetic distribution of photosynthesis

• Prokaryotes (5 of 10 clades)
• One of the most interesting - proteobacteria
• A range of other clades, including, greensulfur
  bacteria, gram positive bacteria (recall
  peptidoglycan cell walls), and filamentous green
  non-sulfur bacteria
• Cyanobacteria
• only clade with oxygenation abilities (what are
  those?)

16
(No Transcript)
17
Figure 27.20 Extreme Halophiles - Euryarchaeota
18
Figure 27.11 Cyanobacteria (Part 2)
19
Biological soil crusts
20
Universal Photosynthetic Structure?

• Similar form in both prokaryotes and eukaryotes
• A simple dogma of photoautotrophic organisms -
  energy acquisition, a common physiological
  paradigm for a diverse set of organisms
• Structure antenna / reaction center design
• chlorophyll based light harvesting pigments
• Chlorophylls can absorb visible light and
  delocalize energy across their molecular
  structure
• heterodimeric protein core of reaction center
• Two distinct yet related proteins
• Suggests origin as monomeric structure with gene
  duplication and neofunctionalization leading to
  novel function

21
(No Transcript)
22
(No Transcript)
23
Antenna / Reaction Center Design

• One exception from this general design -
  Halobacteria (Euryarchaeota - extreme saline
  environments)
• Contain retinal - protein system (as a complex
  molecular structure)
• Recall that retinal is found in the vertebrate
  eye
• Consequences?
• Photosynthesis has evolved at least TWICE!

24
Chlorophyll based pigments

• Harvest light by trans-cis interconversion
  resulting in greater energy states
• all oxygen evolving photosynthetic groups use chl
  a
• all other bacteria use other chl -
  bacteriochlorophylls

25
Biosynthetic pathway

• Does this present an evolutionary problem?
• Does biosynthesis recapitulate phylogeny?
• Evolutionary solutions?

• 5-aminolevulinic acid
• protochlorophyllidae
• chlorophyll c
• chlorophyllide a
• chlorophyll a
• chlorophyll b
• bacteria chlorophylls

26
Dimeric protein complex (reaction center)

• Converts that energy to a usable form
• Types
• (1) iron-sulfur clusters
• (2) pheophytin and quinones
• From a variety of groups.but.in cyanobacteria
  and eukaryotes, they coexist!
• Coexist as Photosystem I (1 above) and
  Photosystem II (2)

27
Light harvesting structures

• Photosystem I uses reduces NADP to NADPH H
• Photosystem II uses light energy to oxidize water
  molecules, producing electrons, protons, and O2.
• Both of these are stand-alone energy systems,
  but combined they can maintain energy flow
  through a system

28
Stealing electrons capturing light energy
producing high energy compounds
29
Endosymbiotic origins of eukaryote photosynthesis

• Coexistence of multiple photosystems when both
  can be found in isolation in nature
• Similarities between cyanobacteria and
  chloroplasts
• Multiple endosymbiotic events (not just one)

30
BACTERIA
Remaining EUKARYA
Cyanobacteria
PLANTAE
Chloroplasts
Mitochondria
Proteobacteria
Chlamydiales
ARCHAEA
Spirochaeles
If mit. or chl. DNA were derived from nuclear
DNA, we would expect there would be braches here
31
(No Transcript)
32
Regulation of Photosynthesis where does the ATP
and NADPH following light harvesting?

• The Calvin cycle
• Carboxylation (enzymatic)
• Reducing (energy dependent)
• Regenerating(energy dependent)
• Turns out there is plenty of light energy, most
  of the time, what regulates photosynthetic rate
  is carboxylation!

33
The CalvinBenson Cycle

• Ribulose 1,5-bisphosphate carboxylase / oxygenase
  (rubisco) catalyzes the fixation of CO2 into a
  5-carbon compound, ribulose 1,5-bisphosphate
  (RuBP).
• An intermediate 6-carbon compound forms, which is
  unstable and breaks down to form two 3-carbon
  molecules of 3PG (see fig. 8.14)
• Rubisco is the most abundant protein in the world.

34
The CalvinBenson Cycle

• Consists of three (or four) processes
• Fixation of CO2 to RuBP (catalyzed by rubisco)
• Reducing to G3P (uses ATP and NADPH)
• Regeneration RuBP (uses ATP)
• Transport by inorganic phosphate!

35
Sink regulation of photosynthesis different
concept of metabolic regulation in photosynthetic
organisms
36
Figure 8.13 The Calvin-Benson Cycle
37
Making Carbohydrate from CO2

• Products of photosynthesis are critical for
  energy on Earth
• Most photosynthetically acquired energy is
  released by glycolysis and cellular respiration
  of photoautotrophs.
• Some of the carbon incorporates into amino acids,
  lipids, and nucleic acids.
• Some of the stored energy is consumed by
  heterotrophs, where glycolysis and respiration
  release the stored energy.

38
Controls over photosynthesis

• Spatial heirarchy is important for understanding
  photosynthetic regulation
• Physicochemical constraints
• Biochemcial constraints
• Diffusive constraints
• Whole-organism constraints

39
Figure 8.3 An Overview of Photosynthesis
Chloroplast
40
(No Transcript)
41
Figure 8.1 The Ingredients for Photosynthesis
42
Other issues - Photorespiration

• Rubisco is a carboxylase, adding CO2 to RuBP. It
  can also be an oxygenase, adding O2 to RuBP.
• These two reactions compete with each other.
• When RuBP reacts with O2, it cannot react with
  CO2, which reduces the rate of CO2 fixation.

43
Photorespiration and Its Consequences

• Photorespiration
• RuBP O2 phosphoglycolate 3PG.
• Glycolate diffuses into organelles called
  peroxisomes.
• Peroxisomes convert glycolate to glycine.
• Glycine diffuses into mitochondria and is
  converted to glycerate and CO2.

44
Figure 8.15 Organelles of Photorespiration
45
Photorespiration and Its Consequences

• Photorespiration uses the ATP and NADPH produced
  in light reactions.
• CO2 is released rather than fixed.
• Rubisco acts as an oxygenase if CO2 is very low
  and O2 is high.
• O2 becomes high when stomata close, preventing
  plant water loss.

46
(No Transcript)
