Some Issues in System-Level Power Optimization

1

• Some Issues in System-Level Power Optimization
• Abdil Rashid Mohamed, ESLAB, Ph.D. student

2
Presentation Organization

• 1015 - 1115 ? Abdil
• System-level Power/Energy Optimization Techniques
• 1115 - 1130 ? coffee break
• 1130 - 1200 ? Mehdi part I
• 1315 -1345 ? Mehdi part II
• Dynamic Power Management
• Low Power Software Generation
• 1345 1400 ? coffee break
• 1400 1500 ? Aleksandra
• Low Power/Energy Scheduling for Realtime Systems

3
Outline

• Motivation - the compeling need for low power
  systems
• Power reduction at
• conceptualization and modeling levels
• design level - design of power efficient
• hardware units
• memories and
• communication buses
• Conclusion

4
Why Low Power Electronic Systems ?

• Power/Energy is expensive, non-renewable and
  negatively impacts on environments
• Extend life of battery powered systems laptops,
  PDAs.
• In desktops and servers high power consumption
  raises temperature and deteriorates performance
  and reliability.
• Increases need for cooling mechanisms.
• Technical feasibility of high performance
  computation due to heat extraction
• Power efficiency has economic, ecological and
  ethical reasons.
• It worth mention power crisis in California,
  Tanzania.

5
Power Reduction Techniques

• Static techniques for low power
• Applied at conceptualization and design time
• Synthesis for low power
• Compilation for low power
• Dynamic techniques for low power
• Dynamic power management (DPM) - use run time
  behavior to reduce power consumption when system
  is serving light load or when idle
• Dynamic voltage scaling (DVS)- change voltage at
  run time to manage power
• Shutdown unused I/O devices, NIC, display or HDs

6
Hardware Technologies for Low Power

• Very low supply voltage technologies.
• Multiple supply voltages on a single chip.
• Techniques for handling dynamically variable
  supply voltage and/or clock speed.

7
System Organization and Sources of power
Consumption

• Main consumers of energy in HW are
• computation, communication and storage units.
• Does software consume power ?
• Energy efficient design of HW/SW systems
• Need support of a design flow that takes power
  consumption into account at all steps of the
  design process.
• Power estimation metrics at different abstraction
  levels
• Drawbacks Metrics are less accurrate at higher
  levels
• Power depends on implementation specific details

8
Power Consideration at All Levels and Dimensions
Organized in two dimensional taxonomy
Computation -gt communication -gt storage
Abdil
Aleksandra
Mehdi
9
Conceptualization and ModelingSpecification and
Implementation Models
Which modeling style is good for power
consideration ?
10
Specification and Implementation Models

• Functional models
• addresses functionality and requirements
• executable (VHDL, C, Java for simulation ) or
  non executable ( task graph )
• Implementation models
• describe the target realization for systems.
• system complexity modular, component oriented,
  hierarchical.
• Implementation models for energy efficient
  systems modelling
• Spreadsheet model-expresses a combination of
  components and evaluates overall energy budget
• Power state machine model captures the power
  consumption of systems and their constituents as
  they evolve through a sequence of operational
  states.

11
Energy Efficient Design from Executable
Functional Models

• Algorithm selection for low power
• For a given common function, make a library of
  multiple different algorithms
• Characterize each algorithm with performance
  power
• Perform system optimization by
• heuristic to select an implementation algorithm
  and supply voltage that trades off performance
  for power.
• Algorithm computational energy
• Computational energy of the algorithm can be
  estimated using CDFG
• Characterize each elementary operation with a
  computational energy metric
• Compose rules to compute energy cost of a complex
  CDFG.
• Energy of elementary operations is obtained by
  assuming implementation style and extract cost
  per operation through experiments

12
Energy Efficient Design from Executable
Functional Models

• Algorithm communication and storage energy
• communication and storage cost is hidden in
  specifications
• storage and communication energy relate to
  locality of computation data
• data variables with long life time -gt increased
  storage need -gt more power
• problem locality analysis from CDFG is hard,
  information not explicitly available
• Computational kernels
• is an inner loop of an algorithm where most of
  the time is spent during execution
• extract them by profiling data on executable
  system level model
• implement on dedicated power-optimal hardware
• during execution of kernel, rest of system can be
  shutdown, hence save power

13
Power Estimation for non executable functional
models Task Graph
PE allocation, binding, scheduling PE1
T1-gtT2-gtT3-gtT7-gtT4 PE2 T5-gtT6
Communication PE1 lt-gtPE2 L1
Mem allocation M1 T5, T6 M2 T1, T2, T3, T4,
T7
14
Task Graph (contd. )

• Computation energy
• EPE EPE1 EPE2 (1015101112) (4110)
  109
• Storage energy
• EM EM1 EM2 (0.50.3).50 (0.10.10.30.10
  .1).60 88
• Communication energy
• ECom EPE1-gtPE2 EPE2-gtPE1 (0.10.4).20 10
• Total energy
• E EPEEMEcom 1098810 206
• Heuristic to minimize power for the task graph
  implementation
• Drawbacks Need for exhaustive pre-characterizatio
  n and loss of accuracy due to lack of information
  on the effects caused by hardware sharing.

15
Energy efficient design from implementation
models

• Spreadsheet model
• Expresses a combination of components and
  evaluates overall energy cost
• Useful when designing systems that use specific
  parts and interconnect topologies
• Estimates the impact of a component on the power
  budget
• Total power is the sum of the power of all
  components.
• Power consumption of all components is taken from
  data sheets and collected in a spreadsheet.
• Drawback do not model interaction between
  components

16
Energy efficient design from implementation models

• Power State Machine (PSM)
• State based model for system components
• states represent modes of operations
• arcs represent legal transitions between op.
  modes
• states are labelled with power dissipation values
• transitions are labelled with triggering events,
  energy costs and transition times.
• Advantages
• study how system reacts to different workloads
• model interactions between components
• analyze the effects of power management.
• Drawbacks complex component model

17
Low Power Application Specific Units

• Usually gives better power efficiency, but have
  low flexibility
• Power reduction techniques low power RTL, logic
  level and physical level techniques
• Power Driven Voltage Scaling (PDVS) and scaling
  down Vdd, reduce power, but performance may
  diminish.
• multiple supply voltages on a single chip
  (globally asynchronous and locally synchronous
  systems (GALS) )
• reduce clock frequency, load capacitance and
  switching activity.
• set clock frequency of a component that is not
  performing useful work to zero and nullify
  dynamic power consumption of that component
• A. Hemani transformed single clock industrial
  designs into GALS - 70 power reduction

18
Low Power through Switching Activity Reduction

• Reduce the number of basic operations, -gt
  transform DFG to minimize the number of
  operations
• Reduce switching of the inputs to functional unit
  (FU) -gt increase correlation between successive
  patterns at the input of FU.
• Scheduling and binding for reduced switching
  activity

19
Application Specific Processors

• Provides high degree of flexibility,
  programmability, and reuse
• Not energy efficient and have several
  disadvantages
• Power overhead for instruction fetch and decoding

• not an issue for computation units with hardwired
  control
• Perform computation as a sequence of instruction
  execution -gtpower overhead
• can not take full advantage of algorithmic
  parallelism.
• Can perform a limited number of elementary
  operations specified by ISA
• Low power technique Instruction subsetting -gt
  reducing the number of instructions supported by
  ASIP
• Reduce instruction decoding and micro
  architectural complexity

20
Core Processors

• Reduce power by
• Voltage scaling
• low power version of µPs has low supply voltage
• Dynamic variable voltage supply
• Low power micro architecture design (critical
  path redesign)
• avoid useless switching activity in idle units
• Special instructions - enhance power
  performance
• subword parallel, special addressing mode,
  multiply-accumulate
• problem hard to design compilers for special
  instructions

21
Design of Power-Efficient Memory Subsystems

• Memory accesses are slow and consume more power
  with increasing memory size
• reduce memory storage requirements of the
  applications
• during system conceptualization use principle of
  temporal locality to reduce memory storage
  requirement
• improve locality and reduce need for temporary
  storage of results of computation by consuming
  them ASAP
• Reduce memory need by data compression
• Advanced hierarchical memory architectures for
  low power

22
Hierarchical Memory Models

• Power and access time increases as we move up
  memory hierarchy
• Exploit non uniformities in access frequencies of
  data
• Place frequently accessed locations in low
  hierarchies to minimize average cost per access

23
Low Power Communication Resources

• At physical level communication power is reduced

• scaling down the voltage swing on the high
  capacitance wires of the bus
• scaling down the average number of signal
  transitions
• low power data encoding
• Arbitration protocols
• bus access control
• reduce bus power by scheduling binding highly
  correlated data streams consecutively on the bus

24
Low Power Bus Design

• Low power bus design techniques
• lower switching activity, reduce capacitance to
  be switched
• minimize bus length by module placement and bus
  routing
• build hierarchical bus
• Bus segmentation
• transform a long heavily loaded global bus into a
  partitioned multistage network by inserting pass
  transistors on the bus lines to separate various
  local buses (segments)
• partitioning can reduce bus power by 60

25
Conclusion

• A balance between power and performance
• Designing energy efficient systems is a
  multifaceted problem high degree of freedom for
  power reduction at all abstraction levels
• Main referenece Benini, D. Micheli, System
  level Power Optimization Techniques and Tools
• THE END

26
Power Crisis

• It worth mention Power crisis in California,
  Tanzania.
• Companies install their own power plants to cope
  with the problem.
• 12 additional surcharge per day per room due to
  increased power cost at some hotels.
• Refereences from
• http//www.aspstreet.com/archive/d.taf/what,show/i
  d,6362/sid,14 Keeping the Silicon Burning
  California's Power Crisis Concern for Data
  Centers The lights in California may fade, but
  data and Web pages are still served up. What
  weve done is protect our customers, asserts
  Lloyd Howison, senior manager of construction and
  engineering for Web hosting at WorldCom. Data
  centers themselves contribute significantly to
  the power problem. Full of servers, disk drives,
  networking gear and cooled air, data centers
  consume a staggering amount of electricity.
  Reportedly, a data center gobbles as much power
  as six office buildings. A widely publicized 1999
  study estimated that eight percent of the U.S.
  consumption of electricity was Internet related.
• An Internet service provider data warehouse with
  8,000 servers consume as much as 2 MW of power. A
  household in Tanzania gets only about 600KWh per
  month.
• NB Since embedded systems are increasingly
  being used and are massively produced not only
  for mobile devices, but most of them end up in
  stationary home based or industry based devices,
  every Mw of power that can be saved will result
  in tremendous power savings in total due to mass
  production of similar embedded VLSI systems by
  Abdil.
• Since energy consumption of electronic systems
  will scale up as they become more complex and
  integrated, energy-efficient electronic system
  development is mandated by economic, ecological
  and ethical reasons.

Just for your information !
