Integrated Data Editing and Imputation

1
Integrated Data Editing and Imputation

• Ton de Waal
• Department of Methodology Voorburg Statistics
  Netherlands
• ICES III conference, Montréal
• June 19, 2007

2
What is statistical data editing and imputation?

• Observed data generally contain errors and
  missing values
• Statistical Data Editing (SDE)
• process of checking observed data, and, when
  necessary, correcting them
• Imputation
• process of estimating missing data and filling
  these values in into data set

3
What is integrated SDE and imputation?

• Integration of error localization and imputation
• Integration of several edit and imputation
  techniques to optimize edit and imputation
  process
• Integration of statistical data editing into rest
  of statistical process

4
What is integrated SDE and imputation?

• Integration of error localization and imputation
• Integration of several edit and imputation
  techniques to optimize edit and imputation
  process
• Integration of statistical data editing into rest
  of statistical process

5
SDE and the survey process

• We will focus on identifying and correcting
  errors
• Other goals of SDE are
• identify error sources in order to provide
  feedback on entire survey process
• provide information about the quality of incoming
  and outgoing data
• Role of SDE is slowly shifting towards these
  goals
• feedback on other survey phases can be used to
  improve those phases and reduce amount of errors
  arising in these phases

6
Edits

• Edit rules, or edits for short, often used to
  determine whether record is consistent or not
• Inconsistent records are considered to contain
  errors
• Consistent records that are also not suspicious
  otherwise, e.g. are not outlying with respect to
  the bulk of the data, are considered error-free
• Example of edits (T turnover, P profit, and C
  costs)
• T  P  C (balance edit)
• T 0

7
SDE and imputation

• Three related problems
• Error localization determine which values are
  erroneous
• Correction correct missing and erroneous data in
  best possible way
• Consistency adjust values such that all edits
  become satisfied
• Correction often done by means of imputation

8
SDE and imputation

• Three related problems
• Error localization determine which values are
  erroneous
• Imputation impute missing and erroneous data in
  best possible way
• Consistency adjust imputed values such that all
  edits become satisfied

9
SDE and imputation

• Three related problems
• Error localization determine which values are
  erroneous
• Imputation impute missing and erroneous data in
  best possible way
• Consistency adjust imputed values such that all
  edits become satisfied
• Most SDE techniques focus on error localization

10
SDE in the old days

• Use of computers in SDE started many years ago
• In early years role of computers restricted to
  checking which edits were violated
• Subject-matter specialists retrieved paper
  questionnaires that did not pass all edits and
  corrected them
• After correction, data were again entered into
  computer, and again checked whether all edits
  were satisfied
• Major problem during manual correction process
  records were not checked for consistency

11
Modern SDE techniques

• Interactive editing
• Selective editing
• Automatic editing
• Macro-editing

12
Interactive editing

• During interactive editing a modern survey
  processing system (e.g. BLAISE) is used
• Such a system allows one to check and if
  necessary correct in a single step
• Advantages
• number of variables, edits and records may be
  high
• quality of interactively edited data is generally
  high
• Disadvantage
• all records have to be edited costly in terms of
  budget and time
• not transparent

13
Selective editing

• Umbrella term for several methods to identify the
  influential errors
• Aim is to split data into two streams
• critical stream records that are the most likely
  ones to contain influential errors
• non-critical stream records that are unlikely to
  contain influential errors
• Records in critical stream are edited
  interactively
• Records in non-critical stream are either not
  edited or are edited automatically

14
Selective editing

• Many selective editing methods are based on
  common sense
• Most often applied basic idea is to use a score
  function
• Two important components
• influence measures relative influence of record
  on publication figure
• risk measures deviation of observed values from
  anticipated values (e.g. medians or values from
  previous years)

15
Selective editing

• Local score for single variable within record
• usually defined as distance between observed and
  anticipated values, taking influence of record
  into account
• Example W x Y Y
• W raising weight, Y observed value, Y
  anticipated value
• influence component W x Y
• risk component Y Y / Y
• Local scores combined into global score for
  entire record by
• sum of local scores
• maximum of local scores
• Records with global score above certain cut-off
  value edited interactively

16
Selective editing (dis)advantages

• Advantage
• selective editing improves efficiency in terms of
  budget and time
• Disadvantage
• no good techniques for combining local scores
  into global score are available if there are many
  variables
• Selective editing has gradually become popular
  method to edit business data

17
Automatic editing

• Two kinds of errors systematic ones and random
  ones
• Systematic error error reported consistently
  among (some) responding units
• gross values reported instead of net values
• values reported in units instead of requested
  thousands of units (so-called thousand-errors)
• Random error error caused but by accident
• observed value where respondent by mistake typed
  in a digit too many

18
Automatic editing of systematic errors

• Can often be detected by
• comparing respondents present values with those
  from previous years
• comparing responses to questionnaire variables
  with values of register variables
• using subject-matter knowledge
• Once detected, systematic error is often simple
  to correct

19
Automatic editing of random errors

• Three classes of methods
• methods based on statistical models (e.g. outlier
  detection techniques and neural networks)
• methods based on deterministic checking rules
• methods based on solving a mathematical
  optimization problem

20
Deterministic checking rules

• State which values are considered erroneous when
  record violates edits
• Example if component variables do not sum up to
  total, total variable is considered to be
  erroneous
• Advantages
• drastically improves efficiency in terms of
  budget and time
• transparency and simplicity
• Disadvantages
• many rules have to be specified, maintained and
  checked for validity
• bias may be introduced as one aims to detect
  random errors in a systematic manner

21
Error localization as mathematical optimization
problem

• Guiding principle is needed
• Freund and Hartley (1967) minimize sum of the
  distance between observed and corrected data
  and a measure for violation of edits
• Casado Valera et al. (90s) minimize quadratic
  function measuring distance between observed and
  corrected data such that corrected data
  satisfy all edits
• Bankier (90s) impute missing data and
  potentially erroneous values by means of donor
  imputation, and select imputed record that
  satisfies all edits and that is closest to
  original record

22
Fellegi-Holt paradigm (1976)

• Data should be made to satisfy all edits by
  changing values of fewest possible number of
  variables
• Generalization data should be made to satisfy
  all edits by changing values of variables with
  smallest possible sum of reliability weights
• reliability weight expresses how reliable one
  considers values of this variable to be
• high reliability weight corresponds to variable
  of which values are considered trustworthy

23
Fellegi-Holt paradigm (dis)advantages

• Advantages
• drastically improves efficiency in terms of
  budget and time
• in comparison to deterministic checking rules
  less, and less detailed, rules have to be
  specified
• Disadvantages
• class of errors that can safely be treated is
  limited to random errors
• class of edits that can be handled is restricted
  to so-called hard (or logical) edits which hold
  true for all correctly observed records
• risky to treat influential errors by means of
  automatic editing

24
Macro-editing

• Macro-editing techniques often examine potential
  impact on survey estimates to identify suspicious
  data in individual records
• Two forms of macro-editing
• aggregation method
• distribution method

25
Macro-editing aggregation method

• Verification whether figures to be published seem
  plausible
• Compare quantities in publication tables with
• same quantities in previous publications
• quantities based on register data
• related quantities from other sources

26
Macro-editing distribution method

• Available data used to characterize distribution
  of variables
• Individual values compared with this distribution
• Records containing values that are considered
  uncommon given the distribution are candidates
  for further inspection and possibly for editing

27
Macro-editing graphical techniques

• Exploratory Data Analysis techniques can be
  applied
• box plots
• scatter plots
• (outlier robust) fitting
• Other often used techniques in software
  applications
• anomaly plots graphical overviews of important
  estimates, where unusual estimates are
  highlighted
• time series analysis
• outlier detection methods
• Once suspicious data have been detected on a
  macro-level one can drill-down to sub-populations
  and individual units

28
Macro-editing (dis)advantages

• Advantages
• directly related to publication figures or
  distribution
• efficient in term of budget and time
• Disadvantages
• records that are considered non-suspicious may
  still contain influential errors
• publication of unexpected (but true) changes in
  trend may be prevented
• for data sets with many important variables
  graphical macro-editing is not the most suitable
  SDE method
• most persons cannot interpret 10 scatter plots at
  the same time

29
Integrating SDE techniques

• We advocate an SDE approach that consists of the
  following phases
• correction of evident systematic errors
• application of selective editing to split records
  in critical stream and non-critical stream
• editing of data
• records in critical stream edited interactively
• records in non-critical stream edited
  automatically
• validation of the publication figures by means of
  (graphical) macro-editing

30
Imputation

• Expert guess
• Deductive imputation
• Multivariate regression imputation
• Nearest neighbor hot-deck imputation
• Ratio hot-deck imputation

31
Deductive imputation

• Sometimes missing values can be determined
  unambiguously from edits
• Examples
• single missing value involved in balance edit
• for non-negative variables if a total variable
  has zero value all missing subtotal (component)
  variables are zero

32
Regression imputation

• Regression model per variable to be imputed
• Y A B X e
• Imputations for missing data can be obtained from
• Y Aest Best X
• or from
• Y Aest Best X e
• where e is drawn from appropriate distribution

33
Regression imputation

• Imputation can also be based on multivariate
  regression model that relates each missing value
  to all observed values Ymis Meanmis B(Yobs
  Meanobs) e
• Estimates of model parameters can be obtained by
  using EM-algorithm
• Imputations for missing data can be obtained from
• Ymis Meanest,mis Best(Yobs Meanest,obs)
• or from
• Ymis Meanest,mis Best(Yobs Meanest,obs)
  e
• where e is drawn from appropriate distribution

34
Nearest neighbor hot deck imputation

• For each receptor record with missing values on
  some (target) variables a donor record is
  selected that has
• no missing values on auxiliary and target
  variables
• smallest distance to receptor
• Replace missing values by values from donor
• Often used distance measure is minimax distance
• Zsi value of scaled auxiliary variable i in
  record s
• distance between records s and t
• D(s,t) max_i Zsi Zti

35
Ratio hot deck imputation

• Modified version of nearest neighbor hot-deck for
  variables that are part of balance edit
• Calculate difference between total variable and
  sum of observed components
• this difference equals the sum of the missing
  components
• Sum of missing components are distributed over
  missing components using ratios (of missing
  components to sum of missing components) from
  donor record
• level of imputed components is determined by
  total variable but their ratios are determined by
  donor
• imputed and observed components add up to total

36
Example of ratio hot deck

• P C T
• Record to be imputed given by
• T 400, P ?, C ?
• Donor record
• T 100, P 25, C 75
• Imputed record
• T 400, P 100, C 300

37
Consistency

• If imputed values violate edits, adjust them
  slightly
• Observed values not adjusted
• Minimize Si wi Yi,final Yi,imp subject to
  restriction that Yi,final in combination with
  observed values satisfy all edits
• Yi,imp imputed values (possibly failing edits)
• Yi,final final values
• wi user-specified weights
• As numerical edits are generally linear
  (in)equalities, resulting problem is a linear
  programming problem

38
Consistency

• Prerequisite
• it should be possible to find values Yi,final
  such that all edits become satisfied
• this is the case if Fellegi-Holt paradigm has
  been applied to identify errors
• Instead of first imputing and then adjusting
  values, better (but more complicated) approach is
  to impute under restriction that edits become
  satisfy
• see doctorate thesis by Caren Tempelman
  (Statistics Netherlands, www.cbs.nl)

39
Conclusion

• All editing and imputation methods have their own
  (dis)advantages
• Integrated use of editing techniques (selective
  editing, interactive editing, automatic editing,
  and macro-editing) as well as various imputation
  techniques can improve efficiency of SDE and
  imputation process while at same time maintaining
  or even enhancing statistical quality of produced
  data
