Chapter 3 The Laws of Thermodynamics

1
Chapter 3The Laws of Thermodynamics

• Notes on
• Thermodynamics in Materials Science
• by
• Robert T. DeHoff
• (McGraw-Hill, 1993).

2
The Laws of Thermodynamics

• 0th Law --- There is a temperature scale and
  energy (heat) flows down hill on that scale.
• 1st Law --- Energy is conserved.
• 2nd Law --- Entropy is not conserved. Entropy
  always changes in one direction (increases).
• 3rd Law --- There is an absolute zero
  temperature, and the entropy of all substances is
  the same at absolute zero.

3
Temperature Scales
4
Energy The ability to do work.Can be converted
or transported.Cannot be created or destroyed.

• Kinetic Energy --- Energy of motion.
• K.E. 1/2 mV2
• Potential Energy --- Energy of position in a
  potential field.
• P.E. mg.h ...
• Internal Energy (U) --- Energy associated with
  the condition of matter, not its motion or
  position.

5
First LawEnergy is a property of the universe
which cannot change no matter what process occurs.

• The change in internal energy of a system must be
  equal to the sum of all energy transfers across
  the boundary of the system.
• DU increase in the internal energy of the
  system.
• Q quantity of heat that flows into the system.
• W mechanical work done on the system by
  external pressure exerted by the surroundings.
• W/ all other kinds of work done on the system.
• For a process DU Q W W/
• For an infinitesimal step dU dQ dW dW/

6
WorkA process variable. Value depends on path.

• An increment of work (dW) equals an increment of
  motion (dx) of a point on a body under an applied
  force (F).
• dW F.dx
• The work done by a process is integrated over the
  path.

Substituting P F/A and dV -A.dx
7
Second Law

• Entropy is a property of the universe which
  always changes in the same direction no matter
  what process occurs.
• DSt, DSt/ entropy transferred across the
  boundary during the process for system
  surroundings, respectively.
• DSp , DSp/ entropy production within the system
  surroundings, respectively, during the process.

8
Entropy --- a State Function

• Entropy is transferred across a boundary
  created within the system the surroundings.
• Entropy production results from dissipative
  processes.
• Entropy production increases as the rate of the
  process increases system is further from
  equilibrium.
• Entropy processes carried out infinitesimally
  close to equilibrium, ideally, have zero entropy
  production are reversible.
• Real processes, carried out at finite rates, are
  irreversible, create entropy there is some
  permanent change in the universe.

9
3.6 Give five examples of the operation of the
second law of thermodynamics in your daily
experience (different from those given in the
text).

• The morning coffee cools with time.
• Sugar dissolves in hot coffee.
• Left to itself a pendulum will slow and stop.
• Organisms die.
• An expanding gas cools.

10
3.6 Why is irreversible so appropriate in its
application to the description of processes in
thermodynamics? Suggest 2 or 3 alternate phrases.

• Incapable of being reversed.
• The reverse process cannot happen.
• Process producing a permanent change.
• Irretraceable.
• All real processes are accompanied by permanent
  change in the universerse. By definition, the
  permanent changes cannot be undone by reversing
  the influences driving the system.

11
Combined 1st 2nd Laws

• Applying,
• dWrev -PdV
• and
• dQrev TdS
• then
• dU TdS - PdV dW/

12
The Third Law

• There is a lower limit to the temperature that
  can be attained by matter, absolute zero.
• The entropy of all substances at that
  temperature, at absolute zero, is the same.

13
Entropy Change for a Reaction
aA bB cC dD
DSO cSOC dSOD - aSOA bSOB
As example 3/2 SiO2 2Al 3/2 Si Al2O3
SO (J/mole-K) 42.09 11.55 18.83
50.99
DSO 3/2 (18.83) (50.99) - 3/2 (42.09) 2
(11.55)
DSO -7.0 J/mole-K
