Title: TNM Catalog


1
TNM Catalog
  • BASICS

2
What is a Catalog?
  • Catalogs
  • Are Distinct Collections of Referenced Items
  • Items are not stored in the catalog only
    references
  • There are no super-catalogs
  • Each has some qualifying constraint
  • Each has a distinct purpose.
  • Containing Adequate Descriptions of the Items
  • This metadata is directly related to the item
  • It is only as detailed as required for the
    purpose
  • Organized for Discover

3
What is the TNM Catalog?
  • The National Map (TNM) Catalog is
  • A Collection of TNM Web Service Metadata
  • Storing Service metadata - not the actual data.
  • Stores references to approved data not a
    discovery mechanism.
  • Described by TNM and Service metadata
  • TNM-specific attributes (theme,resolution,)
  • WMS Layer and WFS Feature Type attributes
  • Supports any TNM Client application
  • Accessible Through Standard Interfaces
  • OGC Catalog/Registry specifications
  • Web Service Interface (Java and .Net compatible)

4
How It Is Used - Basic
1 - CLIENT REQUEST TO CATALOG A client requests
all the TNM Service Information matching the
user-specified spatial and non-spatial
constraints of the client. 2 - CATALOG
RESPONSE The Catalog resolves spatial and
non-spatial queries against its data store and
responds with a list of Service Information
matching the request. 3 - CLIENT REQUEST TO
DISTRIBUTED SERVICES Based on the Catalog
response, the Client then makes a request to each
distributed service for its applicable
information. 4 DISTRIBUTED SERVICES
RESPONSE Each service processes the request from
the client and returns the data (an image,
feature info, or actual features) to the client.
TNM Catalog
2
1
TNM Client
3
4
Service
Service
Service
Service
5
How It Is Used - Expanded
TNM Catalog
TNM Internal
TNM Viewer
TNM PG
WMS
WMS
WFS
WMS
WMS
WFS
WFS
WMS
WFS
WFS
WMS
WFS
6
Catalog Significance
  • Logically Centralizes Critical TNM Metadata
  • Maintenance is simplified
  • Metadata consistency between clients.
  • Avoids Duplication of Query Resolution Operations
  • Leverages a Service-Oriented Architecture (SOA)
  • Takes advantage of common network services
  • Supports multi-client interoperability
  • Minimizes the effects of change by being
    loosely-coupled.

7
Catalog Milestones
8
TNM Catalog Components
  • Query Resolution Engine
  • Spatial Extents (MBR Polygon)
  • Theme Classification Layer/FeatureType
  • Attributes (Theme, Class, Resolution, )
  • Catalog API
  • Interface to Query Resolution Engine
  • Implemented as OGC Stateless Catalog
  • Implemented as Java Web Service
  • Middleware Servlets
  • Interface between Viewer Catalog API
  • Handles service disruptions
  • Advanced Image Handling
  • Business rule configuration
  • GUI
  • Handles view parameters
  • Handles user-specific requests

Oracle
Oracle Spatial
DB API
Catalog API
WSDL
OGC
Middleware Servlets
GUI
9
TNM Catalog Attributes
10
Catalog Issues
  • Oracle/Oracle Spatial vs. SQLServer/SDE
  • TNM Feature Classifications
  • OGC WMS Versions
  • WMS Optional Features
  • getFeatureInfo option
  • Styled-Layer Descriptor option (SLD)
  • WFS Dependencies
  • Feature query capability???
  • Download capability???
  • Overlapping Data Handling
  • Spatial Overlap
  • Query
  • Image
  • Attribute Resolution
  • TNM Catalog Roles
  • Symbology Data Model and Process

11
References Links
  • Current Under Catalog Instances
  • OGC Catalog Web Service http//isis.er.usgs.gov
    9080/catprod/start?requestgetRecords
  • Catalog-based Viewer (prod) http//isis.er.usgs
    .gov9080/tnmcatprod/Run.htm
  • Catalog-based Viewer (dev) http//isis.er.usgs.
    gov9080/tnmcatdev/Run.htm
  • Open GIS Consortium Links
  • OGC Home Page http//www.opengis.org/
  • Stateless Catalog Discussion Paper
    http//member.opengis.org/tc/archive/arch01/01-062
    .pdf
  • Services and data discovery Paper
    http//member.opengis.org/tc/archive/arch02/02-047
    .pdf
  • OGC Catalog Revision Working Group
    http//member.opengis.org/tc/revision.tf/cat.htm
  • OGC Catalog Revision Working Group (portal)
    http//member.opengis.org/portal/index.php
  • Contacts
  • Rick Brown reb_at_usgs.gov 573-308-3525
  • Jeff Wendel - jwend_at_usgs.gov 573-308-3632

12
Catalog Demo - ArcXMLConnector
  • Purpose
  • Provide TNM look-and-feel to Catalog efforts.
  • Reduce Client-Side development time.
  • Accommodate parallel development efforts that
    depend on ArcIMS functionality.
  • Investigate ArcXML incompatibilities with TNM.
  • Components
  • ArcXML Viewer essentially the out-of-the box
    ArcIMS HTML client communicating requests and
    responses using the ArcXML format. Instead of
    connecting to an ArcIMS map service the viewer
    connects to the USGS TNM ArcXML Connector.
  • ArcXMLConnector middleware implemented as a
    Servlet to provide translation of ArcXML requests
    into TNM Catalog queries and TNM Catalog
    responses back to ArcXML responses.
  • TNM Catalog The storage application for TNM
    service metadata. The interface to the catalog
    is an OGC Web Registry Service (WRS).

TNM Catalog
ArcXMLConnector
ArcXML Request
ArcXML Response
ArcXML Viewer
