CREATIVE IRIS Integrated Voice

1
CREATIVE IRIS Integrated Voice Data Exchange

• convergence at its best

2
Highlights of CREATIVE IRIS

• New 32 ports peripheral cards.
• Back-plane based on HDLC (High Level data Link
  Control).
• Existing Expandability upto 1000 ports.
• Provision for remote shelf access.
• ISDN BRI /PRI with QSIG on PRI
• New DLC design based on ISDN U interface
• Upto 56 kpbs modem speed on analog extensions

3
Highlights of CREATIVE IRIS

• SLICOFI based trunk/ext cards for providing
  programmable gain.
• Integrated Test and Diagnostic Functions
• Futuristic design to meet all present and future
  CTI data server applications.
• Compatibility with all latest telecom concepts

4
Cards used in CREATIVE IRIS

• MCC - Master Controller Card
• PSC - Peripheral Shelf Controller
• FLC 32 - Feature Line Card
• FTC(COIC 24) - 24 CO Interface Card
• DCC 16 - Digital Communication Card
• CEPT 30 - E1 Card
• DID 32 - DID card

5
Cards used in CREATIVE IRIS

• BWT 16 - Bothway Trunk Card or FXO/FXS
• BRI 8 - ISDN BRI card
• PRI 30 - ISDN PRI card
• SLC - Low cost Line Card
• ENM 8 - EM card (4/2 wire)

6
A 256 Ports CREATIVE IRIS-SL machine
MCC - Master Controller Card This card contains
the HDLC controllers, Switch, memory, peripheral
ports, DSP for tone gen., MFC tone gen det.,
Recordable music port (16 min.)
7
A 512 Ports CREATIVE IRIS-I machine
MCC - Master Controller Card This card contains
the HDLC controllers, Switch, memory, peripheral
ports, DSP for tone gen., MFC tone gen det.,
Recordable music port (16 min.)
8
A 1024 Ports CREATIVE IRIS-II machine
MCC
15 Peripheral Slots
PSC
15 Peripheral Slots
PSC - Peripheral Shelf Controller
9
A 1000 Ports CREATIVE IRIS-III machine
10
MCC - highlights

• Upto 1000 ports, the processor will be
• Intel 32 bit .
• On-board 32MB SDD for enhanced storage capacity
• IAU - CREATIVE IRIS Authorisation Unit for
  software lock - each machine has a unique ID

11
MCC - highlights

• 2 serial ports 1 parallel port
• Provision for Ethernet card (baby card)
• Communication with all peripheral cards thru HDLC
  controllers
• Voice switch for handling upto 1000 ports

12
MCC - DSP section

• On-board dual DSP - 100 MIPS each
• Programmable progress tone generation (i.e) Dial
  tone, RBT etc.
• Multi-channel DTMF dialing detection,
• Multi-channel MFC tones dialing detection

13
MCC - DSP section

• 16 minutes voice storage device for storing
  customised hold-on music
• 3 independent multi-message storing devices.

14
USPs OF THE CREATIVE IRIS

• Duslic based circuit designs for full 64Kbps
  bandwidth for internet access on subscriber side.
• Software controlled CLIP generation both DTMF
  and FSK, polarity reversal, message wait lamp,
  DTMF generation and detection, on hook
  transmission , fax modem detection, dynamic
  software gain control for teleconferences as well
  as
• Auto fault diagnostics like leakage currents,
  ringing voltage, foreign voltages, circuit
  breaks, faulty instruments etc.
• These features were available only on PTT
  exchanges and now available on the CREATIVE IRIS.
• Software programmable parameters ensure that
  interface and extension parameters can be
  modified on site to enable us to meet various
  specifications in different countries on site.


15
Advanced Backplanes

• The CREATIVE IRIS uses HDLC backplanes for
  primary voice circuit switching transmission .
• The CREATIVE IRIS will also incorporate Utopia
  level 2 backplane for compatibility to future
  transmission standards based on SDH or ATM
• This will allow an ATM cloud to be directly
  terminated on the Switch. Conventional switches
  use E1/PRI lines for these connections behind a
  router device.
• STM1s, ADSLs will be the new standards of
  broadband connectivities over ATM that can be
  terminated directly on the cards from the WAN.V
  5.1,V 5.2 as well as ADSL CO/CPE capability.
• Extension of ATM over copper wire upto 5 kms.

16
INskin/INbuilt Solutions

• The CREATIVE IRIS will offer in skin solutions on
  the same platform.
• In skin voice mail with seamless integration
• 10 BaseS Card for high speed LAN environment on
  copper and very high speed first/third party CTI
  applications.
• ADSL card for generating true DSL extensions with
  bandwidths of upto 1.5MB upload and 640 kb
  download.
• VOIP card with in skin gatekeeper functions for
  Voice over Internet .
• Multiple CREATIVE IRIS can be networked over the
  IP WAN for a true Virtual private network for
  voice and data switching over Internet protocol.
• H.323

17
IP Networking of CREATIVE IRIS
CREATIVE IRIS
CREATIVE IRIS
CHENNAI
EM MUXS
DELHI
CREATIVE IRIS
CREATIVE IRIS
MUMBAI
KOLKATTA
18
ExclusivePreview

• G.SHDSL capability for transmission of a
  combination of multiple voice channels and data
  over a single pair of copper wire, upto a
  distance of 5Kms.
• Broadband connectivity over existing copper media
  will give CREATIVE IRIS a tremendous cost
  advantage for networking our switches over
  Ethernet links extended on 2mb streams on copper
  pairs upto 5 kms.
• Existing copper pair can be used for connecting
  multiple LANs to form WANs.
• Such WANs can be used for providing multiple
  channels for voice transmission and integrated
  access to multilocational cos..

19
Exclusive Preview

• 10BaseS card for carrying Ethernet and voice on 2
  wire copper, upto a distance of 1.5kms . The
  card can be used for simultaneous voice and LAN
  transmissions.
• Existing standards of Ethernet are 10baseT or
  100base T over cat5 cabling limited to 200 Mtrs .
• 10baseS card finds wide applications in MTUs,
  MDUs, hospitality industry.

20
Connectivity Available in CREATIVE IRIS for LAN
extension
CREATIVE IRIS
ADSL Line
Ethernet Port
ADSLModem
To LAN
To local LAN or Internet
SHDSL Line
IAD - Integrated Access Device
21
10baseS in CREATIVE IRIS
Customer Premises
CREATIVE IRIS
10baseS Modem
Internet Cloud
1 pair Copper Wire
- Locally hosted services
- Internet Access
- Video servers
.
Ethernet Switch
Internet Access Router
22
Exclusive Preview

• Fibre connectivity for remote shelves
• Networking of CREATIVE IRIS over multi locations
  can be done over optical fibres. The optical
  fibres can be terminated directly on the Remote
  Switching Units (RSU)
• The RSUs are capable of operating as independent
  switches, in case of failures of the main and
  redundant fibre connectivity to the main
  switching unit (MSU)Main Switching Unit.

23
Exclusive

• ADSI- Analog Data Services interfaces.
• This technology will allow advanced KTS functions
  hitherto available on digital ports only, to be
  extended even on standard analog extensions.
• ADSI terminals will display SMS, CLIP, CIDCW and
  much more.
• ADSI terminals will also be able to send SMS to
  any part of the world

24
Exclusive

• COMPACT PCI BUS
• CPCI bus will allow the CREATIVE IRIS
  processors to be upgraded from 2000 ports to
  43,000 ports.
• Hot Stand by for mission critical functions.
• The latest processors can be added to the
  CREATIVE IRIS for system CPU processor up
  gradations.
• Multiple racks with multiple MCCs will
  integrate and share processor resources over
  remote locations on the CPCI bus very much
  like a super computer works.
• The CREATIVE IRIS can thus cater to an entire
  city and function like a City Exchange Grid.
