ECE 1747: Parallel Programming

1
ECE 1747 Parallel Programming

• Basics of Parallel Architectures
• Shared-Memory Machines

2
Two Parallel Architectures

• Shared memory machines.
• Distributed memory machines.

3
Shared Memory Logical View
Shared memory space
proc1
proc2
proc3
procN
4
Shared Memory Machines

• Small number of processors shared memory with
  coherent caches (SMP).
• Larger number of processors distributed shared
  memory with coherent caches (CC-NUMA).

5
SMPs

• 2- or 4-processors PCs are now commodity.
• Good price/performance ratio.
• Memory sometimes bottleneck (see later).
• Typical price (8-node) 20-40k.

6
Physical Implementation
Shared memory
bus
cache1
cache2
cache3
cacheN
proc1
proc2
proc3
procN
7
Shared Memory Machines

• Small number of processors shared memory with
  coherent caches (SMP).
• Larger number of processors distributed shared
  memory with coherent caches (CC-NUMA).

8
CC-NUMA Physical Implementation
mem2
mem3
memN
mem1
inter- connect
cache2
cache1
cacheN
cache3
proc1
proc2
proc3
procN
9
Caches in Multiprocessors

• Suffer from the coherence problem
• same line appears in two or more caches
• one processor writes word in line
• other processors now can read stale data
• Leads to need for a coherence protocol
• avoids coherence problems
• Many exist, will just look at simple one.

10
What is coherence?

• What does it mean to be shared?
• Intuitively, read last value written.
• Notion is not well-defined in a system without a
  global clock.

11
The Notion of last written in a Multi-processor
System
r(x)
P0
w(x)
P1
w(x)
P2
r(x)
P3
12
The Notion of last written in a Single-machine
System
w(x)
w(x)
r(x)
r(x)
13
Coherence a Clean Definition

• Is achieved by referring back to the single
  machine case.
• Called sequential consistency.

14
Sequential Consistency (SC)

• Memory is sequentially consistent if and only if
  it behaves as if the processors were executing
  in a time-shared fashion on a single machine.

15
Returning to our Example
r(x)
P0
w(x)
P1
w(x)
P2
r(x)
P3
16
Another Way of Defining SC

• All memory references of a single process execute
  in program order.
• All writes are globally ordered.

17
SC Example 1
Initial values of x,y are 0.
w(x,1)
w(y,1)
r(x)
r(y)
What are possible final values?
18
SC Example 2
w(x,1)
w(y,1)
r(y)
r(x)
19
SC Example 3
w(x,1)
w(y,1)
r(y)
r(x)
20
SC Example 4
r(x)
w(x,1)
w(x,2)
r(x)
21
Implementation

• Many ways of implementing SC.
• In fact, sometimes stronger conditions.
• Will look at a simple one MSI protocol.

22
Physical Implementation
Shared memory
bus
cache1
cache2
cache3
cacheN
proc1
proc2
proc3
procN
23
Fundamental Assumption

• The bus is a reliable, ordered broadcast bus.
• Every message sent by a processor is received by
  all other processors in the same order.
• Also called a snooping bus
• Processors (or caches) snoop on the bus.

24
States of a Cache Line

• Invalid
• Shared
• read-only, one of many cached copies
• Modified
• read-write, sole valid copy

25
Processor Transactions

• processor read(x)
• processor write(x)

26
Bus Transactions

• bus read(x)
• asks for copy with no intent to modify
• bus read-exclusive(x)
• asks for copy with intent to modify

27
State Diagram Step 0
I
S
M
28
State Diagram Step 1
PrRd/BuRd
I
S
M
29
State Diagram Step 2
PrRd/-
PrRd/BuRd
I
S
M
30
State Diagram Step 3
PrWr/BuRdX
PrRd/-
PrRd/BuRd
I
S
M
31
State Diagram Step 4
PrWr/BuRdX
PrRd/-
PrRd/BuRd
PrWr/BuRdX
I
S
M
32
State Diagram Step 5
PrWr/BuRdX
PrRd/-
PrWr/-
PrRd/BuRd
PrWr/BuRdX
I
S
M
33
State Diagram Step 6
PrWr/BuRdX
PrRd/-
PrWr/-
PrRd/BuRd
PrWr/BuRdX
I
S
M
BuRd/Flush
34
State Diagram Step 7
PrWr/BuRdX
PrRd/-
PrWr/-
PrRd/BuRd
PrWr/BuRdX
I
S
M
BuRd/Flush
BuRd/-
35
State Diagram Step 8
PrWr/BuRdX
PrRd/-
PrWr/-
PrRd/BuRd
PrWr/BuRdX
I
S
M
BuRdX/-
BuRd/Flush
BuRd/-
36
State Diagram Step 9
PrWr/BuRdX
PrRd/-
PrWr/-
PrRd/BuRd
PrWr/BuRdX
I
S
M
BuRdX/-
BuRd/Flush
BuRd/-
BuRdX/Flush
37
In Reality

• Most machines use a slightly more complicated
  protocol (4 states instead of 3).
• See architecture books (MESI protocol).

38
Problem False Sharing

• Occurs when two or more processors access
  different data in same cache line, and at least
  one of them writes.
• Leads to ping-pong effect.

39
False Sharing Example (1 of 3)

• for( i0 iltn i )
• ai bi
• Lets assume we parallelize code
• p 2
• element of a takes 4 words
• cache line has 32 words

40
False Sharing Example (2 of 3)
cache line
a0
a1
a2
a3
a4
a5
a6
a7
Written by processor 0
Written by processor 1
41
False Sharing Example (3 of 3)
a2
a4
P0
a0
...
inv
data
P1
a3
a5
a1
42
Summary

• Sequential consistency.
• Bus-based coherence protocols.
• False sharing.
