RTC-Mon

1
RTC-Mon

• Enabling High-Speed and Extensible
  Real-TimeCommunications Monitoring

Diego Costantini, Felipe Huici costantinihuici_at_
nw.neclab.eu
2
Motivation

• Internet as medium for real-time communications
  like VoIP has grown significantly over the past
  years
• However best-effort model not well-suited to
  these sort of applications
• Need real-time monitoring in order to
• ensure good service quality
• take corrective action should service degradation
  occur

3
Monitoring Difficulties

• Real-time monitoring is difficult
• System often has to correlate signaling and media
  streams
• Connections tend to use dynamic ports
• Monitoring in real-time results in non-trivial
  performance requirements
• In the case of VoIP, the abundance of small
  packets exacerbates this problem

4
State of the Art

• Current software solutions insufficient
• Limited monitoring capabilities, not easy to
  extend
• Long development time
• Not efficient enough to track traffic in
  real-time
• Hardware solutions are inflexible and hard to
  extend
• Need a general monitoring framework that
• provides basic VoIP monitoring capabilities in
  order to reduce development time
• is easily extensible
• is efficient enough to cope with demands of
  real-time traffic monitoring

5
RTC-Mon The Real-Time Communications Monitor
Framework

• Implemented over Linux
• Consists of
• Extended PF_RING with plugin architecture
• SIP and RTP plugins
• Event-based user-level library
• Also implemented VoIP Console
• Proof-of-concept monitoring application
• Small, quick to develop (800 lines of code)
• Can track numerous VoIP statistics

6
Extended PF_RING

• PF_RING
• Linux kernel module providing new type of socket
• Yields high performance
• Can be used with any network card
• Extended PF_RING
• Has plugin architecture
• Includes IP defragmentation

7
Extended PF_RING

• Each PF_RING socket has set of rules
• Processed sequentially
• Each rule has
• a filter
• a plugin ID to send packets to
• an action ID which decides what to do after
  plugin processes packet
• Filter can be hash or wild-card based
• Hash can be used to track flows (RTP plugin)
• Wildcard more flexible (match all UDP packets to
  one port)

8
Libvoip
VoIP console
custom application
APPS
USER SPACE
libvoip
libpfring
RTC-MON FRAMEWORK
SIP plugin
RTP plugin
custom plugin
KERNEL SPACE
extended PF_RING

• User-level, event-based library
• Extensible, can support other, non-VoIP
  applications
• Made of a dispatcher and trackers
• Dispatcher
• receives packets from plugins and decides which
  trackers to send them to
• Trackers
• Combine information from several plugins to
  monitor a specific characteristic of the traffic
• Can perform further analysis, parsing and can
  keep state
• Library is extended by writing custom trackers

network interfaces
9
Libvoip
VoIP console
custom application
APPS
USER SPACE
libvoip
libpfring
RTC-MON FRAMEWORK
SIP plugin
RTP plugin
custom plugin
KERNEL SPACE
extended PF_RING
network interfaces

• Implemented two trackers
• UserTracker, uses SIP information to keep track
  of SIP users
• CallTracker, combines SIP/RTP data to monitor
  call information

10
VoIP Console

• Proof-of-concept monitoring application
• Only 800 lines of code, short development time
• Uses UserTracker, CallTracker and SIP/RTP plugins
• Despite small size, can still track large number
  of statistics

11
Evaluation Testbed

• IXIA 400 generates up to 50,000 concurrent trash
  UDP flows
• VoIP traffic generator replays VoIP trace
• Trace has 1,000 calls each lasting 30 seconds

Codec Sample Size (bytes) Sample Rate (ms) Max Num Flows (Gb link)
G.711 80 10 11,468
G.726 20 5 18,116
G.726 15 5 21,186
G.728 10 5 31,780
G.729 10 10 32,051
iLBC 38 20 36,101
G.723.1 24 30 45,732
G.723.1 20 30 48,077
12
Performance

• Focus is on RTP traffic
• puts larger strain on system than SIP
• Measure improvement in CPU usage from performing
  data analysis in kernel

13
Performance

• Measure monitoring performance for 50,000 flows
  and varying number of RTP rules (flows)

14
Performance

• Rule reconfiguration times

Rules Avg. Ins. (usec) Max. Ins. (usec) Avg. Del. (usec) Max. Del. (usec)
10,000 20.9 98 4.7 81
20,000 22.3 130 5.3 95
30,000 25.2 210 7.9 150
40,000 27.9 379 12.7 22.5
50,000 47.1 2037 19.1 52.7

• In worst-case (2 msec) a single G.711 or G.729
  packet would go untracked

15
Conclusions

• Presented RTC-Mon
• Framework for quickly developing real-time
  monitoring applications
• Easily extensible, can support future
  applications
• Performs well even under heavy loads and small
  packet sizes
• Future work
• Additional plugins (RTSP, RTCP, MPEG-7?)
• Distributed monitoring
• Track SIP/RTP flows traversing different paths

16
