Equating And Scaling

1
Equating And Scaling
2
The Goal of this Session Is

• To give you a general idea of
• What equating is
• Why we need to do it
• How it works
• As part of this, we will discuss
• Different equating models
• A quick review of IRT
• Scaling

3
Why Equate?

• Why would the average raw scores on a test
  administered in 2006 and 2007 differ?

4
Why Equate?

• Why would the average raw scores on a test in
  2006 and 2007 differ?
• The 2006 form is harder than the 2007 form
• This years students are better prepared than
  last years were
• Both

5
Why Equate?

• Equating allows us to determine the extent to
  which
• one test is harder than the other (which is
  usually the case)
• one group is more able (i.e., has more of the
  construct of interest) than the other (also
  usually the case)
• This enables us to ensure that well-prepared
  examinees get higher scores than the less
  well-prepared, regardless of the test they took

6
Why Equate?

• If we gave both groups the same test, we could
  directly compare their performance, but this is
  not practical
• Security
• Release of items
• This is where equating items come in a subset
  of items administered in both tests

7
Why Equate?

• The performance on the equating items is used to
  compare student ability across the two groups
• We can use this information to determine to what
  extent the difference in performance is due to
  one group being better prepared than the other
• Once we know that, we can then determine how much
  harder or easier one test is than the other and
  adjust so that scores based on the two tests can
  be compared directly
• ? the tests are equated

8
Equating Items

• In order to ensure that this is done accurately,
  the equating items should have the following
  characteristics
• Good psychometric properties
• Be parallel to the overall test
• Content
• MC vs. CR items
• Passage length
• Graphics
• etc.

9
Equating Items

• The difficulty of the non-equating items in each
  test can vary -- within reason. However
• We dont want the feel of the assessment to
  change differentially for different subgroups of
  students. As one example
• If one test is harder than another, lower
  performing students may be more frustrated on the
  harder test
• If one test is easier than another, higher
  performing students may be more bored and
  unmotivated on the easier test
• Either of these could result in differences in
  performance on the two tests that are unrelated
  to the construct of interest

10
Equating Items

• In addition, equating items should not be changed
  in any way from one administration to the next
• Again, any change in the item (wording, location
  within the test, response options, etc.) can
  cause a change in student performance that is
  unrelated to the construct of interest

MUST!
11
Equating Models

• Classical test theory models (CTT)
• Item response theory models (IRT)
• Internal anchor (counts toward student scores)
• External anchor (doesnt count toward student
  scores)
• Intact, separate anchor test
• Embedded anchor test

12
Equating Models

• CTT models are concerned with estimating the
  relationships of the anchor test with each total
  test, and the anchor test in group 1 with the
  anchor test in group 2.
• IRT models focus on estimating the relationship
  of each item with the underlying trait (q) that
  is being measured.

13
Equating Models
Difficulty
Difficulty
Ability
Anchor 1
Anchor 2
Test 2
Test 1
Classical test theory equating diagram
14
Example

• Group 1 (2006)
• Total test score 30.6
• Score on equating items 14.2
• Group 2 (2007)
• Total test score 38.6
• Score on equating items 15.5
• Based on their performance on the equating items,
  we know that Group 2 is a bit higher performing,
  but their total score on the test is quite a bit
  higher which suggests that the 2007 test is
  easier.

15
Equating Models

• CTT models are well known, commonly used, and are
  relatively easy computationally
• IRT models have a shorter history and are
  computationally difficult, but they have certain
  advantages that make their use desirable
• At MP, we use pretty much exclusively IRT
  equating models

16
Basics of Item Response Theory

• Why Use IRT?
• Review of IRT
• The Item Characteristic Curve (ICC)
• The Test Characteristic Curve (TCC)

17
Why Use IRT?

• Advantages over CTT
• IRT allows us to calculate an estimate of student
  ability (q), not just observe how a particular
  student performs on a particular test
• IRT uses the same theta scale to describe
  students and items this has certain advantages
• It provides more sophisticated information that
  (depending on the specific model used) takes into
  consideration various characteristics of the item

18
The ICC

• Describes the interaction between examinees and
  test items
• In the simplest case, ability is a function of
  item difficulty
• As more sophisticated models are used, other item
  characteristics are taken into consideration as
  well

19
The Basics
20
The Basics
21
Item Difficulty
22
Item Discrimination
23
Item Guessing
24
A Test is Made up of Many ICCs
25
A Test is Made up of Many ICCs
26
A Test is Made up of Many ICCs
27
A Test is Made up of Many ICCs
28
A Test is Made up of Many ICCs
29
A Test is Made up of Many ICCs
30
For a given examinee with ability (?) 1.0
31
For a given examinee with ability (?) 1.0

• The expected score on the total test is equal to
  the sum of the probabilities for each item on the
  test 0.820.480.980.990.820.354.41

32
The TCC

• Summation of ICCs
• Describes the relationship between ability and
  expected performance on the whole test

33
TCC is the sum of the ICCs
34
TCC is the sum of the ICCs
35
Is It Really That Simple?

• Polytomous Items
• Parameter Estimation
• Item Parameters
• Person Parameters
• Various IRT Models
• Examinee-Model Fit

36
So What Does This Do For Us?

• Using the TCC, we can estimate the total test
  score for a student at a given level of ability
• In actuality, however, this isnt what we want to
  do we already know the students total raw
  scores what we dont know is their ability.
• Fortunately, once we have the ICCs and TCC, we
  can go the other way we can estimate ability
  based on a students observed total test score.

37
So What Does This Have to Do with Equating?

• Back in 2006, we established the relationship
  between the total test and student ability using
  the theta scale
• Using the equating items, we can put the 2007
  test on the same scale

38
How Do We Do This?

• Estimate item parameters (i.e., calibrate the
  items) for 2006 test
• Estimate item parameters for 2007 test, fixing
  the parameters for the equating items to their
  2006 values
• This forces the ability estimates for 2007 to
  be on the same scale as those for 2006
• As a result, we will get the same ability
  estimate for a student regardless of which test
  they took

39
2006 and 2007 TCCson the Same Scale
40
Typical Equating Process

• Selecting Equating Items
• IRT Calibrations/equating
• Determining scores for reporting (scaling)

41
Selecting Equating Items

• Initial Selection
• Test questions from last years test are included
  in this years test
• The total points from equating items should be at
  least 40 of the total points on the test
• The distribution of the items across different
  relevant categories is similar to that of the
  whole test
• Each item should be in about the same position
  this year and last year

42
Selecting Equating Items

• We also do some statistical checks to look for
  items that are functioning very differently in
  2007 than they did in 2006, relative to the rest
  of the equating items
• If we find those, we will exclude them from use
  as equating items

43
Item Calibrations

• We talked about this earlier, remember?
• Estimate parameters for 2006 items
• Estimate parameters for 2007 items, fixing the
  values for the equating items
• Voila the same ability estimate for students,
  regardless of which test they took!

44
Scaling

• It does not really make sense to report scores on
  the raw score metric
• Equated raw scores do not equal the number of
  points the student achieved on that test, but
  rather the number of points that the student
  would be expected to achieve on the equated to
  test

45
Scaling

• Similarly, it does not really make sense to
  report scores on the theta metric
• While psychometricians are quite fond of theta
  scores, they have some unfortunate
  characteristics (decimal and negative values)
  that would make them alarming to most test users
• (Note they in the previous sentence refers to
  the theta scores)

46
Scaling

• It does make sense to report scores on an
  arbitrary scale that has no inherent meaning.
• The meaning of the scale is defined by the
  assessment
• Scaled scores are typically a linear
  transformation of ability estimates
• Example of a linear transformation
• (Ability x Slope) Intercept

47
Scaling

• This appears to be pretty simple, but, like most
  things, scaling is more complicated than it
  appears at first

48
Issues in Scaling

• Endpoints
• If one test is more difficult than the other, the
  highest possible raw score on the harder test
  ought to result in a higher scaled score than the
  top score on the easier test.
• However, top bottom scores may be truncated so
  that a student who gets one or more items wrong
  may still receive the top scaled score, or a
  student who gets some items right may still
  receive the lowest scaled score.

49
Issues in Scaling

• Number of points
• Should be sufficient to differentiate examinees.
• Should not be more than the number of raw score
  points.
• Cut points
• If more than two cut-points are used and each
  cutpoint is a pre-determined scaled score, the
  scale will be non-linear. In this case taking
  averages is questionable.

50
Issues in Scaling

• Scale compression and/or expansion
• If cut points are very close together on the
  theta scale and far apart on the scaled score
  scale, or vice versa
• You can have compression in one part of the scale
  and expansion in another part

51
Determining Scaled Scores
52
Determining Scaled Scores
53
Determining Scaled Scores
Raw Score
Scaled Score
