Title: EDUSAT SESSION FOR COMPUTER NETWORKSI CS64


1
EDUSAT SESSION FOR COMPUTER NETWORKS-I
(CS64) Date 01.03.2006 Session I Topic
Introduction and Uses of N/W Faculty Anita
Kanavalli MSRIT
2
Course Overview
  • Introduction to Computer Networks
  • LANs
  • Network Layer
  • Transport Layer
  • ATM Networks

3
Text Reference Books
  • Text Books
  • - Computer Networks, By Andrew S Tanenbaum
    Fourth Edition PHI
  • - Communication Networks Fundamental Concepts
    and Key Architectures, By Alberto Leon Garcia
    and Indra Widjaja TMH second edition

4
Text Reference Books
  • Reference Books
  • - Data communications and Networking, By Behrouz
    A Forouzan TMH Third edition
  • - Data and Computer Communication, By William
    Stallings Fifth Edition PHI
  • - Computer Networking A Top Down approach
    featuring the internet By J F Kurose Keith W
    RossSecond edition PHI

5
Computer Network?

A computer network is a collection of computers
and other devices (nodes) that use a common
network protocol to share resources with each
other over a network medium. interconnected
collection of autonomous computers connected by a
single technology Tanenbaum
6
Why Computer Network?
  • To share information or receive a service via a
    network, group members must be able to
    communicate with each other.

7
Communication Model
  • Source
  • Generates data to be transmitted
  • Transmitter
  • Converts data into transmittable signals
  • Transmission System
  • Carries data
  • Receiver
  • Converts received signal into data
  • Destination
  • Takes incoming data

8
Communication Model

9
Communication Model

10
Classification of Computer Networks
  • Wired, Wireless and Fiber Optic Networks
  • LANs, MANs and WANs
  • Circuit Switched, Packet Switched and Virtual
  • Circuit Switched Networks
  • Access, Edge and Core Networks

11
Classification of Computer Networks
  • Architecture
  • Common LAN architectures Ethernet IEEE 802.3,
    Token Ring, and FDDI.
  • Access Possibilities
  • shared-media networks
  • switching networks
  • Transmission Technology
  • Broadcast links
  • Point-to-point links

12
Wired Network

13
Wireless Network

shared wireless access network connects end
system to router via base station aka access
point wireless LANs 802.11b (WiFi) 11 Mbps
14
Fiber Optic Network

15
LANs
  • company/univ local area network (LAN) connects
    end system to edge router
  • Ethernet
  • shared or dedicated link connects end system
    and router
  • 10 Mbs, 100Mbps, Gigabit Ethernet
  • deployment institutions, home LANs happening now

16
MAN

A cable TV is an example of MAN
17
WANs
  • Spans a large geographic area, e.g., a country
    or a continent
  • A WAN consists of several transmission lines and
    routers
  • Internet is an example of a WAN

18
Circuit Switched Network

19
Packet Switched Network

20
Virtual Circuit Switched Network

21
Access Edge/Core

22
Internetworking ?
  • internetwork interconnection of networks
    also called an internet
  • Subnetwork a constituent of an internet
  • Intermediate system a device used to connect
    two networks
  • allowing hosts of the networks to correspond
    with each other
  • Bridge
  • Routers
  • Internet is an example of an internetwork.

23
What is Internet ?

network of networks collection of networks
interconnected by routers a communication
medium used by millions Email, chat, Web
surfing, streaming media
24
What is Internet ?

25
What is Internet ?
  • millions of connected computing devices hosts,
    end-systems
  • PCs workstations, servers
  • PDAs phones, toasters
  • running network apps
  • communication links
  • fiber, copper, radio, satellite
  • Links have different bandwidth
  • routers forward packets
  • Packet a piece of messg.

26
Uses of Computer Networks
  • Business applications
  • Resource sharing
  • Example-client server model
  • E-mail
  • E-commerce

27
Application 1


28
Application 1
  • end systems (hosts)
  • run application programs
  • e.g. Web, email
  • at edge of network
  • client/server model
  • client host requests, receives service from
    always-on server
  • e.g. Web browser/server email client/server
  • Client/server model is applicable in an intranet.


29
Uses of Computer Networks
  • Home applications
  • Access to remote information
  • Person to person communication
  • Interactive entertainment
  • E-commerce

30
Uses of Computer Networks
  • Mobile users
  • PDA
  • WAP 1.0
  • Social Issues
