STI Cell Broadband Engine

1
STICell Broadband Engine

• Brian J. Alliet
• Jonathon W. Donaldson

2
Agenda

• History of development
• Technical overview of architecture
• Detailed technical discussion of components
• Design choices
• Other processors like the cell
• Programming for the cell

3
History of Development

• Ken Kutaragi
• Partnership between Sony, Toshiba, IBM (STI)
• Provide high-performance, low cost chip to the
  average home user
• Utilizes AIMs vector instructions (SPE, PPE) and
  PowerPC ISA (PPE)

4
Overall Goals for Cell

• High performance in multimedia apps
• Support for both real-time and general-purpose OS
• Power consumption Hofstee
• Low Cost
• Available 2005 ?
• Avoid latency issues

5
The Cell itself

• Power PC based main core (PPE)
• Multiple SPEs
• On die memory controller
• Inter-core transport bus
• High speed IO

6
(No Transcript)
7
Cell Implementation

• Cell is an architecture
• Preliminary PS3 Implementation
• 1 PPE
• 7 SPE (1 Disabled for yield increase)
• 221 mm² die size on a 90 nm process
• Clocked at 3-4ghz
• 256GFLOPS Single Precision _at_ 4ghz

8
Why a Cell Architecture

• Follows a trend in computing architecture
• Natural extension of dual and multi-core
• Extremely low hardware overhead
• Software controllable
• Specialized hardware more useful for multimedia

9
Possible Uses

• Playstation3 (Obviously)
• Blade servers (IBM)
• Amazing single precision FP performance
• Scientific applications
• Toshiba HDTV products

10
Power Processing Element

• PowerPC instruction set with AltiVec
• Used for general purpose computing and
  controlling SPEs
• Simultaneous Multithreading
• Separate 32 KB L1 Caches and unified 512 KB L2
  Cache

11
PPE (cont.)

• Slow but power efficient PowerPC instruction set
  implementation
• Two issue in-order instruction fetch
• Conspicuous lack of instruction window
• Compare to conventional PowerPC implementations
  (G5)
• Performance depends on SPE utilization

12
Synergistic Processing Element (SPE)

• Specialized hardware
• Meant to be used in parallel
• (7 on PS3 implementation)
• On chip memory (256kb)
• No branch prediction
• In-order execution
• Dual issue

13
SPE Architecture

• 0.99µm2 on 90nm Process
• 128 registers (128 bits wide)
• Instructions assumed to be 4x 32bit
• Variant of VMX instruction set
• Modified for 128 registers
• On chip memory is NOT a cache

14
SPE Execution

• Dual issue, in-order
• Seven execution units
• Vector logic
• 8 single precision operations per cycle
• Significant performance hit for double precision

15
SPE Execution Diagram
16
SPE Local Storage Area

• NOT a cache
• 256kb, 4 x 64kb ECC single port SRAM
• Completely private to each SPE
• Directly addressable by software
• Can be used as a cache, but only with software
  controls
• No tag bits, or any extra hardware

17
SPE LS Scheduling

• Software controlled DMA
• DMA to and from main memory
• Scheduling a HUGE problem
• Done primarily in software
• IBM predicts 80-90 usage ideally
• Request queue handles 16 simultaneous requests
• Up to 16 kb transfer each
• Priority DMA, L/S, Fetch
• Fetch / execute parallelism

18
SPE Control Logic

• Very little in comparison
• Represents shift in focus
• Complete lack of branch prediction
• Software branch prediction
• Loop unrolling
• 18 cycle penalty
• Software controlled DMA

19
SPE Pipeline

• Little ILP, and thus little control logic
• Dual issue
• Simple commit unit (no reorder buffer or other
  complexities)
• Same execution unit for FP/int

20
SPE Summary

• Essentially small vector computer
• Based on Altivec/VMX ISA
• Extensions for DMA and LS management
• Extended for 128x 128bit registerfile
• Uniquely suited for real time applications
• Extremely fast for certain FP operations
• Offload a large amount on to compiler / software.

21
Element Interconnect Bus

• 4 concentric rings connecting all Cell elements
• 128-bit wide interconnects

22
EIB (cont.)

• Designed to minimize coupling noise
• Rings of data traveling in alternating directions
• Buffers and repeaters at each SPE boundary
• Architecture can be scaled up with increased bus
  latency

23
EIB (cont.)

• Total bandwidth at 200GB/s
• EIB controller located physically in center of
  chip between SPEs
• Controller reserves channels for each individual
  data transfer request
• Implementation allows for SPE extension
  horizontally

24
Memory Interface

• Rambus XDR memory to keep Cell at full
  utilization
• 3.2 Gbps data bandwidth per device connected to
  XDR interface
• Cell uses dual channel XDR with four devices and
  16-bit wide buses to achieve 25.2 GB/s total
  memory bandwidth

25
Input / Output Bus

• Rambus FlexIO Bus
• IO interface consists of 12 unidirectional byte
  lanes
• Each lane supports 6.4 GB/s bandwidth
• 7 outbound lanes and 5 inbound lanes

26
Design Choices

• In-order execution
• Abandoning ILP
• ILP 10-20 increase per generation
• Reducing control logic
• Real time responsiveness
• Cache Design
• Software configuration on SPE
• Standard L2 cache on PPE

27
Cell Programming Issues

• No Cell compiler in existence to manage
  utilization of SPEs at compile time
• SPEs do not natively support context switching.
  Must be OS managed.
• SPEs are vector processors. Not efficient for
  general-purpose computation.
• PPEs and SPEs use different instruction sets.

28
The IBM Octopiler
29
Cell Programming (cont.)

• Functional Offload Model
• Simplest model for Cell programming
• Optimize existing libraries for SPE computation
• Requires no rebuild of main application logic
  which runs on PPE

30
Cell Programming (cont.)

• Device Extension Model
• Take advantage of SPE DMA
• Use SPEs as interfaces to external devices

31
Cell Programming (cont.)

• Computational Acceleration Model
• Traditional super-computing methods using Cell
• Shared memory or message passing paradigm for
  accelerating inherently parallel math operations
• Can overwrite intensive math libraries without
  rewriting applications

32
Cell Programming (cont.)

• Streaming model
• Use Cell processor as one large programmable
  pipeline
• Partition algorithms into logically sensible
  steps. Execute each separately, in serial, on
  separate processors.

33
Cell Programming (cont.)

• Asymmetric Thread Runtime Model
• Abstract Cell architecture away from programmer.
• Use OS to use processors to each run different
  threads.

34
Sample Performance

• Demonstration physics engine for real-time game
• http//www.research.ibm.com/cell/whitepapers/cell_
  online_game.pdf
• 182 Compute to DMA ratio on SPEs
• For the right tasks, Cell architecture can be
  extremely efficient.

35

• Supposed to act like cells in a biological system
• Core 512KB cache
• Different version with different numbers of SPEs
• PPE core carchitecture unlike ANY other Power
  architecture in existence (i.e. clock comparisons
  are meaningless) but same Instruction Set

36

• SPE
• 256kB local store
• Access only to LS
• 16 simultaneous transfers
• 128-bit by 128 entry register file

37
References

• IBM Cell Developer Works (SDK/Tutorials)
• http//www-128.ibm.com/developerworks/power/cell/
