Dijkstras Algorithm

1
Dijkstras Algorithm

• Matt Jurkoic
• CS566 Analysis of Algorithms
• April 10, 2007

2
Introduction

• Developed in 1959 by Edsger W. Dijkstra (1930
  -2002) a Dutch computer scientist
• Addresses the Shortest Path Problem
• Given a connected graph G (V, E), a weight
  dE-gtR and a fixed vertex s in V, find a
  shortest path from s to each vertex v in V.
• Specifically it solves the single source path
  problem for a directed graph with non-negative
  edge weights
• It is a greedy algorithm.

3
Description

• Start with a graph G (V, E) where V is the set
  of all vertices and E is the set of all edges.
  All edges have non-negative weights.
• Dijkstra's algorithm keeps two sets of vertices

• S  the set of vertices whose shortest paths
  from the source havealready been determined
• This is initialized to empty.
• V-S  the remaining vertices.
• This is initialized to the set of all vertices
  (V) in G
• The other data structures needed are
• d array of best estimates of shortest path to
  each vertex
• pi an array of predecessors for each vertex

4
Description (continued)

• The basic mode of operation is
• 1. Initialise d and pi,
• 2. Set S to empty,
• 3. While there are still vertices in V-S,
• i. Sort the vertices in V-S according to the
  current best estimate of their distance from the
  source,
• ii. Add u, the closest vertex in V-S, to S,
• iii. Relax all the vertices still in V-S
  connected to u

5
Description (continued)

• The relaxation process updates the costs of all
  the vertices, v, connected to a vertex, u, if we
  could improve the best estimate of the shortest
  path to v by including (u,v) in the path to v.
• The relaxation procedure starts with the
  following
• initialize_single_source( Graph g, Node s )
• for each vertex v in Vertices( g )
• g.dv infinity
• g.piv nil
• g.ds 0
• This sets up the graph so that each node has no
  predecessor (piv nil) and the estimates of
  the cost (distance) of each node from the source
  (dv) are infinite, except for the source node
  itself (ds 0).

6
Description (continued)

• The relaxation procedure checks whether the
  current best estimate of the shortest distance to
  v (dv) can be improved by going through u (i.e.
  by making u the predecessor of v)
• relax( Node u, Node v, double w )
• if dv gt du wu,v
• then dv du wu,v
• piv u

7
Pseudocode

• The algorithm itself is now
• Dijkstra( Graph g, Node s )
• initialize_single_source( g, s )
• S 0 / Make S empty /
• V-S Vertices( G ) / Put the vertices in
  a PQ /
• while not Empty(V-S)
• u ExtractMin( V-S )
• AddNode( S, u ) / Add u to S /
• for each vertex v in Adjacent( u )
• relax( u, v, w )
• http//www.cs.auckland.ac.nz/software/AlgAnim/dijk
  stra.html

8
Step1. Given initial graph G(V, E). All nodes
have infinite cost except the source node, s,
which has 0 cost.
9
Step 2. First we choose the node, which is
closest to the source node, s. We initialize
ds to 0. Add it to S. Relax all nodes adjacent
to source, s. Update predecessor (see red arrow
in diagram below) for all nodes updated.
10
Step 3. Choose the closest node, x. Relax all
nodes adjacent to node x. Update predecessors for
nodes u, v and y (again notice red arrows in
diagram below).
11
Step 4. Now, node y is the closest node, so add
it to S. Relax node v and adjust its predecessor
(red arrows remember!).
12
Step 5. Now we have node u that is closest.
Choose this node and adjust its neighbor node v.
13
Step 6. Finally, add node v. The predecessor
list now defines the shortest path from each node
to the source node, s.
14
Running Time

• V-S as a linear array
• EXTRACT_MIN takes O(V) time and there are V
  such operations. Therefore, a total time for
  EXTRACT_MIN in while-loop is O(V2). Since the
  total number of edges in all the adjacency list
  is E. Therefore for-loop iterates E times
  with each iteration taking O(1) time. Hence, the
  running time of the algorithm with array
  implementation is O(V2 E) O(V2).
• V-S as a binary heap ( If G is sparse)
• In this case, EXTRACT_MIN operations takes O(lg
  V) time and there are V such operations.The
  binary heap can be build in O(V) time.Operation
  DECREASE (in the RELAX) takes O(lg V) time and
  there are at most such operations.Hence, the
  running time of the algorithm with binary heap
  provided given graph is sparse is O((V E) lg
  V). Note that this time becomes O(ElgV) if all
  vertices in the graph is reachable from the
  source vertices.

15
Applications

• Trucking/Freight Delivery Company
• A trucking company can use this algorithm to
  determine the shortest route from city A to city
  B (or multiple cities) when delivering its
  freight.
• Phone/Power Company
• A utility can use this algorithm to determine
  the best route of a new line in its network to
  get from pole A to pole B (or multiple poles).
• Computer Network Design
• A computer network designer may use this
  algorithm to find an optimal network path to get
  from server A to server B (or multiple servers).

16
Comparisons with Other Algorithms

• Prims Algorithm
• Both Dijkstras Algorithm and Prims Algorithm
  use a min-priority queue to find the lightest
  vertex outside a given set. In Dijkstras it is
  the set S and in Prims it is the minimum
  spanning tree that is being built. Both
  algorithms then add this vertex into the set and
  adjust the weights of the remaining vertices,
  that are outside of this set, accordingly.
• Bellman-Ford Algorithm
• The Bellman-Ford Algorithm computes single
  source shortest paths in a weighted digraph where
  some of the edge weights may be negative as long
  as the graph contains no negative cycle reachable
  from the source vertex s. The presence of such
  cycles means there is no shortest path, since the
  total weight becomes lover each time the cycle is
  traversed. Dijkstras Algorithm accomplishes the
  same problem with a lower running time, but
  requires edge weights to be non-negative. Thus,
  Bellman-Ford is only used when there are negative
  edge weights.

17
References

• Grimaldi, Discrete and Combinatorial Mathematics,
  An Applie Introduction, 2000
• Cormen, Leiserson, Rivest, Stein, Introduction to
  Algorithms Second Edition, 2001
• E.W. Dijkstra Archive
• http//www.cs.utexas.edu/users/EWD/
• http//www.personal.kent.edu/rmuhamma/Algorithms/
  MyAlgorithms/GraphAlgor/dijkstraAlgor.htm
• National Institute of Standards and Technology
• http//www.cs.auckland.ac.nz/software/AlgAnim/dij
  kstra.html

18
References (continued)

• http//www.nist.gov/dads/HTML/greedyalgo.html
• Homepage of Kenji Ikada, Ph.D, The University of
  Tokushima
• http//www-b2.is.tokushima-u.ac.jp/ikeda/suu
  ri/dijkstra/Dijkstra.shtml
• Wikipedia entry for Dijkstras Algorithm
• http//en.wikipedia.org/wiki/Dijkstra27s_algorit
  hm
• Wikipedia entry for Greedy algorithm
• http//en.wikipedia.org/wiki/Greedy_algorithm
