Algorithms and the Grid

• Geoffrey FoxComputer Science, Informatics,
  Physics
• Pervasive Technology Laboratories
• Indiana University Bloomington IN 47401
• March 18 2005
• gcf_at_indiana.edu
• http//www.infomall.org

2
Trends in Simulation Research

• 1990-2000 the HPCC High Performance Computing and
  Communication Initiative
• Established Parallel Computing
• Developed wonderful algorithms especially in
  partial differential equation and particle
  dynamics areas
• Almost no useful software except for MPI
  messaging between parallel computer nodes
• 1995-now Internet explosion and development of
  Web Service distributed system model
• Replaces CORBA, Java RMI, HLA, COM etc.
• 2000- now almost no USA academic work in core
  simulation
• Major projects like ASCI (DoE) and HPCMO (DoD)
  thrive
• 2003-? Data Deluge apparent and Grid links
  Internet and HPCC with focus on data-simulation
  integration

3
e-Business e-Science and the Grid

• e-Business captures an emerging view of
  corporations as dynamic virtual organizations
  linking employees, customers and stakeholders
  across the world.
• e-Science is the similar vision for scientific
  research with international participation in
  large accelerators, satellites or distributed
  gene analyses.
• The Grid or CyberInfrastructure integrates the
  best of the Web, Agents, traditional enterprise
  software, high performance computing and
  Peer-to-peer systems to provide the information
  technology e-infrastructure for
  e-moreorlessanything.
• A deluge of data of unprecedented and inevitable
  size must be managed and understood.
• People, computers, data and instruments must be
  linked.
• On demand assignment of experts, computers,
  networks and storage resources must be supported

4
Some Important Styles of Grids

• Computational Grids were origin of concepts and
  link computers across the globe high latency
  stops this from being used as parallel machine
• Knowledge and Information Grids link sensors and
  information repositories as in Virtual
  Observatories or BioInformatics
• More detail on next slide
• Collaborative Grids link multidisciplinary
  researchers across laboratories and universities
• Community Grids focus on Grids involving large
  numbers of peers rather than focusing on linking
  major resources links Grid and Peer-to-peer
  network concepts
• Semantic Grid links Grid, and AI community with
  Semantic web (ontology/meta-data enriched
  resources) and Agent concepts
• Grid Service Farms supply services-on-demand as
  in collaboration, GIS support, Image processing
  filter

5
Information/Knowledge Grids

• Distributed (10s to 1000s) of data sources
  (instruments, file systems, curated databases )
• Data Deluge 1 (now) to 100s petabytes/year
  (2012)
• Moores law for Sensors
• Possible filters assigned dynamically (on-demand)
• Run image processing algorithm on telescope image
• Run Gene sequencing algorithm on compiled data
• Needs decision support front end with what-if
  simulations
• Metadata (provenance) critical to annotate data
• Integrate across experiments as in
  multi-wavelength astronomy

Data Deluge comes from pixels/year available
6
Virtual Observatory Astronomy GridIntegrate
Experiments
Radio
Far-Infrared
Visible
Dust Map
Visible X-ray
Galaxy Density Map
7
e-Business and (Virtual) Organizations

• Enterprise Grid supports information system for
  an organization includes university computer
  center, (digital) library, sales, marketing,
  manufacturing
• Outsourcing Grid links different parts of an
  enterprise together Manufacturing plants with
  designers
• Animators with electronic game or film designers
  and producers
• Coaches with aspiring players (e-NCAA or e-NFL
  etc.)
• Outsourcing will become easier ..
• Customer Grid links businesses and their
  customers as in many web sites such as amazon.com
• e-Multimedia can use secure peer-to-peer Grids to
  link creators, distributors and consumers of
  digital music, games and films respecting rights
• Distance education Grid links teacher at one
  place, students all over the place, mentors and
  graders shared curriculum, homework, live
  classes

8
DAME
In flight data
5000 engines
Gigabyte per aircraft per Engine per
transatlantic flight
Global Network Such as SITA
Ground Station
Airline
Engine Health (Data) Center
Maintenance Centre
Internet, e-mail, pager
Rolls Royce and UK e-Science ProgramDistributed
Aircraft Maintenance Environment
9
NASA Aerospace Engineering Grid
10
e-Defense and e-Crisis

• Grids support Command and Control and provide
  Global Situational Awareness
• Link commanders and frontline troops to
  themselves and to archival and real-time data
  link to what-if simulations
• Dynamic heterogeneous wired and wireless networks
• Security and fault tolerance essential
• System of Systems Grid of Grids
• The command and information infrastructure of
  each ship is a Grid each fleet is linked
  together by a Grid the President is informed by
  and informs the national defense Grid
• Grids must be heterogeneous and federated
• Crisis Management and Response enabled by a Grid
  linking sensors, disaster managers, and first
  responders with decision support
• Define and Build DoD relevant Services
  Collaboration, Sensors, GIS, Database etc.

11
Analysis and Visualization
Large Disks
Old Style Metacomputing Grid
Large Scale Parallel Computers
Spread a single large Problem over multiple
supercomputers
12
Classes of Computing Grid Applications

• Running Pleasing Parallel Jobs as in United
  Devices, Entropia (Desktop Grid) cycle stealing
  systems
• Can be managed (inside the enterprise as in
  Condor) or more informal (as in SETI_at_Home)
• Computing-on-demand in Industry where jobs
  spawned are perhaps very large (SAP, Oracle )
• Support distributed file systems as in Legion
  (Avaki), Globus with (web-enhanced) UNIX
  programming paradigm
• Particle Physics will run some 30,000
  simultaneous jobs this way
• Pipelined applications linking data/instruments,
  compute, visualization
• Seamless Access where Grid portals allow one to
  choose one of multiple resources with a common
  interfaces

13
What is Happening?

• Grid ideas are being developed in (at least) two
  communities
• Web Service W3C, OASIS
• Grid Forum (High Performance Computing,
  e-Science)
• Open Middleware Infrastructure Institute OMII
  currently only in UK but maybe spreads to EU and
  USA
• Service Standards are being debated
• Grid Operational Infrastructure is being deployed
• Grid Architecture and core software being
  developed
• Particular System Services are being developed
  centrally OGSA framework for this in
• Lots of fields are setting domain specific
  standards and building domain specific services
• Grids are viewed differently in different areas
• Largely computing-on-demand in industry (IBM,
  Oracle, HP, Sun)
• Largely distributed collaboratories in academia

14
A typical Web Service

• In principle, services can be in any language
  (Fortran .. Java .. Perl .. Python) and the
  interfaces can be method calls, Java RMI
  Messages, CGI Web invocations, totally compiled
  away (inlining)
• The simplest implementations involve XML messages
  (SOAP) and programs written in net friendly
  languages like Java and Python

PaymentCredit Card
Web Services
WSDL interfaces
Warehouse Shipping control
WSDL interfaces
Web Services
15
Services and Distributed Objects

• A web service is a computer program running on
  either the local or remote machine with a set of
  well defined interfaces (ports) specified in XML
  (WSDL)
• Web Services (WS) have many similarities with
  Distributed Object (DO) technology but there are
  some (important) technical and religious points
  (not easy to distinguish)
• CORBA Java COM are typical DO technologies
• Agents are typically SOA (Service Oriented
  Architecture)
• Both involve distributed entities but Web
  Services are more loosely coupled
• WS interact with messages DO with RPC (Remote
  Procedure Call)
• DO have factories WS manage instances
  internally and interaction-specific state not
  exposed and hence need not be managed
• DO have explicit state (statefull services) WS
  use context in the messages to link interactions
  (statefull interactions)
• Claim DOs do NOT scale WS build on experience
  (with CORBA) and do scale

16
Grid impact on Algorithms I

• Your favorite parallel algorithm will often run
  untouched on a Grid node linked to other
  simulations using traditional algorithms
• Algorithms tolerant of high latency
• Algorithms for new applications enabled by the
  Grid
• Data assimilation for data-deluged science
  generalizing data mining
• Where and how to process data
• Incorporation of data in simulation
• Complex Systems algorithms for non traditional
  simulations as in biology, social systems
• Cellular automata

17
Grid impact on Algorithms II

• MPI software model not suited for Grid use SOAP
  and publish/subscribe
• Microseconds and milliseconds Latency
• Grid workflow needs integration algorithms
• Multidisciplinary algorithms for loose code
  coupling
• Workflow scheduling algorithms (data oriented)
• Data caching algorithms
• Algorithms like distributed hash tables for
  distributed storage and look up of data
• Algorithms for Grid security
• Efficient support of group keys for multicast
• Detection of Denial of Service attacks
• Much better software available for building
  toolkits and Problem Solving Environments i.e.
  for using algorithms

18
Data Deluged Science

• In the past, we worried about data in the form of
  parallel I/O or MPI-IO, but we didnt consider
  it as an enabler of new algorithms and new ways
  of computing
• Data assimilation was not central to HPCC
• DoE ASCI set up because didnt want test data!
• Now particle physics will get 100 petabytes from
  CERN
• Nuclear physics (Jefferson Lab) in same situation
• Use around 30,000 CPUs simultaneously 24X7
• Weather, climate, solid earth (EarthScope)
• Bioinformatics curated databases (Biocomplexity
  only 1000s of data points at present)
• Virtual Observatory and SkyServer in Astronomy
• Environmental Sensor nets

19
Weather Requirements
20
Data DelugedScienceComputing Paradigm
Informatics
21
USArray Seismic Sensors
22
(No Transcript)
23
RepositoriesFederated Databases
Streaming Data
Sensors
Database
Database
Research
Education
SERVOGrid
Data FilterServices
Customization Services From Researchto Education
ResearchSimulations
Analysis and VisualizationPortal
EducationGrid Computer Farm
Geoscience Research and Education Grids
24
SERVOGrid Requirements

• Seamless Access to Data repositories and large
  scale computers
• Integration of multiple data sources including
  sensors, databases, file systems with analysis
  system
• Including filtered OGSA-DAI (Grid database
  access)
• Rich meta-data generation and access with
  SERVOGrid specific Schema extending openGIS
  (Geography as a Web service) standards and using
  Semantic Grid
• Portals with component model for user interfaces
  and web control of all capabilities
• Collaboration to support world-wide work
• Basic Grid tools workflow and notification
• NOT metacomputing

25
OGSA-DAIGrid Services
AnalysisControl Visualize
Grid
Data
Filter
Data Deluged ScienceComputing Architecture
HPC Simulation
Grid Data Assimilation
Other Gridand Web Services
Distributed Filters massage data For simulation
26
Data Assimilation

• Data assimilation implies one is solving some
  optimization problem which might have Kalman
  Filter like structure
• Due to data deluge, one will become more and more
  dominated by the data (Nobs much larger than
  number of simulation points).
• Natural approach is to form for each local
  (position, time) patch the important data
  combinations so that optimization doesnt waste
  time on large error or insensitive data.
• Data reduction done in natural distributed
  fashion NOT on HPC machine as distributed
  computing most cost effective if calculations
  essentially independent
• Filter functions must be transmitted from HPC
  machine

27
Distributed Filtering
Nobslocal patch gtgt Nfilteredlocal patch
Number_of_Unknownslocal patch
In simplest approach, filtered data gotten by
linear transformations on original data based on
Singular Value Decomposition of Least squares
matrix
Send needed Filter Receive filtered data
Nobslocal patch 1
Data
Filter
Nfilteredlocal patch 1
Geographically DistributedSensor patches
Nobslocal patch 2
Data
Filter
HPC Machine
Nfilteredlocal patch 2
Factorize Matrixto product of local patches
Distributed Machine
28
Non Traditional Applications Critical
Infrastructure Simulations

• These include electrical/gas/water grids and
  Internet, transportation, cell/wired phone
  dynamics.
• One has some classic SPICE style network
  simulations in area like power grid (although
  load and infrastructure data incomplete)
• 6000 to 17000 generators
• 50000 to 140000 transmission lines
• 40000 to 100000 substations
• Need algorithms both forsimulating
  infrastructuresbut also to link them

29
Non Traditional Applications Critical
Infrastructure Simulations

• Activity data for people/institutions essential
  for detailed dynamics but again these are not
  classic data but need to be fitted in data
  assimilation style in terms of some assumed lower
  level model.
• They tell you goals of people but not their low
  level movement
• Disease and Internet virus spread and social
  network simulations can be built on dynamics
  coming from infrastructure simulations
• Many results like small world internet
  connection structure are qualitative and unclear
  if they can be extended to detailed simulations
• A lot of interest in (regulatory) networks in
  Biology

30
(Non) Traditional Structure

• 1) Traditional Known equations plus boundary
  values
• 2) Data assimilation somewhat uncertain initial
  conditions and approximations corrected by data
  assimilation
• 3) Data deluged Science Phenomenological
  degrees of freedom swimming in a sea of data

Known Data
Known Equations on Agreed DoF
Prediction
PhenomenologicalDegrees of Freedom Swimming in a
Sea of Data
31
Some Questions for Non Traditional Applications

• No systematic study of how best to represent data
  deluged sciences without known equations
• Obviously data assimilation very relevant
• Role of Cellular Automata (CA) and refinements
  like the New Kind of Science by Wolfram
• Can CA or Potts model parameterize any system?
• Relationship to back propagation and other neural
  network representations
• Relationship to just interpolating data and
  then extrapolating a little
• Role of Uncertainty Analysis everything
  (equations, model, data) is uncertain!
• Relationship of data mining and simulation
• A new trade-off How to split funds between
  sensors and simulation engines

32
When is a High Performance Computer?

• We might wish to consider three classes of
  multi-node computers
• 1) Classic MPP with microsecond latency and
  scalable internode bandwidth (tcomm/tcalc 10 or
  so)
• 2) Classic Cluster which can vary from
  configurations like 1) to 3) but typically have
  millisecond latency and modest bandwidth
• 3) Classic Grid or distributed systems of
  computers around the network
• Latencies of inter-node communication 100s of
  milliseconds but can have good bandwidth
• All have same peak CPU performance but
  synchronization costs increase as one goes from
  1) to 3)
• Cost of system (dollars per gigaflop) decreases
  by factors of 2 at each step from 1) to 2) to 3)
• One should NOT use classic MPP if class 2) or 3)
  suffices unless some security or data issues
  dominates over cost-performance
• One should not use a Grid as a true parallel
  computer it can link parallel computers
  together for convenient access etc.

33
Building PSEs with theRule of the Millisecond I

• Typical Web Services are used in situations with
  interaction delays (network transit) of 100s of
  milliseconds
• But basic message-based interaction architecture
  only incurs fraction of a millisecond delay
• Thus use Web Services to build ALL PSE components
• Use messages and NOT method/subroutine call or
  RPC

34
Building PSEs with theRule of the Millisecond II

• Messaging has several advantages over scripting
  languages
• Collaboration trivial by sharing messages
• Software Engineering due to greater modularity
• Web Services do/will have wonderful support
• Loose Application coupling uses workflow
  technologies
• Find characteristic interaction time (millisecond
  programs microseconds MPI and particle) and use
  best supported architecture at this level
• Two levels Web Service (Grid) and
  C/C/C/Fortran/Java/Python
• Major difficulty in frameworks is NOT building
  them but rather in supporting them
• IMHO only hope is to always minimize life-cycle
  support risks
• Simulation/science is too small a field to
  support much!
• Expect to use DIFFERENT technologies at each
  level even though possible to do everything with
  one technology
• Trade off support versus performance/customization

35
Requirements for MPI Messaging
tcomm
tcalc
tcalc

• MPI and SOAP Messaging both send data from a
  source to a destination
• MPI supports multicast (broadcast) communication
• MPI specifies destination and a context (in comm
  parameter)
• MPI specifies data to send
• MPI has a tag to allow flexibility in processing
  in source processor
• MPI has calls to understand context (number of
  processors etc.)
• MPI requires very low latency and high bandwidth
  so that tcomm/tcalc is at most 10
• BlueGene/L has bandwidth between 0.25 and 3
  Gigabytes/sec/node and latency of about 5
  microseconds
• Latency determined so Message Size/Bandwidth gt
  Latency

36
Requirements for SOAP Messaging

• Web Services has much of the same requirements as
  MPI with two differences where MPI more stringent
  than SOAP
• Latencies are inevitably 1 (local) to 100
  milliseconds which is 200 to 20,000 times that of
  BlueGene/L
• 1) 0.000001 ms CPU does a calculation
• 2) 0.001 to 0.01 ms MPI latency
• 3) 1 to 10 ms wake-up a thread or
  process
• 4) 10 to 1000 ms Internet delay
• Bandwidths for many business applications are low
  as one just needs to send enough information for
  ATM and Bank to define transactions
• SOAP has MUCH greater flexibility in areas like
  security, fault-tolerance, virtualizing
  addressing because one can run a lot of software
  in 100 milliseconds
• Typically takes 1-3 milliseconds to gobble up a
  modest message in Java and add value

37
Structure of SOAP

• SOAP defines a very obvious message structure
  with a header and a body just like email
• The header contains information used by the
  Internet operating system
• Destination, Source, Routing, Context, Sequence
  Number
• The message body is partly further information
  used by the operating system and partly
  information for application when it is not looked
  at by operating system except to encrypt,
  compress it etc.
• Note WS-Security supports separate encryption for
  different parts of a document
• Much discussion in field revolves around what is
  referenced in header
• This structure makes it possible to define VERY
  Sophisticated messaging

38
MPI and SOAP Integration

• Note SOAP Specifies format and through WSDL
  interfaces
• MPI only specifies interface and so
  interoperability between different MPIs requires
  additional work
• IMPI http//impi.nist.gov/IMPI/
• Pervasive networks can support high bandwidth
  (Terabits/sec soon) but latency issue is not
  resolvable in general way
• Can combine MPI interfaces with SOAP messaging
  but I dont think this has been done
• Just as walking, cars, planes, phones coexist
  with different properties so SOAP and MPI are
  both good and should be used where appropriate

39
NaradaBrokering

• http//www.naradabrokering.org
• We have built a messaging system that is designed
  to support traditional Web Services but has an
  architecture that allows it to support high
  performance data transport as required for
  Scientific applications
• We suggest using this system whenever your
  application can tolerate 1-10 millisecond latency
  in linking components
• Use MPI when you need much lower latency
• Use SOAP approach when MPI interfaces required
  but latency high
• As in linking two parallel applications at remote
  sites
• Technically it forms an overlay network
  supporting in software features often done at IP
  Level

40
Pentium-3, 1GHz, 256 MB RAM 100 Mbps LAN JRE 1.3
Linux
41
(No Transcript)
42
Fast Web Service Communication I

• Internet Messaging systems allow one to optimize
  message streams at the cost of startup time,
• Web Services can deliver the fastest possible
  interconnections with or without reliable
  messaging
• Typical results from Grossman (UIC) comparing
  Slow SOAP over TCP with binary and UDP transport
  (latter gains a factor of 1000)

7020
5.60
43
Fast Web Service Communication II

• Mechanism only works for streams sets of
  related messages
• SOAP header in streams is constant except for
  sequence number (Message ID), time-stamp ..
• One needs two types of new Web Service
  Specification
• WS-StreamNegotiation to define how one can use
  WS-Policy to send messages at start of a stream
  to define the methodology for treating remaining
  messages in stream
• WS-FlexibleRepresentation to define new
  encodings of messages

44
Fast Web Service Communication III

• Then use WS-StreamNegotiation to negotiate
  stream in Tortoise SOAP ASCII XML over HTTP and
  TCP
• Deposit basic SOAP header through connection it
  is part of context for stream (linking of 2
  services)
• Agree on firewall penetration, reliability
  mechanism, binary representation and fast
  transport protocol
• Naturally transport UDP plus WS-RM
• Use WS-FlexibleRepresentation to define
  encoding of a Fast transport (On a different
  port) with messages just having
  FlexibleRepresentationContextToken, Sequence
  Number, Time stamp if needed
• RTP packets have essentially this structure
• Could add stream termination status
• Can monitor and control with original negotiation
  stream
• Can generate different streams optimized for
  different end-points

45
Role of Workflow
Service-2

• Programming SOAP and Web Services (the Grid)
  Workflow describes linkage between services
• As distributed, linkage must be by messages
• Linkage is two-way and has both control and data
• Apply to multi-disciplinary, multi-scale linkage,
  multi-program linkage, link visualization to
  simulation, GIS to simulations and visualization
  filters to each other
• Microsoft-IBM specification BPEL is current
  preferred Web Service XML specification of
  workflow

46
Example workflow
Here a sensor feeds a data-mining application (We
are extending data-mining in DoD applications
with Grossman from UIC) The data-mining
application drives a visualization
47
Example Flood Simulation workflow
48
SERVOGrid Codes, Relationships
Elastic Dislocation Inversion
Viscoelastic FEM
Viscoelastic Layered BEM
Elastic Dislocation
Pattern Recognizers
Fault Model BEM
This linkage called Workflow in Grid/Web Service
parlance
49
Two-level Programming I

• The Web Service (Grid) paradigm implicitly
  assumes a two-level Programming Model
• We make a Service (same as a distributed object
  or computer program running on a remote
  computer) using conventional technologies
• C Java or Fortran Monte Carlo module
• Data streaming from a sensor or Satellite
• Specialized (JDBC) database access
• Such services accept and produce data from users
  files and databases
• The Grid is built by coordinating such services
  assuming we have solved problem of programming
  the service

50
Two-level Programming II

• The Grid is discussing the composition of
  distributed services with the runtime interfaces
  to Grid as opposed to UNIX pipes/data streams
• Familiar from use of UNIX Shell, PERL or Python
  scripts to produce real applications from core
  programs
• Such interpretative environments are the single
  processor analog of Grid Programming
• Some projects like GrADS from Rice University are
  looking at integration between service and
  composition levels but dominant effort looks at
  each level separately

51
3 Layer Programming Model
Application (level 1 Programming)
MPI Fortran C etc.
Semantic Web
Application Semantics (Metadata, Ontology) Level
2 Programming
Basic Web Service Infrastructure
Web Service 1
WS 2
WS 3
WS 4
Workflow (level 3) Programming BPEL
Workflow will be built on top of NaradaBrokering
as messaging layer
52
Conclusions

• Grids are inevitable and pervasive
• Can expect Web Services and Grids to merge with a
  common set of general principles but different
  implementations with different scaling and
  functionality trade-offs
• We will be flooded with data, information and
  purported knowledge
• Develop algorithms that exploit and support the
  data deluge
• Software infrastructure for building tools
  getting much better
• Use MPI where its appropriate
