RTL Power Optimization with Gatelevel Accuracy

1
RTL Power Optimization with Gate-level Accuracy
Qi Wang Cadence Design Systems, Inc
Sumit Roy Calypto Design Systems, Inc
2
Outline

• Introduction
• Literature Review
• Proposed Approach
• Experimental Results
• Conclusion
• Future work

3
RTL Power Optimization Techniques

• Clock Gating
• Shut-off clock signal when the outputs of the
  driven registers are not used.
• Reduce the dynamic power dissipated by the clock
  tree network and the registers
• Sleep Mode (Operand Isolation)
• Shut-off combination blocks when the outputs of
  the blocks are not used.
• Useful for designs with lots of datapath blocks
  and small amount of average switching activities.

4
Example of Sleep Mode Transformation
5
Challenges
Timing Closure
a


1
b
out
1
0
Achieving Power Saving
0
en2
en1
Identifying Complex Enable Function
6
Literature Review

• H. Kapadia and et.al. Reducing Switching
  Activity on Datapath Buses with Control-Signal
  Gating, IEEE Journal of Solid-State Circuits,
  Vol. 34, No. 3, March 1999, pp. 405-414.
• 6 S. Dey and et. al., Controller-Based Power
  Management for Control-Flow Intensive Designs,
  IEEE Trans. on Computer-Aided Design of
  Integrated Circuits and Systems, Vol. 18, No. 10,
  October 1999, pp. 1496-1508.
• M. Munch, and et. al., Automating RT-Level
  Operand Isolation to Minimize Power Consumption
  in Datapaths, Proceedings of Design and Test
  Automation Conference in Europe, Mar. 2000, pp.
  624-631.

7
Limitations of Previous Work

• Insert gating logic before timing optimization
• Poor accuracy for power estimation at RTL
• Poor accuracy for timing analysis at RTL
• Problems for timing closure
• Timing constraints may be violated
• Inserted logic may shift critical path
• Simply undoing transformations is not enough
• Possible loops between RTL and timing
  optimization to achieve timing closure
• Result in long run time and bad QoR
• Power may be increased

8
Proposed Approach

• Objective
• A robust solution to meet the challenges of both
  timing closure and power requirement for
  nanometer designs.
• Two step approach
• RTL exploration
• Behavioral level observability analysis to derive
  complex enable function from CDFG.
• Mark the netlist with candidates for sleep mode
  transformations with enable functions but do not
  commit it.
• Gate-level committing
• Perform regular logic and timing optimization
  like not sleep mode logic has been inserted.
• Commit it after timing optimization.
• Accurate power and delay trade-off becomes
  possible.

9
Control Data Flow Graph (CDFG)
module m(a,b,en,clk,y) input en, clk input 70
a, b output 80 y register 80 y always _at_
(posedge clk) if (en) y a b endmodule
10
Behavioral Level Observability

• TOC Token Observable Condition of an edge is the
  condition under which the token on that edge can
  be observed at one or more output nodes of a
  CDFG.
• NOC Node Observable Condition is the condition
  under which the token on any input edge of the
  node can be observed at one or more output nodes
  of a CDFG.
• TO Token Observability of an edge is the
  probability of the TOC of this edge being 1.
• NO Node Observability of a node is the
  probability of the NOC of the node being 1.

11
Computation of TOC/NOC
Output/Register nodes NOC(nout) 1 TOC(i)
1
12
Computation of TOC/NOC (cont.)
Operation nodes NOC(nop) TOC(o0) ?
TOC(o1) ? ?
TOC(oj-1) TOC(ip) NOC (nop) ?
p ?0, 1, , k-1
13
Computation of TOC/NOC (cont.)
Merge nodes NOC(nmerge) TOC(o) TOC(c)
NOC(o) TOC(ip) cp ? TOC(o) where cp ? p ?0,
k-1 is a Boolean encoding of the variables for
the value of the token at the control port to
select output port p
14
Computation of TOC/NOC (cont.)
Branch nodes NOC(nbranch) TOC(o0) ?
TOC(o1) ? ... ? TOC(oj-1) TOC(c)
NOC(nbranch) TOC(i) c0 ? TOC(o0) ? c1
? TOC(o1) ? ? cj-1 ? TOC(oj-1) where cp
? p ?0, j-1 is a Boolean encoding of the
variables for the value of the token at the
control port to select output port p
15
Fast Computation of TOC/NOC
16
RTL Exploration
a
1
out
1

0
0
b
en1
en2
17
Gate Level Committing
a
1
out
1

0
0
b
en1
en2
18
Partial Committing
committed
fa(bc)
? fnewa
19
Synthesis Flows
20
Experiment Setup

• Implemented into Cadence PKS/LPS? 5.0
• A commercial low power synthesis tool for both
  logical and physical power optimization.
• Using the incremental power analysis engine
  inside PKS/LPS ? to evaluate the impact of power
  during the gate-level committing stage.
• Using the incremental timing analysis engine
  inside PKS to evaluate the impact of timing
  during the gate-level committing stage.
• The overhead of extra delay and power introduced
  by the gating logic is accurately considered.

21
Experiment Setup (cont.)

• 6 industrial blocks were chosen for
  experimentation
• All except 6 having customer provided simulation
  testbench to obtain the switching information for
  power estimation

22
Experimental Results
23
Experimental Results (cont.)

• Proposed approach can achieve a wide range of
  power delay trade-offs
• Design 6 was chosen to run the flow several times
  with different timing constraints

24
Conclusion

• Robust solution for applying sleep-mode
  transformation
• 2-step approach toward achieving RTL
  transformation with gate level accuracy
• Accurate and full range of power delay trade off
• No impact on normal timing optimization
• Fully automated
• Ideal solution to meet the challenges of both
  timing closure and power management for modern
  nanometer designs.
