TwoPort Networks

1
Two-Port Networks

• BEE2113 Signals Systems
• R. M. Taufika R. Ismail
• FKEE, UMP

2
Introduction
Two-port n/w
One-port n/w
Eg
Eg
R
L
C
3
Reciprocal symmetrical n/w

• Reciprocal n/w A two-port n/w which is linear
  has no dependent sources
• Symmetrical n/w A two-port n/w which has
  mirrorlike symmetry about some central line
  i.e. a line can be found that divides the n/w
  into two similar halves

4
Impedance (z) Parameters
5
Or
Equivalent circuit
6
The values of the parameters are
I2 0 means o/c port 2
I1 0 means o/c port 1
7
Finding z11 and z21 o/c port 2 and apply source
to port 1
Finding z12 and z22 o/c port 1 and apply source
to port 2
For reciprocal case z12 z21
8
Example 1 (Pb.19.1, pg.890)
Obtain the z parameters for the following n/w.
9
Solution
Finding z11 and z21 o/c port 2 and apply source
to port 1
10
Finding z12 and z22 o/c port 1 and apply source
to port 2
(or simply since reciprocal case)
11
Example 2 (P.P.19.2, pg.854)
Calculate I1 and I2 in the following two-port
12
Solution
Method 1 Use equivalent circuit
13
From (2)
Subst. into (1)
Hence
14
Method 2 Use matrix operations
Hence,
15
Therefore
16
Admittance (y) Parameters
17
Or
Equivalent circuit
18
The values of the parameters are
V2 0 means s/c port 2
V1 0 means s/c port 1
19
Finding y11 and y21 s/c port 2 and apply source
to port 1
Finding y12 and y22 s/c port 1 and apply source
to port 2
For reciprocal case y12 y21
20
Example 3 (P.P.19.3, pg.857)
Obtain the y parameters for the following n/w.
21
Solution
Finding y11 and y21 s/c port 2 and apply source
to port 1
22
(No Transcript)
23
Finding y12 and y22 s/c port 1 and apply I2 to
port 2
24
(or simply since reciprocal case)
25
Relation between z and y parameters
Therefore,
or
26
Hybrid (h) Parameters
Dependent variables
27
Or
Equivalent circuit
28
The values of the parameters are
V2 0 means s/c port 2
I1 0 means o/c port 1
29
Finding h11 and h21 s/c port 2 and apply source
to port 1
Finding h12 and h22 o/c port 1 and apply source
to port 2
For reciprocal case h12 -h21
30
Inverse Hybrid (g) Parameters
If I1 and V2 are chosen as the dependent
variables, then
That is
or
g parameters
31
Example 4 (Pb.19.34, pg.894)
Obtain the h and g parameters of the following
two-port n/w.
32
Solution
Finding h11 and h21 s/c port 2 and apply source
to port 1
33
(No Transcript)
34
Finding h12 and h22 o/c port 1 and apply source
to port 2
35
(No Transcript)
36
Hence,
Finding g,
37
Transmission (T or ABCD) Parameters
Dependent variables
38
Input V1 , I1
Output V2 , -I2
Linear Two-port
-I2 is used rather than I2 because the
current at port 2 is considered to be leaving
the network!
39
The values of the parameters are
I2 0 means o/c port 2
V2 0 means s/c port 2
40
Finding A and C o/c port 2 and apply source to
port 1
Finding B and D s/c port 2 and apply source to
port 1
For reciprocal case AD - BC 1
41
Inverse Transmission (t) Parameters
V1 and I1 are chosen as the dependent variables
If V2 and I2 are chosen as the dependent
variables, then
42
Notice that
because
43
Hence,
44
where
45
Example 5 (Pb.19.49, pg.896)

• Using impedances in the s-domain, obtain the
  transmission parameters for the following circuit.

46
Solution
Finding A and C o/c port 2 and apply source to
port 1
47
(No Transcript)
48
Finding B and D s/c port 2 and apply source to
port 1
49
Hence,
50
Summary
In summary,
For reciprocal case
51
(No Transcript)
52
Interconnections of N/w 1.Series
53
We have
and
Notice that
and
Hence
54
Interconnections of N/w 2.Parallel
55
We have
and
Notice that
and
Hence
56
Interconnections of N/w 3.Cascade
57
We have
and
Notice that
and
Hence
58
In summary,
series
cascade
parallel
59
Example 6 (P.P.19.13, pg.876)
Obtain the y parameters for the n/w
60
Solution
Na
Nb
Then find the y parameters for each of Na and Nb
61
Finding y parameters for Na
Finding y11 and y21
Finding y12 and y22
I1
I2
I1
I2
V1 -
V2 -
(reciprocal case)
62
Finding y parameters for Nb
Finding y11 and y21
Finding y12 and y22
I1
I2
I1
I2
V1 -
V2 -
(reciprocal case)
(symmetry)
63
We find that
Therefore, since Na and Nb are connected in
parallel,
