ICA-210 Pan / Tilt IP Camera Deluxe

1
ICA-210Pan / Tilt IP Camera Deluxe

• 2006.4.17

2
Presentation Outline

• Product Outlook
• Specification Features
• Applications

3
The Product

• ICA-210

• Internal Microphone

• Access LED
• Active or in privacy mode

• PIR Sensor
• Passive InfraRed Sensor

• Lens
• f 6.0mm/F 1.8 adjustable focus

• Compensative LED

• USB port

• Privacy mode button

• 10/100Base-TX LAN port

• 5VDC jack

• Desktop / Wall mount holes

• Reset button

4
Specification

• Hardware
• Image Sensor
• Color CMOS, VGA resolution, f6.0/F1.8
• Focus adjustable
• Video Compression
• M-Jpeg 30fps _at_ CIF/QCIF, 20fps_at_VGA
• 1x / 2x / 4x Digital Zoom
• Audio
• Built-in microphone, PCM compression
• PIR
• X/Y /-15 5-meter max.
• Compensative LED
• White light LED
• USB
• USB 1.1/2.0

5
Specification

• Hardware continued
• Pan / Tilt capability
• Pan /- 120 180 for privacy/park mode
• Tilt -5 45
• LAN
• 10/100Base-TX RJ-45 LAN
• Dimension (mm)
• W x D x H 80 x 110 x 100
• Desktop or Wall mountable
• Management
• Web browser
• IP View Pro

5
120
120
45
6
Features Benefits

• Easy Install
• Desktop or Wall mount
• Desk Stand for easy placement right on the
  desktop
• Wall mount holes for wall installation any where
• 10/100Base-TX LAN port
• Can direct wire to PC or LAN switches
• Live image and audio receiving through LAN
• Easy Management
• Web Brower support
• Use any at hand Internet Explorer 5.0 or above
• Built-in view integration, up to 4 cam viewed in
  one browser screen
• Web recording support
• IP View Pro support
• Up to 16 Cam viewed, record and managed

7
Features Benefits

• Live voice video
• Built-in mic and adjustable lens
• On-line recording
• Multiple view support
• Max. 4 ICA-210 can be viewed at one browser
  screen
• Can be used for object observation at different
  angel at one time

8
Features Benefits

• Pan, Tilt Digital Zoom
• 120 degree, Left and Right
• -5, 45 degree Up and Down
• 1x, 2x, 4x digital zoom

Digital Zoom
Buzzer
White light LED
Privacy Mode
PIR Sensor
Pan/Tilt direction PT quick tab
Snapshoot and recording
9
Features Benefits

• Up to 16 cameras manageable
• Through IP View Pro, up to 16 Camera can be
  viewed, recorded

10
Comparison

• ICA-210 v.s. Web Cam
• No dedicated PC with USB port required
• No driver required
• Audio and Video receiving / recording
• Supplemental LED for dark environment
• Better image quality

Web Cam images
ICA-210 images

• Sharper in image for moving object

• Even in the dark

• White light LED also provide the capability to
  see things in the dark (_at_ 1 meter)

11
Application

• Live communication
• With no need for driver, the ICA-210 shall
  provide an easy way for you to live communicate
  with your friends, colleagues no matter where
  they are
• DDNS supports
• Easy find the camera even using dynamic IP
• Privacy mode support
• Keep personal privacy when needed
• On line recording
• Schedule/ Access Time
• Privacy for off-business hour

12
Application

• Home object observation
• ICA-210 can be used for close object observation,
  or other purpose such as baby watching, antique,
  precious object monitoring, etc.
• Adjustable focus / Digital Zoom support
• Image/voice recording
• White Light LED
• Motion detection

13
Application

• Home Surveillance
• ICA-210 can be installed in the house or
  apartment anywhere (wired/wireless) for home
  surveillance and can be accessed from the
  Internet
• PIR Motion detection, Email alarm, FTP upload
• Pan and Tilt, Whit Light LED
• 4 Cam in one browser
• Digital Zoom
• Web recording
• USB backup
• Buzzer

Wireless Model ICA-210W will ready at June
14
Comparison
Feature ICA-102W ICA-210/210W ICA-500
WLAN 802.11b/g 802.11b/g na
Video compression MPEG-4 MJPEG (3 levels) MJPEG (3 levels)
Pan / Tilt (degrees) --- 120 to 180 / 45 to -5 0 to 325 / 10 to 90
PIR Sensor --- 5M PIR (Infrared Sensor) ---
USB Port --- USB 1.1/2.0 for Image backup ---
Supplement LED --- SuperLight white LED ---
Buzzer --- Internal alarm buzzer ---
Digital Zoom 2X 4X ---
External I/O na na Yes
15
Pioneer of IP Innovation
