Title: Lowry Model


1
Lowry Model
  • Pam Perlich
  • URBPL 5/6020
  • University of Utah

2
Reading / Model
  • Urban Form The Lowry Model of Population
    Distribution
  • Chapter 7 from
  • Modeling the World in a Spreadsheet, Timothy
    Cartwright, John Hopkins University Press, 1993.
  • Ereserve

http//ereserve.lib.utah.edu/ereserve/trms/annual/
URBPL/5020/Perlich/urban.pdf
3
Gravity Models
  • Planners need small area forecasts of population
    and employment
  • Travel models require small area forecasts
  • Transportation networks
  • Distance
  • Travel time
  • Capacity
  • Gravity models specify interactions between
    origins and destinations

4
Gravity Model Basics
  • Given a set of origins, destinations, and travel
    times, trips to destinations are
  • Directly related to the size of the destinations
    (gravitational pull)
  • Inversely related to travel time
  • Gravity models are used to
  • Analyze commuting and other travel patterns
  • Determine optimal location for facilities and
    services
  • Allocate regional projections to specific
    locations within the region

5
Lowry Model
  • 1960s Ira Lowry
  • Spatial interaction model
  • Modeling innovations
  • Sub-regional forecasts were generated to control
    to regional totals
  • Employment, population, and transportation were
    combined in one model
  • Many variations and extension have been
    subsequently developed

6
Sectors in Lowry Model
  • Basic or Export Sector
  • Sell their goods and services to non-locals
  • Exogenous (Determined outside the model)
  • Non-basic or Residentiary or Retail Sector
  • Sell their goods and services to locals
  • Includes government schools, etc.
  • Endogenous (Determined by the model)
  • Household Sector
  • Size and residential location are endogenously
    determined

7
Specification of the Model
  • Basic is given (exogenous)
  • Forecast is derived from regional projections
  • Retail sector
  • Size and location are determined by size and
    location of the population
  • Household sector
  • Size is determined by employment opportunities
    (including basic and nonbasic)
  • Location is determined by accessibility,
    particularly to employment

8
Model Logic
Size of Population
Demand for Labor
Basic Sector
Distribution of basic jobs across zones is
given Travel time (network) is given Model
generates population and non-basic employment by
zone
Demand for Non-Basic
9
Model Inputs
  • Basic jobs by zone
  • Transportation network travel times between
    every pair of zones (generalized cost matrix)
  • Ratio of population to workers
  • Ratio of service (non-basic) workers to
    population
  • Friction factor (willingness to travel)
  • Location probability matrix
  • Provides the basis of residential location
    decisions based on employment locations and
    travel times

10
Computation Sequence
  1. Basic job locations by zone (assumed)
  2. Location probability matrix ? residential zones
    of basic workers
  3. workers per zone ? population x zone
  4. Population x zone ? number of service jobs x zone
  5. Location probability matrix ? residential zones
    of service sector workers

11
Lowry Model Structure
Basic Employment by Zone - Exogenous
Residential Location of Basic Employees
Population Associated with Non-Basic Employees
Residential Location of Non-Basic Employees
Converge to Solution
Population Associated with Non-Basic Employees
Service Workers (Non-Basic) by Zone
Residential Location of Non-Basic Employees
Service Workers (Non-Basic) by Zone
Population Associated with Basic Employees
12
Technical Notes W
  • Willingness to travel W
  • Travel time 2
  • F friction factor
  • F 0 ? all sectors equally attractive regardless
    of travel time
  • Increase F ? shorter travel times become very
    attractive

13
Technical Notes Probabilities
  • Convert travel times to an index
  • Divide each component travel time in a zone by
    the total for the zone
  • These become probabilities
  • Location probability matrix

14
Inputs Changes to Analyze
  • Basic Jobs
  • Service worker Population
  • Worker Population
  • Friction Factor
  • Travel times

15
Model Operation
  • Cartwright Chapter 7
  • Same Logic
  • Initial conditions in Cartwright Baseline
  • Scenario is the first scenario on Project 4
  • Two tabs
  • Inputs Model input cells are shaded yellow
  • Outputs
  • Basic assumptions as well as outputs
  • Compares scenarios to baseline

16
Model Operation
Model Operation Tab 1 Model and Inputs
17
Model Operation
Model Operation Tab 1 Model and Inputs
  • Inputs (shaded yellow)
  • Scenario Name
  • Scenario Description
  • Friction Factor
  • Population / Worker Multiplier
  • Service Worker Population Ratio
  • By Zone
  • Generalized Travel Costs / Time
  • Number of Basic Jobs

18
Output Page 1
19
Output Page 2
  • Note the comparisons to the baseline case.
    Scenario results minus baseline results impact
    results. These three tables have conditional
    formatting as follows
  • Green ? scenario gt baseline
  • Orange ? scenario lt baseline
  • No shading ? scenario baseline
