Quantitative Microscopy and Micro-CT

• by
• Kimerly A. Powell, Ph.D.

2
Quantitative microscopy
3
Objective
To determine the quantitative morphometrics
(i.e., number, size, orientation) of biological
structures (i.e., cells, cell nuclei, collagen
fibers) in an automated unbiased fashion.
4
Feature Analysis Rat Tendon Collagen Fibrils
Number fibrils 247 Mean (s.d.) Area 16701.32
(791.6) nm Range Area 857.7 - 48203.3 nm Mean
(s.d.) Diameter 134.2 (57.0) nm Range Diameter
33.0 - 247.7 nm
5
Mouse Alveolar Septae Width
MAT overlayed EDM
Histogram
EDM image
mean half-width 8.3 (0.03) pixels mean width
11.5 microns
6
Mouse Bone Stem Cells Colony Proliferation
7
Mouse Bone Stem Cells
8
Introduction - Micro-CT Imaging
Micro-CT is a high resolution version of X-ray
tomographic imaging (resolution 10 - 100
microns). It has primarily been used to image ex
vivo bone core specimens. And more recently been
used to image various bone structures in vivo in
small animal models.
9
Introduction Micro-CT Imaging

• increased scanning speed
• more efficient use of x-rays
• reduced dose

Cone-Beam Micro-CT
10
CCF Micro-CT Imaging System

• 4 micron spot size X-ray
• 10-225 kV, 0.01 - 0.3 mA
• 3-field II (5, 7, 9 inch FOV)
• 2k x 2k 12-bit CCD camera
• 7 - axis positioning system

11
Micro-CT Imaging Applications

• Bone trabecular morphometry
• iliac crest, calcaneous, femoral head
• Tissue engineering
• Bone density and location of new bone formation
  in HA and PCL bone tissue scaffolds
• In-vivo small animal imaging
• Longitudinal evaluation of callus and bone
  volume in in vivo bone fracture/healing model
• Mouse Phenotyping
• Morphometric analysis of skeletal structure in
  metalloprotease knockout mice

12
Small Animal Imaging
13
Fracture Model - Image Acquisition
resolution 100 mm
Projection radiograph
Hind limbs secured in micro-CT system
14
Fracture Model 3D Reconstructions
Right leg
Left leg
15
Fracture Model Spatial Registration

• Segment bone global threshold
• Find outer outlines
• ICP registration
• reference prinicpal axis week 0

ROI
Red week 0 Yellow week 5
16
Fracture Model - Morphometrics
17
Fracture Model - Morphometrics
18
Fracture Model - Results
19
Fracture Model - Results
20
Trabecular Architecture In vivo imaging
Trabecular morphometry Treatment therapies - PtH
Proximal tibia rat
21
Mouse Phenotyping
22
Mouse Phenotyping
E18.5 WT mouse
23
Application Embryonic Development
E18.5 in ethanol
Alizarin red/Alcian Blue
after staining
24
Application Embryonic Development
25
Application Embryonic Development
26
Soft Tissue Micro-CT Imaging Rat Embryo (E18)
cut plane
heart
liver
intestines
Side view
Front view
27
Ex vivo Micro-CT Imaging of Mouse Skulls
2 week old Wild Type
2 week old MMP-14 KO
28
Application Skull Morphometry
29
Application Skull Morphometry

• Procrustes Analysis
• 3D Landmark Data
• Separates Size from Shape

3D reconstruction rat skull
30
Application Skull Morphometry
M
I
S
31
Application Vertebral Morphometry

• Segment bone
• Label separate objects
• Separate touching objects
• Make linear and volumetric
• measurements on separated
• objects

S1
S2
S3
Sacral spine of 2-week old WT mouse
32
Application Vertebral Morphometry
S2
S2
Spinous process
verterbal foramen
articular process
transverse process
2 week old MMP-14 KO
2 week old Wild Type
33
Application Vertebral Morphometry S2
34
Application Tibia Morphometry
growth plate
trabeculae
Internal micro-architecture of 2 week old mouse
tibia resolution 15 microns
35
Application Skeletal Atlas

• Automatically label individual bones in skeleton
• Standardize measurements for individual bones

36
Application Mouse Histology
37
Acknowledgements
Collaborators Suneel Apte, MBBS D. Phil. Ron
Midura, Ph.D. George Muschler, M.D. Don Stredney
(OSC)
Barry Kuban, B.S. Larry Latson, M.S. Craig
Bennetts B.S. BME Prototype Lab Jason Bryan (OSC)
NIH DOD
