Transactions with replicated data EEE465 2001 Reference: CDK00 14'5

1
Transactions with replicated data EEE465
2001Reference CDK00 14.5

• Major Greg Phillips
• Royal Military College of Canada
• Electrical and Computer Engineering
• greg.phillips_at_rmc.ca
• 1-613-541-6000 ext. 6190

2
Transaction with replicated data

• a transaction on replicated objects should appear
  the same as one with only non-replicated objects
  (one-copy serializability)
• each replica manager (RM) provides concurrency
  control and recovery of its own objects.
• here, assume normal two-phase locking is used for
  concurrency control
• when RM recovers from failure, it uses info from
  other RMs to restore its objects to their current
  values
• last transaction from own log, other transactions
  from other RMs

3
Architecture

• different schemes to address different needs
• can a client request be addressed to any of the
  RM or just a particular RM?
• how many RM are required for the successful
  completion of an operation?
• can contacted RM defer the forwarding of requests
  until a transaction is committed?
• two-phase commit protocol
• each transaction is a two-level nested 2PC
• coordinator communicates with participants
• if participant is replica, must communicate with
  other replicas
• participant votes No if any replica unable to
  commit

4
Replication Management Schemes

• primary copy
• all reads and writes from a single copy, updates
  others
• read-one/write-all
• simple, reads from any replica, writes to all
  replicas
• not fault tolerant
• available copies with validation
• works through network partition
• when partitions reconnected, inconsistencies
  detected and repaired
• quorum consensus
• operations only carried out in larger partition
• on reconnection, smaller partition brought up to
  date
• virtual partition
• combination of available copies and quorum
  consensus

5
Primary copy replication

• all requests directed to distinguished primary
  copy
• primary copy performs local concurrency control,
  updates replicas
• useful for fault tolerance, availability on
  primary copy failure we appoint a new primary
  from the backups
• no help with performance over single server
• approaches
• eager updates backups first, then responds to
  client
• replicas always consistent
• lazy responds to client first, then updates
  backups
• faster performance at the cost of possible
  inconsistency (visible on primary failure)
• one-copy serializable (why?)

6
Read-one/write-all

• read request may be immediately handled by any
  replica
• write request requires concurrence of all
  replicas
• doesnt handle network partition
• one-copy serializable
• transaction can succeed if there are no read or
  write lock confilicts
• if there is a write/write conflict it will be
  detected as there will be conflicting write locks
  at all replicas
• if there is a read/write conflict it will be
  detected as there will be conflicting read and
  write locks at one replica

7
Available copies

• extends read-one/write-all to account for failure
• read request performed by any active replica
• write request requires all available replicas
• when a replica manager fails it is replaced by a
  recovered copy
• with no failures, equivalent to
  read-one/write-all, therefore one-copy
  serializable
• in failure case, requires additional mechanism

8
Available copies failure example
getBalance(A) deposit(B,3)
T
U
getBalance(B) deposit(A,3)
B
M
A
A
B
B
Y
X
N
P
Replica group
Replica group
Consider if X fails just after T has performed
getBalance(A) and N fails just after U has
performed getBalance(B), but neither transaction
has performed its deposit. Which replicas perform
Ts deposit? Which replicas perform Us
deposit? Do the transactions succeed or fail? Is
there an inconsistency?
9
Local validation

• local validation is added to available copies to
  prevent inconsistencies from RM failure
• rule no failure or recovery event can appear to
  happen during a transaction
• before a transaction commits it checks for
  failures and recoveries of replica managers of
  any object it has accessed
• in our example T detects Ns failure when it
  writes to B
• on commit, check that N is still failed and X, P,
  and M are still available if true, can commit
• this imposes a causal order on commits
• algorithm will fail for network partitions
  (working replica managers unable to communicate)

10
Quorum consensus

• designed to reduce the number of RMs that must
  perform update operations, but at the expense of
  increasing the number of RMs required to perform
  read-only operations
• key idea timestamp each replica, vote on which
  replicas hold current timestamp
• to read, require contact with R replica managers
• to write, require contact with W replica managers
• set W gt one half total RMs
• set RW gt total RMs
• ensures any pair of read quorums and write
  quorums will contain some common copies and at
  least one will be the most up-to-date
• using read and write locks, can ensure one-copy
  serializability

11
Virtual Partition

• a combination of available copies and quorum
  consensus
• quorum consensus works correctly in the presence
  of partitions
• available copies more efficient for read
  operations
• key idea if a virtual partition (set of
  communicating RMs) has enough votes to make a
  quorum, use available copies algorithm for reads
• if a RM fails and the partition changes during
  the transaction, abort
• ensures all transactions that complete see the
  failures and recoveries of RMs in the same order
• managing virtual partitions is complex

12
Next ClassName Services
