Title: Modern Instrumentation Final Project AM/FM Radio


1
Modern Instrumentation Final Project AM/FM
Radio
  • Zhou Brian

2
AM Signal Processing
  • Amplitude modulation (AM) is a technique used in
    electronic communication, most commonly for
    transmitting information via a radio carrier wave

3
AM Modulation
  • Include the original information of signal to a
    carrier wave
  • Carrier wave
  • first order component of signal
  • AM signal

4
Frequency range 500Khz-1.6MhZ
5
AM Demodulation
  • Extract the message from the AM wave
    Rectification
  • Ideal diode and capacitor to rectify AM signal
    and to extract the envelop wave
  • Capacitor here is for discharging process and it
    has to be relatively large in order to discharge
    very slowly
  • Half wave rectification/Full wave
    rectification(use diode bridge to utilize both
    sides of the AC signal)

6
Circuits
7
Explanation
  • BJT needs a low voltage power supply which is
    around 1.5 v(voltage across 2 diodes)
  • Signal out of diode is the envelop but with a
    small amplitude(50 mv, not enough fan-out to
    drive next stage)
  • According to chip datasheet , connect control
    capacitance to get a larger gain

8
(No Transcript)
9
Experimental Results
10
Frequency Modulation (FM)
  • Whats it all about?

11
How does FM carry information?
  • FM, as its name suggests, varies the frequency
    around a carrier wave
  • i.e. a carrier wave is what you tune into on your
    radio at its carrier frequency
  • The signal is put into the carrier wave during
    transmission (broadcasting)
  • Carrier wave frequency range is between 80-110MHz
    (VHF)

12
Some FUN!
Xm is the signal
This is the carrier wave.
TRANSFORM!!!
fD is the deviation from the carrier
wave frequency (fc)
13
What FM Looks Like
14
How do you pull the signal out?
  • One way is to use a Foster-Seeley discriminator
  • This converts your FM signal into AM
  • Part of a process called slope detection which
    converts amplitude changes to sound
  • HOWEVER, pulling a signal out this way does not
    reduce noise (compared to the AM receiver)

15
Super Regenerative Detector
  • In this type of FM detection, there are two types
    of oscillations at work through a regenerative
    amplifier
  • The primary oscillation is the carrier frequency
    (resonance) fed into the amplifier, and the
    secondary oscillation is for pulling out the
    signal
  • The secondary is operated at ultrasound levels to
    avoid audio interference
  • This is not possible for AM due to the secondary
    lying in the audio range

16
FM Radio SchematicSuperRegenerative
17
Summary
  • AM signal is easier to demodulate (extract the
    message), but it needs more power when
    transmitting the signal and noise is manifest in
    the signal compared to FM.
  • FM has better quality of sound ,noise immunity,
    and consumes little power in signal transmission,
    however the demodulation part is harder, we need
    convert the very high frequency into sound which
    is in a low frequency range. So in order to do
    that, we have to use multiple stages of
    amplifier frequency converter(mixer)

18
The Future!
  • Continue working on FM receiver
  • Implement full wave rectification (bridge) for AM
    receiver and compare quality of signal
  • Work on transmitting signals (walkie-talkie)
  • Radio Telescope
  • Mission to Mars
