Detector Characteristics

1
Detector Characteristics
2
(No Transcript)
3
Detector Details
4
Vital Statistics

• Overall detector area 6.4 cm by 6.4 cm
• Wafer thickness 400 mm
• Silicon n-type substrate, p-type strips
• Large substrate resistivity 5-8 kW
• Number of strips 320
• Strip pitch 194 mm
• Strip width 50 mm
• AC coupled strip readout

5
Some Considerations in Estimating Energy from TOT

• Detector Energy deposited gt Charge Q in
  detector
• Landau Distribution of deposited energy
• Shot noise
• Preamplifier and Front End Electronics
• Threshold Calibration
• Charge Saturation plateau in TOT vs. Input
  charge response
• Controller and Readout gt TOT
• Estimated charge Q gt Estimated particle energy

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
Leakage Current

• Possible source of detector noise
• Minimized with care. Usually a small noise
  source
• Shot noise. Mainly affects long shaping time.
• Temperature dependence
• Leakage current doubles for each 7C rise in
  detector temperature
• Bias voltage dependence
• Illustrated on following chart

10
I-V Characteristics
HKM Factory Data, Detector 312. Factory Data for
other 3 detectors similar. 25C
SCIPP Data, Apr. 25, 2001 24C
11
Energy Deposition
Comparison of Landau distribution (theoretical
line) with ToT data from GLAST
12
Two MIP Events
Comparison of theoretical and observed energy
deposition for possibility of 2 tracks passing
through the same strip
