Networks and Pathways II

1
Networks and Pathways II

CBW Bioinformatics Workshop February 23th 2006,
Toronto Christopher Hogue The Blueprint
Initiative
2
About this talk

• The Future and Requirements for Cell Simulation
• Systems Biology and Modeling

3
The Old Future
Jules Verne Machines and adventures
4
Artists Concept Adventures in faraway places
and the machines that get us there
Galileo Probe Concept Instrument Design
Reality
5
The New FutureAdventures Inside Cellular Life
Forms
6
David Goodsells painting at the molecular level
Zoom in to the bacterium a simple cell
7
Propellor
Protein Motor
Assembly Line for Proteins
DNA
8
How did this image come about?

• Information integration by the artist
• High level view taken from light microscope
• Filled in with parts drawn to scale
• Parts from Life Science Databases
• Over 25,000 protein structures in PDB database
• Complete E. coli, Human Genome in GenBank
• 12 Million PubMED articles

9
Software, not hardware, does the last
magnification

• The Artist the human brain
• Memory, knowledge, semantics, inference
• Bioinformatics Software
• Ultimately has to be rule based
• Integrate a disparate variety of information
  sources
• Creating a computer simulation of the living
  cellular system

10
RequirementsTowardsCellularSimulation
Whole Cell Visualization
Modular Cell Simulation Software Layer
Data Access Layer
PARTS Molecules SeqHound
InteractionsReactionsKinetics, PTMs
Initial Conditions
Machine Readable Data
Expression, Concentration, Localization/distributi
ons
microscopy
GENBANK PDB
BIND KEGG
The PRINT Literature (PubMed)
Human Readable Data
11
Classification of Simulation Methods

• Deterministic get same results with same input
  (large scale input)
• Stochastic get different results with same
  input (small scale input)
• Spatial movement (diffusion) of entities in
  space accounted for
• Non-spatial assumes homogeneous mixture in
  unlimited volume

12
Modeling Techniques

• Quantum Mechanics
• Molecular Dynamics
• Brownian Dynamics
• Monte Carlo Molecular
• Cellular Automata
• Petri Networks
• Partial Differential Equations
• Stochastic Differential Equations
• Ordinary Differential Equations
• Flux and Energy Balance
• Boolean Networks
• Static Models

Increasing scope and efficiency Decreasing
resolution and complexity
13
Static Model

• Static implies no analysis of temporal effects
• An example of how protein interaction networks
  recapitulate cellular structure
• Nucleolar network derived from core analysis of
  high-throughput yeast interactions

• F Fibrillar Center
• transcription of rDNA into rRNA
• D Dense Fibrillar Center
• finishing of rRNA with various enzymes snoRNP
• migrates to cytoplasm during chromatin
  condensation in cell cycle
• G Granular Component
• Ribosome assembly
• Stays in the nucleus

14
9-core from 15,000 yeast interactions
Dense Fibrillar Center
Fibrillar Center
Granular Component
Surprisingly, a simple dense interconnected
network of F, D, and G proteins recapitulates the
Nucleolar image, ignoring spatial and temporal
information
15
Flux Balance Analysis

• Simulates Flux or Flow thorugh Metabolic Pathways
• Kinetics of each step not required
• Predicts effects of gene knockouts

B. Palsson UCSD Engineering
16
Ordinary Differential Equations - Nonlinear ODE

• Assumes a homogeneous solution with unlimited
  volume
• v1
• 2x ? y
• dx/dt -2v1
• dy/dt v1

17
A simple ODE model of yeast glycolysis
18
ODE Based Systems

• Gepasi (Mendes, 1997 Mendes Kell, 2001)

http//dbk.ch.umist.ac.uk/softw/gepasi.html

• SBML http//www.sbml.org
• A data exchange format for network models
• JWS Online http//jjj.biochem.sun.ac.za/

19
(No Transcript)
20
(No Transcript)
21
JWS online
http//jjj.biochem.sun.ac.za/
22
JWS OnlineDatabase of ODE based Models
23
(No Transcript)
24
Oscillation a common behavior
25
Control Theory Fourier Transform of Oscillatory
Data
Can we reduce the ODE model even further to
Amplitude and Frequency?
Biophys J, January 2002, p. 99-108, Vol. 82, No.
1 Control Analysis for Autonomously Oscillating
Biochemical Networks Karin A. Reijenga, Hans V.
Westerhoff, Boris N. Kholodenko,   and Jacky L.
Snoep
26
Some Problems with DE approaches

• Almost all simulation systems are ultimately
  based on solving either ordinary differential
  equations (ODEs), partial differential equations
  (PDEs) or stochastic differential equations
  (SDEs)
• Differential equations are hard to work with
  when simulating
• spatial phenomena,
• discrete events (binding, switching)
• non continuous variables (low copy number)
• when key parameters are unknown or unknowable

27
More Problems

• DEs are notorious for instabilities or situations
  where small rounding errors lead to singularities
  or chaotic behavior
• DE methods are not conducive to visualization or
  interactive movies
• DE methods require considerable mathematical
  skill and understanding (not common among
  biologists)
• DE methods dont easily capture stochasticity or
  noise (common in biology)
• Issue of realism cells dont do calculus

28
Do we need the calculus?

• Sidney Brenner calls it biological arithmetic
  not calculus
• Needs to accommodate the discrete (binding,
  signaling) and continuous (substrate
  concentration) nature of many cellular phenomena
• Approaches which avoid DEs
• Petri Nets (stochastic and hybrid)
• Cellular Automata
• Monte Carlo simulations

29
Petri Nets from network control analysis
30
Petri Nets

• A directed, bipartite graph in which nodes are
  either "places" (circles) or "transitions"
  (rectangles)
• A Petri net is marked by placing "tokens" on
  linked or connected places
• When all the places have a token, the transition
  "fires", removing a token from each input place
  and adding a token to each place pointed to by
  the transition (its output places)
• Petri nets are used to model concurrent systems,
  particularly network protocols w/o differential
  eqs.
• Hybrid petri nets allow modeling of continuous
  and discrete phenomena

31
Hybrid Petri Nets Phage Assembly
Matsuno H, Tanaka Y, Aoshima H, Doi A, Matsui M,
Miyano S. Biopathways representation and
simulation on hybrid functional Petri net.In
Silico Biol. 20033(3)389-404.
Predicted protein expression
l phage control circuit
32
Petri Nets - Limitations

• Not designed to handle spatial events or spatial
  processes easily
• Stochasticity is imposed, it does not arise
  from underlying rules or interactions
• Does not reproduce physical events (brownian
  motion, collisions, transport, binding, etc.)
  that might be seen in a cell Petri Nets are
  more like a plumbing and valving control system

33
Cellular Automata

• Computer modeling method that uses lattices and
  discrete state rules to model time dependent
  processes a way to animate things
• No differential equations to solve, easy to
  calculate, more phenomenological
• Simple unit behavior -gt complex group behavior
• Used to model fluid flow, percolation, reaction
  diffusion, traffic flow, pheromone tracking,
  predator-prey models, ecology, social nets
• Scales from 10-12 to 1012

34
CA Methods in Games
SimCity 2000
The SIMS
35
Cellular Automata
Can be extended to 3D lattice
36
Dynamic Cellular Automata

• A novel method to apply Brownian motion to
  objects in the Cellular Automata lattice (mimics
  collisions)
• Brownian motion is scale-free in heterogeneous
  mixtures
• Allows simulations to span many orders of time
  (nanosec to hours) and space (nanometers to
  meters)

37
SimCell http//wishart.biology.ualberta.ca/SimCel
l/
38
SimCell

• CA or Agent-based simulation system
• Designed to permit easy set-up (4-step set-up
  Wizard)
• Allows for general dynamic, stochastic modeling
  of almost all cellular processes (enzyme
  kinetics, diffusion, metabolism, operon activity)
• Allows real time monitoring (graphing) and
  animation of the system

39
SimCell Interactions

• User defines interaction rules between molecular
  objects using a simple GUI according to
  biological observations and measurements
• Interaction rules framed internally as logical
  boolean operations (if-then-else and do
  while) that respect boundaries and cellular
  barriers

40
SimCell Interactions

• Five different types of objects allowed in
  SimCell
• small molecules
• soluble proteins
• membrane proteins
• DNA molecules
• membranes
• Interactions reduced to relatively small number
  of possibilities
• Touch and Go (TG)
• Bind and Stick (BS)
• Transport (TRA)

41
Touch Go
No interaction
Interaction/catalysis
42
Bind Stick
Preserve ID
Interaction/catalysis
43
Transport
1-way in 1-way out
both ways
44
SimCell Molecules and Interaction Rules
45
Enzyme-Substrate Progress Curves CA is more
realistic - sensitive to number of molecules
Lactate Lo (1 e-kt)
Lactate Lo (1 e-kt)
pyruvate NADH ? lactate NAD
46
Drawing Interaction Rules with SimCell
47
The TCA Cycle SimCell
Acetate
Acetyl-CoA
Glycerol
Pyruvate
Oxaloacetate
Citrate
Isocitrate
L-Malate
?-Ketoglutarate
Fumarate
2
1
Succinate dehydrogenase
Succinate
Succinyl-CoA
48
Metabolic Profiling with NMR
49
Succinate Production
Observed Predicted (SimCell)
50
Glycerol Consumption
Observed Predicted (SimCell)
51
Repressilator
Nature, 403 335-338 (2000)
52
Repressilator
53
Repressilator ODE predicted behavior
54
Repressilator observed in growing culturecells
blinking
55
SimCell Repressilator Oscillations
56
SimCell vs. ODE
57
Monte Carlo Simulation Method

• Monte Carlo Simulation Method random binding
  and displacement of molecules based on given rate
  and diffusion constants
• Attempt to model instances of molecules, their
  physics, motion and binding
• More detailed than CA approach, but similar

58
Modeling receptor motion on a cell surface

• Assuming the cell is a sphere
• The surface area of the cell is vast compared to
  those of molecules
• Local interactions between molecules on the cell
  surface can be considered to be planar
• Spherical 3D surface can be mapped on to a 2D
  planar surface by uniform area mapping

59
Example EGFR

• A 3D structure is transformed and viewed at the
  axis perpendicular to the cell membrane
• Binding sites are determined from the positions
  of alpha carbons of the two farthest residues
  that constitute the site
• Radius of the molecule is the average distance
  from the center of mass to the surface binding
  sites (circle enclosed by blue circle)

60
Representation of a protein

• Each molecule is represented as a solid circle
  with a radius on a planar grid.
• The area of the circle is used for collision
  detection.
• The radius is the approximate distance from the
  center of mass to the edge of the molecule
  (determined by the average positions of all
  surface binding sites)
• Binding sites are represented as arcs on the
  circle, with the arc lengths representing the
  sizes of the binding sites
• The distance of the binding sites to the center
  of mass must be at least that of the radius
  (surface) but can be greater (distal)

61
Collision and Diffusion

• Rotational diffusion is random (fast in this time
  scale)
• Unidirectional displacement of molecules follows
  a Gaussian-like distribution
• Time step decided by the maximum possible
  displacement traveled by a molecule that is less
  than the diameter of the smallest molecule.
• This is to ensure that molecules dont skip
  over each other.

62
Modeling motion on a Membrane2D Probabilistic
model of Molecular MotionHow far does a molecule
travel? Sample a move distance using
probability density function.
Sampling over 30 intervals of displacement
?0Inf f(s)ds 1
Derived from Ficks Second Law for 2 Dimensions
63
Binding

• Two types of binding reactions
• 1. Diffusion limited kgtgt D
• 2. Not diffusion limited Dgtgtk
• Binding is said to occur based on the following
  criteria
• Two interaction sites are compatible
• The sites are within line of sight of each
  other and within interaction distance
• The probabilistic threshold of binding (dependent
  on the kinetics of the binding sites) is met
• More detailed than CA approach but requires
  microscopic binding parameters.

64
Modeling Techniques - Redux

• Quantum Mechanics
• Molecular Dynamics
• Brownian Dynamics
• Monte Carlo Molecular
• Cellular Automata
• Petri Networks
• Partial Differential Equations
• Stochastic Differential Equations
• Ordinary Differential Equations
• Flux and Energy Balance
• Boolean Networks
• Static Models

Decreasing scope and efficiency Increasing
resolution and complexity
65
How to Choose a Modeling Method?

• With unlimited time and computation resources
  choose the modeling method of the lowest level
  (i.e. Quantum Mechanics)
• It may account for largest amount of data
• Its solutions may converge to higher level
  solutions if the extra detail is not needed
• It does not scale
• Occams Razor the simplest explanation is the
  one to choose!
• Choose the highest level-of-detail method that
  can satisfactorily depict the given phenomenon.
• Biology and evolution do not always take the
  simple route.
• Sensitivity Analysis is the answer you get from
  modeling robust to different parameter values
  taking into account possible error or differences
  in biochemical measurements?

66
Cyber Cell DBhttp//redpoll.pharmacy.ualberta.ca/
CCDB/
A unique compilation of parameters required for
modeling an entire E. coli cell. Useful
resource for systems biology.
