Title: Shark Team


1
Shark Team
Jenny Hodbod Jason Owens Aaron Sidder
2
The Question
  • Is there a correlation between hurricane strength
    (intensity) and frequency vs. time?

http//www.katrina-hurricane.biz/images/katrina-hu
3
Methods
  • Analyze the total number of storms per decade
  • Analyze the average maximum wind speed per year
    by decade and the maximum wind speed per decade
  • Analyze the number of Category 4 5 hurricanes
    per decade

4
Chi Squared Tests
  • Fo observed data? hurricane data smoothed into
    decadal averages
  • Fe expected data? average for the whole data set
  • (fo-fe)2/fe
  • Sum of the chi squared values
  • Compare to the critical chi squared values

5
Biases and Data Limitations
  • Advances in technology from 1850 (pre-Civil War)
    to 2006
  • Limited time frame, no knowledge of historical
    storm data beyond 1850
  • 2005 was a crazy year that skewed the data

6
Expected and Observed Hurricane Frequencies
7
Chi Squared test Frequency
  • Null Hypothesis the total number of events is
    not increasing per decade
  • Used the average for the entire data set fe 85
    events per decade
  • 16 df critical chi squared value at 5 is 26.30
  • Chi squared total is 53.02
  • Reject null hypothesis

8
Chi Squared Frequency cont.
fo fe fo-fe fo-fe2 fo-fe2/fe
1851-1860 60 85 -25 625 7.35
1861-1870 74 85 -11 121 1.42
1871-1880 75 85 -10 100 1.18
1881-1890 82 85 -3 9 0.11
1891-1900 84 85 -1 1 0.01
1901-1910 79 85 -6 36 0.42
1911-1920 54 85 -31 961 11.31
1921-1930 56 85 -29 841 9.89
1931-1940 104 85 19 361 4.25
1941-1950 98 85 13 169 1.99
1951-1960 98 85 13 169 1.99
1961-1970 98 85 13 169 1.99
1971-1980 98 85 13 169 1.99
1981-1990 95 85 10 100 1.18
1991-2000 109 85 24 576 6.78
2001-2006 95 85 10 100 1.18
53.02
9
Event Category as a of Total
Biggest increases are in TS, 4 5 Tropical storms
increase (y1.9985x 17.2) Category 1 events show
a slight increase (y 0.3029 16.55) Category 2
events show a decrease (y -0.775x
20.65) Category 3 events show a slight increase
(y 0.1191x 9.425) Category 4 events show an
increase (y0.6162x 0.575) Category 5 events
show an increase (y 0.3456x-1.125)
10
Category 45 increase
TS and Category 1 are increasing 23 are
decreasing 45 are increasing
11
Frequency of Category 5 Events
12
Category 45 increase
  • Null hypothesis category 4 5 hurricanes are
    not increasing in frequency
  • Fe average number of 45 per decade 8
  • Total chi squared value 56.62
  • More than the critical chi squared value (26.30)
  • Reject the null hypothesis

13
Maximum Wind Speeds
14
Chi Squared Wind Speed
  • Average the maximum wind speed per year by decade
  • Average of these 16 speeds 115 mph (fe)
  • Null hypothesis no increase in wind speed over
    time
  • Sum of the chi squared values 20.02
  • Below the critical chi squared value for 16df
    (26.30), therefore accept the null hypothesis

15
Chi Squared Wind Speed cont
  • Using the maximum wind speed per decade
  • Average 142.5 fe
  • Sum of chi squared values 29.47
  • Reject the null hypothesis at the 5 probability
    level

16
Number of Storms Through Time
17
(No Transcript)
18
Who is this?!
19
Trying to Summon Nikola Tesla?
20
Number of Storms Through Time
21
Troughs and Spikes can clearly be seen
22
Cycles drive our dynamic Planet
23
Conclusion
Increase in frequency through time?
YES Increase in severity through time?
YES Manifestation of anthropogenic Climate
change? ???
24
Manatees and Hurricanes
Source WEST INDIAN MANATEE (Trichechus manatus
latirostris) FLORIDA STOCK U.S. Fish and
Wildlife Service, Jacksonville, Florida
September 2000
25
Average of storms by decade as compared to Sea
Surface Temp.
26
Average of storms by decade as compared to Sea
Surface Temp.
  • Two-way chi squared test
  • SST anomaly and Average of storms/yr by decade
  • Null Hypothesis no relationship between the two
  • Total chi squared value 29.99
  • Reject the null hypothesis
