Introduction to Marine Habitats

1
Introduction to Marine Habitats
FISH 420/520 Spring 09
2
Terrestrial Biomes
Grassland
Tundra
Desert
Forest
3
What are the marine biomes?

How might they be defined?
4
Towards a Classification of Marine Biomes

• Yentsch and Garside
• Asked whether patterns of pelagic biogeography
  were a response to patterns of primary production
• In other words, biomes can be established by
  similarities in physical forcing of algal growth
• Alan Longhurst took this idea and formulated 4
  pelagic ocean biomes

5
What limits Algal Production? (1) Light
Consider a vertically mixed ocean
Light
compensation depth Photosynthesis Respiration
Depth
6
What Limits Primary Productivity? (2) Nutrients
Stratified Ocean Condition
Temp
Depth
7
Areas of high production must have the following

• Restricted vertical displacement of primary
  producers
• External nutrient source or highly efficient
  nutrient cycling

8
Two primary ways this happens
Upwelling Tidal Fronts / Mixing
9
Upwelling 101
Ekman Transport
Coastal Upwelling
10
Principal Surface Currents
11
Sea Surface Temperature
These four areas, which account for only 1 of
surface area, account for 20 of fishery landings
12
The coldest winter I ever saw was the summer I
spent in San Francisco Mark Twain
13
Depth of the mixed layer is crucial
Cool Water / Anchovy Regime
Warm Water / Sardine Regime
Strong Trade Winds
Weak Trade Winds
Longitude
Longitude
14
Upwelling systems tend to be on western edge of
continents
15
Tidal Mixing on Continental Shelves
70 of fisheries production occurs on
non-upwelling, continental shelf systems
16
Georges Banks and Tidal Mixing
17
Tidal Fronts and Mixing on Continental Shelf and
Seamounts
Warm, low-nutrient water
15
Well Mixed
10
8
Cold, high-nutrient water
18
Tidal Fronts and Mixing on Continental Shelf and
Seamounts
265 mg C m-2 h-1
210 mg C m-2 h-1
160 mg C m-2 h-1
Warm, low-nutrient water
15
10
Tidal Flow
8
Well-Mixed
Cold, high-nutrient water
19
What are the biomes then?

• Longhurst proposed the following
• Trades Biome
• mixed layer depth forced by large scale wind
  forcing
• Westerlies Biome
• mixed layer depth forced by local winds and
  irradiance
• Polar Biome
• mixed layer constrained by surface brackish water
• Coastal
• mixed layer forced by diverse coastal processes

20
Principal Surface Currents
Polar Biome
Westerlies Biome
Trades Biome
Westerlies Biome
Polar Biome
21
The coastal biome is extremely diverse
Continental shelf Estuaries Coral Reefs
22
Other components of Estuaries

• Salt Marshes
• Sea grasses
• Mangroves

23
Classic Estuarine Circulation
Animation from www.chemgapedia.de
24
What about coral reefs?

• Among the most productive marine habitats
• Yet, exist in regions that are generally nutrient
  poor
• Indo-Pacific
• Caribbean
• Two reasons for this
• Shallow
• Extremely efficient nutrient cycling

25
Productivity and Predictability of Marine Habitats
Coral Reefs
Estuaries
Continental Shelf
Coastal Upwelling
Predictability
Open Ocean
100
1000
300
Productivity (g C m-2 y-2)
