Title: Drilled Shaft Extraction


1
Drilled Shaft Extraction
  • Sign Shaft 8 Right
  • I-4 Widening Volusia County
  • FPN 408463-1-52-01

Kathy Gray, P.E. Florida Department of
Transportation (D-5) Mohamad Hussein, P.E. GRL
Engineers, Inc. Christopher Lewis, P.E. FG
Engineering, LLC
2
Agenda
  • Introduction/Background Kathy Gray
  • Cross Hole Sonic Logging (CSL) Mohamad Hussein
    (GRL)
  • Pile Integrity Test (PIT) Chris Lewis (FGE)
  • Shaft Extraction Kathy Gray

3
Site Location
4
(No Transcript)
5
(No Transcript)
6
Drilled Shaft Log
7
Cross Hole Sonic Logging (CSL) Mohamad Hussein,
P.E. GRL Engineers, Inc.
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
Pull Probes From Bottom To Top
Place probes in bottom of tubes.
Stress Waves, emitted in one tube are received in
another one if concrete quality is satisfactory
Receive
Transmit
13
Traditional analysis
14
How to find defects?
Good
Defect
  • Delayed First Arrival Time (FAT)
  • Reduced signal strength (lower energy)

15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
Access Tube Measurements
19
(No Transcript)
20
(No Transcript)
21
Cross-hole Analyzer - CHA
installing
pulling
operation
22
Shaft with full section defect
23
Can locate approximate location and extent of
each defect
Manual Tomography Simple and Fast Procedure
Select affected signals Manually draw it
24
How much data is needed for Tomography?
If few tubes, then have large path sections
undefined, so should also have interior offset
scans.
If enough tubes, then finding interior defect can
be found easily with interior parallel scans only.
25
(No Transcript)
26
(No Transcript)
27
2D horiz. Slice of a defect
3D body view
2D vert. slice
3D Tomography
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
Pile Integrity Testing (PIT) Christopher Lewis,
P.E. FG Engineering, LLC
34
Low Strain Integrity Testing
  • Common Terms
  • PIT (Pile Integrity Test)
  • SIT (Sonic Integrity Test)
  • Impulse Response
  • Sonic Echo
  • PET (Pile Echo Tester)

35
Basic Concepts
  • Multiple analysis techniques
  • Time domain
  • Frequency domain
  • Two Velocity
  • Profile Analysis (Signal Matching)

36
Time Domain
  • Most Common
  • Data presented as a function of time
  • Pile Dynamics equipment presents data as a
    function of length
  • Uses assumed values of wave speed and/or
    foundation length
  • This allows fast, reliable evaluation of data in
    the field

37
Stress Wave Propagation
  • Impact made at pile top
  • Reflections represent changes in impedance
  • Wave speed ? Material Density
  • Stress waves travel faster in denser material
  • Length ? Wave speed ? Observed Reflections

38
Impedance Changes
  • Foundation material property changes
  • Geometric property changes (cross-sectional area)
  • Soil resistance
  • Cracks
  • Changes in soil strata

39
Testing Considerations
  • Test Limitations
  • Length/Diameter Ratio (typically length no more
    than 30 diameters)
  • Other conditions
  • Soil Profile
  • Construction Procedure
  • Construction Records
  • Serviceability
  • Responsibility !

40
Pile Dynamics Equipment
41
FGE Test Procedure
  • Prepare Shaft/Pile top
  • Level and clean area where accelerometer attaches
    and impacts will be made.
  • 3 to 4 spots around the perimeter and 1 spot just
    off center
  • Set up PIT collector
  • Attach accelerometer
  • Impact Shaft/Pile top with standard 2 pound
    hammer
  • Review and save data
  • Acquire second set of data with another hammer
  • Move to next location
  • Check memory to ensure data is saved

42
Data Analysis
  • Data collected is downloaded to PC for further
    analyses using PIT-W software.
  • This software is used for data management,
    manipulation and presentation

43
Data Management
  • Records can be
  • Deleted
  • Averaged
  • Selected for presentation in report
  • Appended to include comments
  • Arranged/Sorted

44
Data Manipulation
  • Change wave speed and length
  • Magnify and filter collected data
  • Importance of Experience
  • False toe
  • Over magnification of other shaft features
  • Filter out defects

45
Data Presentation
46
Basic Evaluation of Data
  • Decreased Impedance
  • Reflection above neutral or zero axis of graph
    prior to toe reflection
  • Usually indicates potential necking or void
  • Increased Impedance
  • Reflection below zero axis of graph prior to toe
    reflection
  • Usually a result of larger cross-section

47
Subject Shaft
Reported Areas of Decreased Impedance
48
Shaft Extraction Kathy Gray, P.E. Florida
Department of Transportation District 5
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
Upper Anomalies
55
Lower Anomaly
56
(No Transcript)
57
Conclusions
  • Cross Hole Sonic Logging Found Defects
  • Pile Integrity Testing Found Defects
  • Both Methods Have Limitations
  • 2 Methods together may be best approach

58
Questions ?
59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
