Nuclear Physics

1
Nuclear Physics

• Chapter 29

2
Chapter 29 Objectives

• Students will understand the significance of the
  mass number and charge of nuclei
• Students will understand the nature of the strong
  nuclear force
• Students will understand nuclear fission

3
Chapter 29 Objectives

• Students will understand the significance of
  half-life radioactive decay
• Students will understand the relationship between
  mass and energy

4
Modern Physics

• Virtual Concept Map

5
Properties of Nuclei

• Atomic (Z)
• Neutron (N)
• Mass ( A )
• AZX

6
Properties of Nuclei

• Nuclei of all atoms of a particular element must
  contain the same number protons.
• Nucleons
• Isotopes

7
Properties of Nuclei

• Charge and Mass
• Electron me 9.11 X 10-31 kg
• Proton mp 1.6726 X 10-27 kg
• Neutron mn 1.6750 X 10-27 kg
• Unified Mass Unit
• 1 u 1.660540 X 10-27 kg

8
Properties of Nuclei

• Size of Nuclei
• Average radius r0A1/3
• r0 1.2 X 10-15 m
• All nuclei have nearly the same density

9
Properties of Nuclei

• Nuclear Stability
• Nuclear Force ( Strong Force )
• Coulomb Force ( Electro-magnetic )
• When Z 83 the repulsive forces between protons
  cannot be compensated by the addition of more
  neutrons

10
Binding Energy

• The total energy of the nucleus is less than the
  combined energy of the separated nucleons.
• Binding Energy
• Eb (mp mn ) melement) c2
• The total energy required to break up a nucleus
  into its constituent protons and neutrons can be
  calculated from E Dmc2, called nuclear binding
  energy

11
Binding Energy
12
Radioactivity

• Radioactivity

13
Radioactivity

• Decay Constant and Half-Life
• Decay rate lN
• N N0e-lT
• l ln 2
• T1/2

14
Radioactive Decay
15
Radioactive Decay

• Methods of Radioactive Decay
• Periodic Table of Elements

16
Decay Processes

• Decay Rules
• The sum of the mass numbers A must be the same on
  both sides of the equation
• The sum of the atomic numbers Z must be the same
  on both sides of the equation

17
Decay Processes

• Alpha Decay
• Parent nucleus
• Daughter nucleus
• Spontaneous decay

18
Decay Processes

• Beta Decay
• The daughter nucleus has the same of nucleons
  as the parent nucleus, but the atomic is
  changed by 1
• A neutron is transformed into an electron,
  proton, and neutrino.

19
Positron Decay

• Something inside the nucleus of an atom breaks
  down, which causes a proton to become a neutron.
• It emits a positron and a neutrino which go
  zooming off into space.
• The atomic number goes DOWN by one and mass
  number remains unchanged.

20
Electron Capture

• An electron from the closest energy level falls
  into the nucleus, which causes a proton to become
  a neutron.
• A neutrino is emitted from the nucleus.
• Another electron falls into the empty energy
  level and so on causing a cascade of electrons
  falling. One free electron, moving about in
  space, falls into the outermost empty level.
  (Incidently, this cascade of electrons falling
  creates a characteristic cascade of lines, mostly
  (I think) in the X-ray portion of the spectrum.
  This is the fingerprint of electron capture.)
• The atomic number goes DOWN by one and mass
  number remains unchanged.

1)
21
Electron Capture
22
Decay Processes

• Gamma Decay
• Nucleus undergoes decay to achieve a lower energy
  state

23
Natural Radioactivity

• Radioactive Nuclei
• Unstable nuclei found in nature (Natural)
• Nuclei produced in the laboratory (Artificial)
• Decay series

24
Works Cited

• http//dbhs.wvusd.k12.ca.us/webdocs/Radioactivity/
  Writing-Alpha-Beta.html
• http//library.thinkquest.org/17940/texts/radioact
  ivity/radioactivity.html
• http//pearl1.lanl.gov/periodic/default.htm
• http//hyperphysics.phy-astr.gsu.edu/hbase/nuclear
  /halfli2.html

25
Chapter 30

• Nuclear Energy
• and
• Elementary Particles

26
Processes of Nuclear Energy

• Fission
• A nucleus of large mass number splits into two
  smaller nuclei
• Fusion
• Two light nuclei fuse to form a heavier nucleus
• Large amounts of energy are released in either
  case

27
Nuclear Fission

• A heavy nucleus splits into two smaller nuclei
• The total mass of the products is less than the
  original mass of the heavy nucleus
• First observed in 1939 by Otto Hahn and Fritz
  Strassman following basic studies by Fermi
• Lisa Meitner and Otto Frisch soon explained what
  had happened

28
Fission Equation

• Fission of 235U by a slow (low energy) neutron
• 236U is an intermediate, short-lived state
• X and Y are called fission fragments
• Many combinations of X and Y satisfy the
  requirements of conservation of energy and charge

29
Sequence of Events in Fission

• The 235U nucleus captures a thermal (slow-moving)
  neutron
• This capture results in the formation of 236U,
  and the excess energy of this nucleus causes it
  to undergo violent oscillations
• The 236U nucleus becomes highly elongated, and
  the force of repulsion between the protons tends
  to increase the distortion
• The nucleus splits into two fragments, emitting
  several neutrons in the process

30
Sequence of Events in Fission Diagram
31
Energy in a Fission Process

• Binding energy for heavy nuclei is about 7.2 MeV
  per nucleon
• Binding energy for intermediate nuclei is about
  8.2 MeV per nucleon
• Therefore, the fission fragments have less mass
  than the nucleons in the original nuclei
• This decrease in mass per nucleon appears as
  released energy in the fission event

32
Energy, cont

• An estimate of the energy released
• Assume a total of 240 nucleons
• Releases about 1 MeV per nucleon
• 8.2 MeV 7.2 MeV
• Total energy released is about 240 Mev
• This is very large compared to the amount of
  energy released in chemical processes

33
In the first atomic bomb, the energy released was
equivalent to about 30 kilotons of TNT, where a
ton of TNT releases an energy of 4.0 109 J. The
amount of mass converted into energy in this
event is nearest to (a) 1 ?g, (b) 1 mg, (c)
1 g, (d) 1 kg, (e) 20 kilotons
QUICK QUIZ 30.1
34
(c). The total energy released was E (30 103
ton)(4.0 109 J/ton) 1.2 1014 J. The mass
equivalent of this quantity of energy is
QUICK QUIZ 30.1 ANSWER
35
Chain Reaction

• Neutrons are emitted when 235U undergoes fission
• These neutrons are then available to trigger
  fission in other nuclei
• This process is called a chain reaction
• If uncontrolled, a violent explosion can occur
• The principle behind the nuclear bomb, where 1 g
  of U can release energy equal to about 20000 tons
  of TNT

36
Chain Reaction Diagram
