GMR Formation

1
AGITATORS
2
Agitators
3
Agitators

• The range
• High speed agitators VDE 1000
• Low speed agitators VRE 2000 3000

4
Agitators

• High speed agitators VDE 1000
• MARINE propeller (? 80 to 160).
• 2 speeds 750 1 500 RPM.
• Power from 0,18 to 1,5 kW.
• Tank volume from 30 l to 5 m3.
• Material 316L SS or Rilsan coated.

5
Agitators

• High speed agitators VDE 1000 (cont d)
• Applications
• Reagent preparation,
• Neutralisation,
• Sludge suspension,
• Lime preparation...

6
Agitators

• Low speed agitators VRE 2000
• 4 axial plain blades inclined 45
• ? 200 to 800.
• Speed from100 to 137 RPM
• Power from 0,25 to 2,2 kW.
• Tank volume from 30 l to 70 m3.
• Material 316L SS or Steel.

7
Agitators

• Low speed agitators VRE 2000 (cont d)
• Applications
• Reagent preparation,
• Neutralisation,
• Sludge suspension,
• Lime preparation,
• Flash mixing (coagulation)...

8
Agitators

• Low speed agitators VRE 3000
• 3 SABRE blade propellers
• ? 200 to 1 800.
• Speed from 57 to 359 RPM.
• Power from 0,37 to 3 kW.
• Tank volume from 30 to 100 m3.
• Material 316L SS or Steel.

9
Agitators

• Low speed agitators VRE 3000 (cont d)
• Applications
• Reagent preparation,
• Neutralisation,
• Sludge suspension,
• Lime preparation,
• Flash mixing (coagulation)...

10
Agitators
VRE 2000
VDE 1000
VRE 3000
11
DOSING AND MIXING OF FLUIDS
