Project 1640 Palomar Interface

1
Project 1640 Palomar Interface
Sasha Hinkley, June 5, 2008
2
Interface specs

• Four pairs of pucks

• Four permanently
• Mounted at PALAO

• Four permanently
• Mounted on 1640

3
P1640 Handling Cart
Including handle 67
width 28
A-frame length 60
Min cart instrument height 56, max 8 ft.
Scissor jack center To handle edge 39
4
P1640 Handling Cart cont.
Eight M6 screws secure each end of instrument to
rotating plates
5
P1640 Handling Cart cont.
Fine x-y adjustment capabilities
Spring mounted
6
Electronics Rack and Control Setup
7
Crates
79x42x62 IFU coronagraph 35x37x61
Electronics rack Two other small ones.
