VARIABLE SPEED PUMP CONTROLLER

1
VARIABLE SPEED PUMP CONTROLLER
MPCSV
Techsys Corporation
2
FUNCTION

• The MPCSV will control up to 3 pumps to maintain
  a
• Uses a stand alone Variable Speed Drive frequency
  Inverter for Speed Control

CONSTANT PRESSURE
3
APPLICATIONS
Irrigation
Air-conditioning
Mechanical Services
Sewerage pumping
SIMPLE VERSATILE
4
OPERATION
Main design function Hold the SET POINT
5
TYPICAL OPERATION
PUMP SPEED INDICATOR Hz
10
20
30
40
50
10
20
30
40
50
10
20
30
40
42
SET POINT
ON/OFF
SYSTEM PRESSURE GAUGE

• EACH PUMP IS STARTED
• ON THE VFD

6
TYPICAL OPERATION
PUMP SPEED INDICATOR Hz
50
42
40
30
20
10
40
30
20
10
50
40
30
20
10
SET POINT
ON/OFF
SYSTEM PRESSURE GAUGE
PUMPS PICKED UP ON THE FLY ON THE WAY DOWN
7
OPERATION
VFD rotates from one pump to the next
8
OPERATION
The change over from VFD to DOL visa versa
is PHASE SYNCHRONIZED Change over time 40msec
No pressure spike on change over either UP or
Down
9
CONTROL FEATURES

• Up to 3 pumps
• Independent control
• Full system status via LED indicators and real
  text LCD
• Easy setup menu screens
• In-built system protection
• 8 Programmable Inputs
• 4 Programmable Outputs
• Set point control to 2
• Smart protection restart
• Flow calculation
• Pressure trip relays

10
SELF CONTAINED

• Comes complete in a IP54 enclosure
• All switchgear included
• VFD included
• Full fan forced cooling thermostat controlled
• 40 degC rated

Just connect MAINS POWER PUMPS - ready to GO
11
MENU OPERATION

• System pressure
• Flow rate / min
• Flow Total
• Pump 1 Hour Run
• Pump 2 Hour Run
• Pump 3 Hour Run
• Fault History
• Access Code
•
• SETTINGS
• TUNING
• TIMING
• CONFIGURE
• OUTPUTS
• INPUTS

Display Menus Available for all operators
Main Menus Available for all operators
12
MENU OPERATION
Main Menus
13
SUB MENUS
SETTINGS
Sub Menus Available after Access Code Entered
LoPress Shutdown Cut In Pressure Set Point Hi
Pressure Limit HiPress Shutdown Pump Flow
Rate Friction Loss Set Point 2 Set Point
3 PressureTrip1low PressureTrip1Hi PressureTrip2lo
w PressureTrip2Hi
Site Settings
14
SUB MENUS
TUNING

• Minimum Frequency
• Response Rate
• Acceleration
• Anti Cycle
• Auto-Rotation
• Fault Restarts
• Shutdown Boost

Site Adjustment
15
SUB MENUS
Site Timing
TIMING

• Low Pressure Delay
• High Pressure Delay
• IN Delay Timer
• OUT Delay Timer
• Shut down delay
• Input Delay Time

16
SUB MENUS
CONFIGURE
System Settings

• Transducer Zero
• Adjust Pressure
• Averaging
• Access Code
• VFD Options
• DOL Backup Mode

17
SUB MENUS
INPUTS / OUTPUTS
Programmable Output 1 Programmable Output
2 Programmable Output 3 Programmable Output
4 Programmable Input 1- 8

• Telemetry
• Communication

18
DATA LOGGING

• Flow Total
• Hour Run meters
• Fault History

Full report history For fault finding and
Historical data
19
FLOW MONITORING

• MPCSV has flow rate calculations on board
• Instantaneous flow
• Totaled Flow
• Based on average flow rate but varied depending
  on VFD speed and number of pumps running
• Accuracy /- 10

20
HOUR RUN
Each pump has an HOUR RUN METER
To reset press ENTER DOWN
21
FAULT MONITORING
22
FAULT MONITORING
When a fault is current the display changes
from SYSTEM PRESSURE to NEW
FAULT This allows the operator to inspect the
log at his leisure

• NEW FAULT

• 1234

23
FAULT RESTARTS

• After a HIGH PRESSURE SHUTDOWN the MPCSV can be
  Automatically restarted via the FAULT RESTART
  Option.
• If selected the system will restart after a
• high pressure shut down fault for the number

• entered

24
VFD OPTIONS

• VFD Type
• Standard
• Normal VFD Configuration
• Duty / Backup
• Two VFDs one to take over in case of failure.
  Only one units operates under normal operation
• Duty / Standby
• Two VFDs They alternate in operation each time
  the system comes to rest or the pumps are
  triggered to cycle.

25
DOL BACKUP MODE

• If a VFD fails and there is no backup for it the
  MPCSV can be programmed to operate as a Fixed
  Speed Pressure System
• MPCSV will attempt to restart the VFD
• 3 times at 15 second intervals
• The Pumps will start and stop a pressure points
  on either side of the set point.

26
DOL BACKUP MODE
27
OUTPUTS

• 4 Programmable OUTPUTS
• Change over contacts for
• NO / NC operation

28
OUTPUTS FAULTS

• Fault Reporting
• Range of information about the fault status of
  the system

29
OUTPUTS

• Status Reporting
• Information about the status of the system

30
OUTPUTS

• External use relays
• Can be used to drive other appliances

31
OUTPUTSPRESSURE TRIP

• Use for
• Jockey Pump
• Filters
• Control devices
• Alarms

Pressure Trip allows the relay to open at Low
pressure and close at high pressure
32
OUTPUTSALTERNATE TRIP
Built in FLIP FLOP SWITCH
Relay will toggle locations after each shutdown
or Forced Lead pump Cycle Use for load sharing
devices
33
INPUTS

• 12 Digital Inputs
• 4 Fixed Function
• 8 Programmable
• Analogue Inputs
• 4-20mA
• 0-10VDC
• Fully adjustable in software

34
INPUTS

• 4 Fixed Function
• Pause
• Protection Pump 1
• Protection Pump 2
• Protection Pump 3

35
INPUTS

• 15 Programmable options
• Allows full remote control
• Allows flexibility for all applications

36
INPUTS

• FIRE MODE All protections are disabled
• Cycle Pumps - Cycles the lead pump
• Reset Resets all shut down faults
• Soft pause Stops the system in a controlled
  manner
• Shutdown verify Flat curved pumps verify no
  flow
• No flow Protection for no flow in the
  system

SMART CONTROL
37
MULTIPLE SET POINTS

• Set Point 2 and 3 are selected by closing the
  associated Input
• Ideal for
• Building management
• Air conditioning
• Town water supply
• Sub-division

38
SENSORS

• MPCSV comes with
• an onboard
• PRESSURE TRANSDUCER
• Will accept any 4-20 mA or
• 0-10VDC sensor input

• Standard transducer
• Bridge Rectifier style transducer
• Operating pressure 0-250psi
• Burst 500 psi
• Fluid temp 50 degC

39
PROTECTION
Thermistor
Pressure / LoP switch
Temperature Switch
No flow switch
Auxiliary Contact Overload

• This protection is ideal for the
• following sensors
•           Flow switch for each pump
•           Temperature switch
•           Under current relays - for sensing low
  flow
•           loss of prime pressure switches

Current Transformer
40
VFD FAILURE

• Standard Mode
• Once failure is detected-
• MPCSV shuts down the VFD
• Waits 15 seconds
• Attempts to restart
• Continues ad infinitum
• Duty / Backup Duty / Standby Mode
• Once failure is detected
• Changes VFD
• Detects a fault
• Shifts to Standard VFD mode

41
FRICTION LOSS

• Automatically add pressure to the
• set point based on flow rate
• Designed to compensate for friction loss

42
PAUSE MODES

• MPCSV can PAUSE from an external input
• EMERGENCY PAUSE
• Instant shutdown restart via standard method
• SOFT PAUSE
• Controlled shutdown based on the set point
  dropping to ZERO

43
PUMP LEAD PUMP CYCLE

• The lead pump can be cycled on
• External Signal
• From time clock
• BMS signal
• SCADA Signal
• External function eg filter backwash
• Time base on a 24hr Basis
• Accurate 2 ie 28 min in 24hr

44
SHUTDOWN

• The pump system will shut down when
• Only 1 pump running
• Shutdown Boost and measures the time taken to
  return to the Set Point

45
PID CONTROL

• The set point control used is a PID Variant
  designed by Techsys Corporation RD engineers
  Achieve 2 at set point
• Designed for pumps
• Forward looking
• System response controlled by RESPONSE RATE
• Damping by Acceleration and Deceleration

46
LEAD VFD - LAG SOFT STARTER

• Multiple pump
• First pump started is the VFD pump
• Lag pumps operate on fixed speed
• Set point 20

47
ONE VFD PER PUMP

• Operational VFD on each pump
• When extra pumps are required the system calls in
  additional VFD/Pump combinations
• The system can have all of the VFDs functioning
  at a speed
• All pumps vary the speed together

48
CASCADING VFD SYSTEM

• VFD starts on First pump
• As the load increases the First pump is switched
  to fixed speed
• The second pump starts on VFD etc.

49
CONTROL MODES

• Pressure
• Level
• Temperature
• Any analogue input for
• Constant Operation
