Title: Ocean PEATE


1
Ocean PEATE
  • Fred Patt

2
Ocean PEATE Agenda
  • Science Team Introduction
  • Ocean PEATE Design
  • ODPS Design Overview
  • Implementation Plan and Schedule
  • Documentation
  • Issues

3
NPP/VIIRS Ocean Team
  • Chuck McClain Ocean Color PI
  • Peter Minnett (U. Miami) SST PI
  • Gene Feldman Ocean PEATE Manager
  • VIIRS Ocean Science Team
  • Wayne Esaias
  • Barney Balch (Bigelow Lab)
  • Mike Behrenfeld (Oregon State U.)
  • Janet Campbell (U. New Hampshire)
  • Bob Evans (U. Miami)
  • Stephane Maritorena (UCSB)
  • Norm Nelson (UCSB)
  • Dave Siegel (UCSB)
  • Ken Voss (U. Miami)
  • Menghua Wang (NOAA/NESDIS)

4
Ocean Team (cont.)
  • VIIRS Instrument and Calibration Support
  • Kevin Turpie
  • Bob Barnes
  • Gene Eplee
  • Gerhard Meister
  • Validation Support
  • Sean Bailey
  • Jeremy Werdell
  • Software Support
  • Bryan Franz
  • Joel Gales
  • Data System
  • John Wilding
  • Systems Management
  • Paul Smith

5
NASA/GSFC Ocean Biology Processing Group (OBPG)
Projects
  • Sea-viewing Wide Field-of-view Sensor (SeaWiFS) /
    Orbview-2 active
  • Moderate-resolution Imaging Spectroradiometer
    (MODIS) / Terra and Aqua active
  • Coastal Zone Color Scanner (CZCS) / Nimbus-7
    heritage
  • Ocean Color and Temperature Scanner (OCTS) /
    ADEOS-I heritage
  • Glory data system prototype 2009 launch
  • Aquarius / SAC-D May 2010 launch
  • VIIRS / NPP September 2009 launch

6
Ocean PEATE Agenda
  • Science Team Introductions
  • Ocean PEATE Design
  • ODPS Design Overview
  • Implementation Plan and Schedule
  • Documentation
  • Issues

7
Ocean PEATE Design
  • The NPP Ocean PEATE will be implemented within
    the framework and facilities of the current NASA
    Ocean Data Processing System (ODPS)
  • This system has been successfully supporting
    operational, satellite-based remote-sensing
    missions since 1996, and its capabilities
    continue to evolve and expand to meet the demands
    and challenges of future missions.

8
Element Overview
  • Acquire VIIRS RDRs, SDRs, and Ocean EDRs from the
    SD3E and ADS/CLASS
  • Assess the quality of the NPP Ocean EDRs for
    accomplishing NASAs climate research
    requirements
  • Provide suggested algorithm improvements to the
    IDPS via the Project Science Office Element
    (PSOE)
  • Process selected data subsets in support of
    Evaluation and Validation activities

9
Changes since PDR
  • Established interface with RSMAS (U. Miami) for
    SST Validation using MODIS validation for proof
    of concept.
  • Expanded and elaborated on xDR evaluation
    methodologies (as presented at July Peer Review).

10
Ocean PEATE Interface Diagram
Analysis Results, Proposed Algorithm Updates
xDRs, IPs, Ancillary Data
Management Direction
xDRs, IPs, Ancillary Data (if unavailable from
SD3E)
OceanPEATE
Pre-flight Algorithms, Data, Info
Software, Data
Alternate Ancillary Data
xDR Eval. Results, Algorithm Updates
Calibration Updates and Evaluations
Interaction
In Situ Data
In Situ Data
Algorithm Updates, Test Requests Results
Matchups
11
Ocean PEATE External Interfaces (1 of 2)
  • SDS Science Data Distribution and Depository
    Element (SD3E)
  • Provides NRT access to raw data
  • Primary source of RDRs
  • Provides selected SDRs and EDRs
  • SDS Integration and Test System Element (ITSE)
  • Build and test updates to operational code in
    mini-IDPS
  • Run tests on selected data per request of PEATE
  • Archive Distribution Segment (ADS)
  • Primary source for archived data
  • xDRs, IPs, Ancillary Data, Operational
    Algorithm/Source Code and Calibration Products
  • Ancillary Data Providers (ADP)
  • Provides alternate ancillary data sets (e.g.,
    ozone, meteorological data sets)
  • CasaNOSA
  • Serves as the NPP pre-flight repository of
    Government held data for distribution to
    Government user teams
  • Place to acquire pre-launch NPP algorithms and
    supported data files

12
Ocean PEATE External Interfaces (2 of 2)
  • NASA VIIRS Ocean Science Team (VOST)
  • Coordinate activities with PEATEs and PSOE on xDR
    and recommended algorithm improvements. Supports
    Independent Calibration Validation Activities
  • NPP Instrument Calibration Support Element
    (NICSE)
  • Provides alternative calibration LUTs and
    recommended improvements to calibration
    algorithms
  • PEATE provides results of LUT and algorithm tests
  • Project Science Office Element (PSOE)
  • Provides management direction
  • Accepts algorithm update recommendations
  • SeaBASS/ODPS
  • Provides Ocean Color in situ data
  • RSMAS/U. Miami
  • Provides SST in situ locations
  • PEATE provides SST EDR matchups
  • Ocean Science Community
  • Relies on Ocean PEATE to provide evaluation
    products and results

13
Assumptions Role of ITSE
  • The Ocean PEATE will rely upon the SDS-provided
    ITSE (mini-IDPS) to serve as the testbed for
    algorithm evaluation and potential improvements
    and will not attempt to duplicate efforts by
    running the operational code within the PEATE
    environment.
  • The staff of the ITSE will have the ability to
    modify any operational code as per Ocean PEATE
    specification and run the code within the
    operational environment against a set of
    PEATE-specified test data sets.
  • The ITSE will receive and install the most
    current version of the code and executable
    programs for all operational IDPS software
    required to produce NASA-evaluated EDRs, starting
    from RDRs.
  • The ITSE will maintain all processing code under
    configuration control. The PEATEs will have
    access to the configuration controlled code.

14
Ocean PEATE Support for IDPS Software
  • The Ocean PEATE will maintain a working knowledge
    of the VIIRS SDR code and the EDR code for the
    Ocean Color and SST EDRs.
  • The Ocean PEATE will maintain an understanding of
    the relevant IP characteristics, but will
    (initially) assume that the IPs are properly
    generated.
  • The Ocean PEATE will design changes to the code
    in the ITSE for the purpose of algorithm
    improvement or problem resolution.
  • The Ocean PEATE will develop appropriate test
    cases and request runs to verify and evaluate the
    changes.
  • The Ocean PEATE will provide recommended changes
    to the PSOE, including a description of the
    proposed change, effect on the EDR performance,
    and the evaluation of the test runs.

15
IDPS VIIRS Ocean EDR Data Flow
Processing Module
VIIRS Product
VIIRS RDR
Dynamic Ancillary Data
Previous VIIRS Gridded Products
Static Ancillary Data
Previous VIIRS Gridded Products
NAAPS TOD
MODIS Land/Water Mask
NCEP Geopotential Height
Ancillary Files
Ancillary Files
DEM
NDT
16
IDPS VIIRS Ocean EDR Data Flow
VIIRS Geolocation
VIIRS SDR
Processing Module
VIIRS_SDR_01 RDR Decompression
VIIRS_GEO_01 Geolocation
VIIRS_SDR.IM 375m SDR
VIIRS_SDR.MOD 750m SDR
VIIRS SDR
VIIRS Product
VIIRS RDR
Dynamic Ancillary Data
Previous VIIRS Gridded Products
Static Ancillary Data
Previous VIIRS Gridded Products
NAAPS TOD
MODIS Land/Water Mask
NCEP Geopotential Height
Ancillary Files
Ancillary Files
DEM
NDT
17
IDPS VIIRS Ocean EDR Data Flow
VIIRS Geolocation
VIIRS SDR
Processing Module
VIIRS_SDR_01 RDR Decompression
VIIRS_GEO_01 Geolocation
VIIRS_SDR.IM 375m SDR
VIIRS_SDR.MOD 750m SDR
VIIRS SDR
VIIRS Product
VIIRS RDR
Dynamic Ancillary Data
Previous VIIRS Gridded Products
Static Ancillary Data
Previous VIIRS Gridded Products
VIIRS_GD_08 750m Granulation
NAAPS TOD
VIIRS_GD_25 NAAPS Granulation
MODIS Land/Water Mask
VIIRS_GD_27 L/W Mask Granulation
NCEP Geopotential Height
Ancillary Files
Ancillary Files
VIIRS_GD_11 Ancillary Profile
VIIRS_GD_09 GFS Granulation
ALL_GD_01 Time Interpolation
VIIRS_GD_28 Surface Pressure Adjustment
VIIRS_GD_12 Bathymetry Granulation
DEM
VIIRS_GD_13 Temperature Granulation
NDT
18
IDPS VIIRS Ocean EDR Data Flow
VIIRS Geolocation
VIIRS SDR
Processing Module
VIIRS_SDR_01 RDR Decompression
VIIRS_GEO_01 Geolocation
VIIRS_SDR.IM 375m SDR
VIIRS_SDR.MOD 750m SDR
VIIRS SDR
VIIRS Product
VIIRS RDR
Dynamic Ancillary Data
Previous VIIRS Gridded Products
Static Ancillary Data
Previous VIIRS Gridded Products
VIIRS_GD_08 750m Granulation
NAAPS TOD
VIIRS_GD_25 NAAPS Granulation
MODIS Land/Water Mask
VIIRS_LN_06 Active Fires
VIIRS_CM_01 Cloud Mask
VIIRS_GD_27 L/W Mask Granulation
NCEP Geopotential Height
Ancillary Files
Ancillary Files
VIIRS_GD_11 Ancillary Profile
VIIRS_GD_09 GFS Granulation
ALL_GD_01 Time Interpolation
VIIRS_GD_28 Surface Pressure Adjustment
VIIRS_GD_12 Bathymetry Granulation
DEM
VIIRS_GD_13 Temperature Granulation
NDT
19
IDPS VIIRS Ocean EDR Data Flow
VIIRS Geolocation
VIIRS SDR
Processing Module
VIIRS_SDR_01 RDR Decompression
VIIRS_GEO_01 Geolocation
VIIRS_SDR.IM 375m SDR
VIIRS_SDR.MOD 750m SDR
VIIRS SDR
VIIRS Product
VIIRS_SN_02 Ice Quality
VIIRS RDR
Dynamic Ancillary Data
Previous VIIRS Gridded Products
Static Ancillary Data
VIIRS_CL_01 Cloud Optical Properties
Previous VIIRS Gridded Products
VIIRS_ST_02 Surface Temp
VIIRS_GD_08 750m Granulation
NAAPS TOD
VIIRS_SN_03 Ice Concentration
VIIRS_GD_25 NAAPS Granulation
MODIS Land/Water Mask
VIIRS_LN_06 Active Fires
VIIRS_CM_01 Cloud Mask
VIIRS_GD_27 L/W Mask Granulation
NCEP Geopotential Height
Ancillary Files
Ancillary Files
VIIRS_ST_01 Sea Surface Temperature
SST EDR
VIIRS_GD_11 Ancillary Profile
VIIRS_GD_09 GFS Granulation
VIIRS_AR_01 Aerosol Type
ALL_GD_01 Time Interpolation
VIIRS_GD_28 Surface Pressure Adjustment
VIIRS_OC_01 Ocean Color / Chlorophyll
VIIRS_GD_12 Bathymetry Granulation
OCC EDR
DEM
VIIRS_GD_13 Temperature Granulation
NDT
20
ODPS MODIS Ocean Product Data Flow
Processing Module
MOD_PR01 Level-0 to 1A
MODIS Product
Dynamic Ancillary Data
MODIS Level-0
MODIS Level-1A
Static Ancillary Data
MODIS 1 km Level-1B
MOD_PR03 Geolocation
MOD_PR02 Level-1A to 1B
MODIS SST
Platform ATTEPH Data
MSl12 Level-1B to 2
MODIS Geolocation
MODIS Ocean Color
MET Ancillary Data
Ozone Ancillary Files
Land/Water Mask
21
Evaluation vs. Product Level
  • Level-1 (SDR) Evaluations
  • Onboard calibration analyses
  • Vicarious calibration
  • Level-2 (EDR) Evaluations
  • Matchup analyses
  • Residual detector (striping) and scan (RVS)
    dependence
  • Level-3 Product Evaluations
  • Sensor cross-comparisons
  • Algorithm comparisons
  • Temporal anomaly evaluations

22
SDR Example Vicarious Calibration
23
EDR Example Scan and Detector Dependence
24
Level-3 Example Zonal Cross-Comparisons
25
Ocean PEATE Agenda
  • Science Team Introductions
  • Ocean PEATE Design
  • ODPS Design Overview
  • Implementation Plan and Schedule
  • Documentation
  • Issues

26
ODPS Design Overview
  • Fully automated, distributed data system for
    acquiring, processing, archiving, and
    distributing scientific data
  • Highly scalable
  • Easily adaptable to support multiple concurrent
    missions
  • Graphical user interfaces for controlling and
    monitoring system functions and activity
  • Non-platform specific

27
ODPS Design Philosophy
  • Building-Block approach
  • Programs are usually small and do one thing well
  • Programs are less complex and subsequently easy
    to maintain
  • Promotes reuse
  • Programs loosely coupled so testing and
    production can be done in the same environment
  • Adopt basic standards
  • ANSI, POSIX, C9x
  • Use existing technology when possible
  • Exit statuses indicate successful or failure
    conditions

28
Components and Subsystems
29
Components and Subsystems (1 of 2)
  • RDBMS is the primary element that manages all
    system activity
  • Generic core databases support system
    infrastructure and non-mission-specific functions
  • Mission databases catalogue products and house
    mission-specific data and procedures
  • High level of reuse possible for similar
    missions e.g., MODIS Aqua/Terra, SeaWiFS, CZCS,
    and OCTS are all ocean-color missions and have
    similar product suites and requirements

30
Components and Subsystems (2 of 2)
  • Relational Database Management System (RDBMS)
    supports all of the system components
    (subsystems)
  • VDC/Scheduler is the primary controlling module
    within the system
  • Other subsystems are independent modules, yet
    rely on the VDC/Scheduler for some their
    functions
  • Archive Device Manager (ADM)
  • Data acquisition and ingest
  • Level-3 Scheduler
  • File migration and management
  • Data distribution

31
ODPS COTS and Freeware
  • Linux OS (CentOS 4.x)
  • Solaris OS
  • Sybase RDBMS
  • Subversion (source code management)
  • Pro-active DBA
  • Interactive Data Language (IDL)
  • Generic Mapping Tool (GMT)
  • Netpbm (graphic image toolkit)
  • HDF5 Library
  • Languages C, PERL, SQL

32
ODPS Architecture Hardware
  • Processing Servers
  • Intel-based dual Xeon / AMD-based dual Opteron
  • 8 GB RAM
  • Five 72 GB SCSI drives
  • Storage Servers
  • Intel-based P4 / AMD-based single Opteron
  • 1 GB / 2 GB RAM
  • 1.5 TB IDE RAID 5 (3ware) / 9.6 TB SATA RAID 6
    (Areca)
  • 2 hot spare drives per RAID5
  • Database Server
  • Sun V880
  • 8-16 GB RAM
  • 6-12 70 GB SCSI HDD

33
ODPS Current Components
34
Building 28 Room W220 Computing Facility
35
Reliability and Redundancy
  • Critical components (database server, network
    systems) have full maintenance contracts to
    ensure rapid response to problems
  • Multiple-server components (ingest, processing,
    storage, distribution) have substantial
    redundancy to maintain full capability spares
    maintained for rapid replacement.
  • Testing nodes are separated from mainstream
    production components.

36
Technology Refresh
  • Hardware technology advances (CPU, storage) are
    continuously monitored to select new components
    for evaluation.
  • Typical upgrade threshold is a doubling in
    capacity (18 months).
  • Two generations of hardware are generally in use.
  • Candidate components are procured, installed in
    testing cluster and rigorously evaluated in a
    production-like environment.
  • Following successful evaluation, multiple copies
    are procured, installed, tested and swapped in
    for older components.
  • ODPS design allows new components to be rapidly
    added to resource tables without interrupting
    system operations.
  • Performance of new components is closely
    evaluated following installation in operations
    environment.
  • Critical components are run in parallel with
    existing system to ensure reliability under
    production loading.

37
Ocean PEATE Agenda
  • Science Team Introductions
  • Ocean PEATE Design
  • ODPS Design Overview
  • Implementation Plan and Schedule
  • Documentation
  • Issues

38
Ocean PEATE Gap Analysis (1 of 2)
  • Acquire, ingest and catalog NPP VIIRS data
    products RDRs, SDRs and Ocean EDRs (Data
    Acquisition Ingest, Device Manager and File
    Migration and Management).
  • Status Development of acquisition and ingest
    scripts underway based on sample products in
    SD3E.
  • Process selected Ocean EDRs (SST and OCC) to
    Level-3 to support data product and algorithm
    evaluations (Level-3 Scheduler, VDC and Level-3
    binner).
  • Status Prototype Level-3 processing has been
    demonstrated using sample IDPS Build 1.4 OCC and
    SST EDRs.
  • Perform VIIRS OCC EDR matchups with SeaBASS Ocean
    Color in situ data (extract code).
  • Status Pending completion of acquisition and
    ingest capabilities.

39
Ocean PEATE Gap Analysis (2 of 2)
  • Incorporate VIIRS SDR processing for vicarious
    calibration analysis. ()
  • Status Pending availability of sample SDRs in
    Build 1.5 format
  • Produce VIIRS proxy data using VOST-developed
    software (VDC/Scheduler).
  • Status Prototype geolocation and EDR simulation
    developed to test Level-3 binning of EDRs.
  • Acquire SST in situ data from RSMAS and perform
    matchups with SST EDRs ()
  • Status Pending final MOU
  • Support browse and distribution of data products
    for team members (Data Distribution).
  • Status Pending completion of acquisition and
    ingest capabilities.
  • () New PEATE capability identified since PDR

40
Prototype Level-3 Processing
  • EDR to Level-3 processing prototype completed
    using IDPS Build 1.4 EDRs.

41
Existing Software Reuse
  • ODPS Components
  • Database
  • VDC/Scheduler
  • Data Acquisition and Ingest
  • Level-3 Scheduler
  • File migration and management
  • Archive Device Manager
  • Data distribution
  • Level-2 multi-mission software (vicarious
    calibration)
  • Level-3 multi-mission software (long-term trends
    and comparisons
  • Level-2 to Level-3 comparison software (residual
    sensor errors)
  • SeaBASS (in situ data management)
  • Matchup/extraction software

42
Basis of Estimate (1 of 2)
  • Acquire, ingest and catalog NPP VIIRS data
    products
  • 200 LOC (combined UNIX shell, SQL, C) per new
    product, for each of the four VIIRS products
  • Process Ocean EDRs (SST and OCC) to Level-3
  • 300 C LOC to add VIIRS Ocean EDR input to
    existing binning software (L2bin)
  • 300 SQL LOC per temporal range (10 ranges total)
  • 200 shell LOC for all ranges
  • Perform VIIRS EDR matchups
  • 100 C LOC 10 PERL LOC to add VIIRS Ocean EDR
    input to existing extraction software

43
Basis of Estimate (2 of 2)
  • Process SDRs for vicarious calibration analysis
  • 1000 C LOC to add VIIRS SDR input to existing
    Level-2 processing software (MSl12)
  • Produce VIIRS proxy data
  • 100 shell LOC for each processing stage
  • Support browse and distribution of data products
  • 3000 C LOC to implement browse image generation
  • 100 PERL LOC to add VIIRS products to existing
    browse and order web site

44
Ocean PEATE Data Storage Estimate
Data Type Daily 1 Year 5 Years
RDR 150 GB 53.5 TB 268 TB
SDR (M-band) 242 GB(2) 8.6 TB(1,2) 43 TB(1,2)
OCC EDR 84 GB 3 TB(1) 15 TB(1)
SST EDR 19 GB 0.7 TB(1) 3.4 TB(1)
Inter. Products 70 GB N/A N/A
Ancillary Data 0.1 GB .04 TB .2 TB
Total 565 GB 66 TB 330 TB
  • Assumptions
  • Long-term storage is sized for 100 of RDRs and
    10 of SDRs and EDRs
  • SDR volume includes geolocation

45
New Hardware for the Ocean PEATE
  • 7 Storage Servers _at_ 9.6 TB first-year VIIRS
    data storage
  • Additional servers acquired post-launch to handle
    years 2 5
  • No new processing or network capacity required
    technology refresh cycle to be continued within
    the ODPS as described.

46
Ocean PEATE Build Schedule
  • Build 1 (L-18 months)
  • All interfaces fully implemented and tested
  • Verify initial versions of operational code
    ported and running in ITSE
  • L-3 product code developed and tested
  • Prelaunch VIIRS test data storage and SDS
    interface testing support with existing ODPS
    storage capacity
  • Initial test products generated for review by
    VIIRS Ocean Science Team
  • Build 2 (L-12 months)
  • Routine exercise of interfaces to acquire proxy,
    surrogate (Aqua?) and/or simulated data
  • Verify pre-launch version of operational code
    running in ITSE
  • Browse and distribution capability developed and
    tested
  • Test products routinely acquired as available and
    posted for access by VIIRS Ocean Science Team
  • Data storage for one year

47
Ocean PEATE Development Schedule
48
External Schedule Dates
  • C3S SDS Integration
  • October 2008
  • IDPS SDS Integration
  • October 2008
  • NSIPS SDS Integration
  • October 2008
  • Functional Thread Test Dates
  • FTT8 A
  • Ingesting xDRs October 2008
  • FTT8 B
  • Validating xDRs October 2008
  • NPP Compatibility Tests
  • NCT2C - December 2007
  • NCT3 - September 2008

49
Ocean PEATE Testing
  • ODPS Testing Philosophy
  • Test as you run.
  • Test early, test often.
  • Phased approach to testing get one thing working
    and move on to the next step until entire
    end-to-end stream is operational.
  • Testing VIIRS support to be done within
    operational ODPS environment, with products
    clearly identified for separation from
    operational product stream.
  • Testing stages
  • Interfaces
  • Internal functionality (processing, evaluation)
  • End-to-end
  • Test data sources
  • VIIRS proxy data
  • VOST simulation
  • MODIS products (e.g., initial SST validation)
  • Availability of official test data is an issue.

50
Ocean PEATERequirements Implementation
  • 95 of requirements (19) implemented by Build 2
    add additional storage capacity before launch

51
Sustaining Operations and Maintenance
  • ODPS runs 24x7 with on-site support 8x5.
  • Support is shared across all projects.
  • Staffing needs are covered by existing OBPG
    support personnel.

52
Ocean PEATE Staffing Levels
  • All staffing needs will be met with existing OBPG
    staff
  • Increases will be accommodated as other projects
    (e.g., MODIS Aqua) wind down.

53
Documentation
  • Ocean PEATE Level 4 Requirements and Operations
    Concept
  • ICDs
  • SD3D to PEATEs
  • CLASS?
  • MOU with RSMAS (TBS)
  • ODPS Project Data Management Plan (draft)
  • OCDPS Risk Management Plan
  • Network IT Security Plan

54
Historical Milestones
  • PEATE selected January 2004
  • PEATE Peer Review November 30, 2006
  • SDS PDR September 19, 2006
  • EDR Evaluation Peer Review July 18, 2007

55
Issues/Challenges/Concerns
  • Limits of available test data
  • Ability to adequately test and flow data across
    interfaces
  • Verification of EDR evaluation processes
  • Extent of prelaunch end-to-end (observatory
    ground system) data flows
  • ADS to PEATE interface
  • Complexity of IDPS internal processes and data
    flows
  • Version synchronization of operational products
    with IDPS software in the ITSE
  • Ability to diagnose software and algorithm
    problems in the ITSE
  • Bandwidth of NSIPS/SD3E interface
  • Sole source of IPs including OBC products
  • Separation of spacecraft diary from science RDRs
  • Requires tracking gt4000 small granules/day

56
Conclusion
  • Ocean PEATE will meet all requirements
  • Next Up Land PEATE Ed Masuoka
  • NPP_SDS_Land.ppt

57

Backup Slides
58
Ocean PEATE Level 4Requirements Allocation (1 of
2)
SDS Rqmt Number SDS Rqmt Title Subsystem
3 Ocean PEATE N/A
3.1 Acquire RDRs, SDRs, and Ocean EDRs N/A
3.1.1 3.1.2 3.1.3 3.1.4 3.1.5 3.1.6 3.1.7 3.1.8 Acquire and Ingest VIIRS RDRs from SD3E Submit Requests to SD3E for Subsets of SDRs and EDRs Acquire and Ingest SDRs and EDRs from SD3E Submit Requests to ADS/Class for SDRs and EDRs Acquire and Ingest SDRs and EDRs from ADS/CLASS Provide Storage for RDRs, SDRs and EDRs Support Cataloging, Searching, Ordering and Distribution VDC/Scheduler Data Acquisition Ingest File Migration and Management Device Manager Data Distribution PEATE Personnel
3.2 Assess the Quality of the NPP Products N/A
3.2.1 Assess the Quality of the Ocean EDRs N/A
3.2.1.1 3.2.1.2 3.2.1.3 3.2.1.4 3.2.1.5 3.2.1.6 3.2.1.7 Ground Truth Validation with In Situ Data Cross-comparisons with Concurrent Satellite Data Sets Comparisons with Climatological Data Sets Assessments of Internal Consistency Flagging and Masking Assessment Prelaunch Algorithm Assessment VDC/Scheduler Level 3 Scheduler Level 3 Binner SeaBASS Matchup/Extraction Software
59
Ocean PEATERequirement Allocation (2 of 2)
SDS Rqmt Number SDS Rqmt Title Subsystem
3.2.2 Support VOST in Assessing Quality of the VIIRS SDRs N/A
3.2.2.1 3.2.2.2 3.2.2.3 Assessment of long-term radiometric stability Assessment of instrumental corrections Analysis of prelaunch test results VDC/Scheduler Level 2 Processing Software PEATE Personnel
3.3 Provide Suggested Algorithm Improvements
3.4 Process Selected Data Subsets N/A
3.4.1 Interface with ITSE for Processing Data PEATE Personnel
3.4.2 Acquire Processing Code from ITSE PEATE Personnel ODPS CM
3.4.3 Acquire SDRs and EDRs from ITSE VDC/Scheduler Data Acquisition Ingest File Migration and Management Device Manager Data Distribution
60

ODPS Design Details
61
RDBMS
Components and Subsystems RDBMS
Goal Isolate RDBMS from system software
To use a different RDBMS vendor, swap in a new
Database Services Layer
RDBMS
Vendor Client Library
Vendor Library Module
Database Services Layer
C Interface Functions
Perl DBI Module
Perl Scripts
C Programs
62
VDC/Scheduler
Subsystems VDC/Scheduler
  • C program with supporting database procedures
  • Runs in a daemon-like state on every processing
    server
  • Primary system element responsible for
    coordinating most of the system activity
  • Monitors task records in a to-do list database
    table
  • Runs tasks according to defined task attributes
  • Standard job-shell interface allows new programs
    to be quickly adapted as tasks for Scheduler
    control

63
VDC/Scheduler
Subsystems VDC
  • Highly scalable, distributed infrastructure for
    concurrent processing of serial streams (e.g., L0
    ? L1A ? L1B ? L2)
  • Suite of C programs with supporting database
    procedures
  • Uses recipes to encapsulate data-specific
    processing schemes, parameters, and
    pre-processing rules
  • Virtual Processing Units (VPUs) serve as distinct
    distributed processing resources
  • VPUs dynamically allocated based on available
    time and current OS load
  • Comprehensive, user-defined processing priorities

64
VDC Ancillary Data Stager
VDC Pre-processing Rule Manager
  • Runs in a daemon-like state
  • Monitors entries in the processing queue and runs
    the rule proceduresthat are associated with the
    rule scheme for each recipe
  • Updates queue-entry status when all rule
    procedures return successfully
  • Governed by currently configured processing
    priorities

65
VDC MakeVDC
VDC MakeVDC
  • Selects processing-queue entries that have passed
    pre-processing-rule requirements
  • Generates custom VDC job files from templates
    according to configured priorities
  • Runs as a Scheduler task, so it can easily be
    configured to run as often as needed to keep the
    VDC queue full

66
VDC Engine
VDC Engine
  • Function performed by the VDC/Scheduler module
  • Each instance actively competes for jobs that it
    is allowed to run, based on priority, length of
    time in the queue, and user nudges
  • Monitors and manages processing resources
  • Initializes processing streams
  • Invokes recipe steps and monitors step-execution
    time
  • Handles operator-requested stream actions

67
Archive Device Manager
Subsystems Device Manager (DM)
  • User defines logical pools of storage devices
  • Processes request a device in a specific pool
  • DM returns information for a storage device in
    the requested pool
  • If auto-cycling is enabled, the DM time-stamps
    the record for the selected device, so a
    different device within the pool will be selected
    for the next request
  • When a device in a pool exceeds a user-configured
    usage threshold, the device is no longer eligible
    to be selected
  • Disk-monitor process polls all devices
    periodically to record usage statistics and
    invoke threshold handlers

68
Data Acquisition and Ingest (1 of 2)
Subsystems Data Acquisition and Ingest
  • Data types and sources are described in the
    database
  • Active, passive, and periodic notification
    methods
  • Active method scans remote systems for new files
    and populates the ingest queue
  • Passive method waits for arrival of e-mail
    messages describing type and location of new file
    and populates the ingest queue
  • Periodic method schedules transfers of files at
    user-specified intervals

69
Data Acquisition and Ingest (2 of 2)
Subsystems Data Acquisition and Ingest
  • File transfers handled by ingest daemons and
    Scheduler tasks
  • FTP, RCP, SCP, WGET transfer protocols supported
  • Generic script handles the file transfer and then
    hands off to data-specific post-ingest scripts

70
Level-3 Scheduler
Subsystems Level-3 Scheduler
  • Responsible for scheduling processing for level-3
    composite products
  • Runs as a Scheduler task
  • Configuration is database driven
  • Mission-specific stored procedures are invoked to
    identify input files for a composite product

71
File Migration and Management
Subsystems File Migration and Management
  • Responsible for compressing files and migrating
    them to their various destinations
  • Event- or time-based actions
  • Ex1 compress files after they are QCd
  • Ex2 remove files that are more than N days old
  • Ex3 mirror files upon creation
  • Queries associated with each action are run
    periodically by a Scheduler task to select files
    that are eligible for some type of migratory
    action and populate a migration queue
  • Command-line queuing for file removal and delayed
    copies
  • Migration daemons query the migration queue,
    perform registered actions on the files, and
    update catalog tables

72
Data Distribution
Subsystems Data Distribution
  • Interactive, web-based Data Ordering System,
    currently supporting SeaWiFS and MODIS Aqua
  • Data Subscription System, currently supporting
    MODIS Aqua, allows users to define region and
    products of interest
  • Order and Subscription Manager Daemons monitor
    the order and subscription queues and stage files
    on FTP servers (stage rate 12 GB/hr)
  • Near-real-time data extraction and image support
  • Web-CGI applications that allow users to view and
    update their orders and subscriptions

73
New Data/Source Acquisition and Ingest
  • Insert DB records for new data-source servers and
    data types
  • Compose data-specific post-ingest scripts
  • Configure ingest daemons if that method is going
    to be used for any of the new data types
  • Define archive-device pools for product storage

74
New Data Product Cataloging
  • Insert record into the core tables (catalog DB)
    that describe the mission and products
  • Create mission specific database and objects,
    reusing objects from existing mission databases
    where applicable
  • Compose a program to provide geographical L1
    meta-data information including granule start and
    stop times, day-night flag, and geographic
    coordinates, e.g., MSl1info
  • Compose functions for DB-metaload program, so
    meta-data files can be read and product tables
    can be populated
  • Configure file migration and management actions
    for new mission data

75
New Data Processing Streams
  • Define a recipe for each distinct serial
    processing stream
  • Insert records for each recipe and each recipe
    step
  • Compose a job template for each recipe
  • Compose a ancillary-selection procedure for each
    recipe that requires ancillary data
  • Compose scripts for each science program
    associated with the new mission's data
  • Insert record in recipe-constraints table for
    each processing host allowed to run a recipe
  • Compose AP-load procedure for each base data type
    that can be processed with a recipe
  • Update the reproc program to support each base
    data type that has an AP-load procedure
  • Configure L3-Scheduler for desired composite
    processing

76
VIIRS Ocean Level-3 Processing
  • Develop data input routines to support processing
    of VIIRS Ocean EDRs using existing multi-mission
    Level-3 binning software

77
New Data Product Distribution
  • Update Subscription CGI to support new mission
    data
  • Compose match-subscription procedure
  • If data extraction and mapping is to be
    supported
  • Compose extraction and mapping programs
  • Compose match-XM-requests procedure
  • Modify XM CGI to support new mission products
  • Compose browser capabilities for new mission
    products
  • Provide FTP access to new mission products
Write a Comment
User Comments (0)
About PowerShow.com
