Shatter: Efficient SymmetryBreaking for Boolean Satisfiability

1
Shatter Efficient Symmetry-Breaking for Boolean
Satisfiability

• Fadi A. AloulIgor L. Markov, Karem A. Sakallah
• The University of Michigan

2
Motivation

• Many powerful SAT solvers are currently available
• Yet, many EDA instances remain hard to solve
• Recent work pointed out that breaking symmetries
  can speed up search
• E.g.

3
Previous Work

• In 1996, Crawford et al.
• Laid theoretical foundation for detecting and
  breaking symmetries in CNF formulas
• In 2002, Aloul et al.
• Extended the framework to handle phase shift
  symmetries and their composition with
  permutational symmetries
• Presented efficient construction of
  symmetry-breaking predicates

4
Symmetries in SAT

• Permutations of variables that preserve clauses
• e.g., symmetries of
• ? (a b c)(d e
  f)include

5
Why Break Symmetries?
SAT Solver
6
Why Break Symmetries?
SAT Solver
7
Why Break Symmetries?
SAT Solver
8
Symmetry Detection and Breaking Flow
CNF instance
Returns Generators which implicitly represents
the group of symmetries
? (ab)(bc)(ca)
DetectSymmetries
?1 (ab)(ab)?2 (bc)(bc)
BreakSymmetries
? (ab)(bc)(ca) (ab)(bc)
9
Symmetry Detection and Breaking Flow
CNF instance
Returns Generators which implicitly represents
the group of symmetries
? (ab)(bc)(ca)
DetectSymmetries
?1 (ab)(ab)?2 (bc)(bc)
BreakSymmetries
? (ab)(bc)(ca) (ab)(bc)
10
Outline

• Symmetry-Breaking Predicate (SBP) construction by
  Crawford et al.
• Efficient SBP constructions
• Experimental results
• Conclusions

11
Full Symmetry Breaking

• Lex-leader formula Crawford et al. 96
• Given a group of symmetries
  defined over totally-ordered variables

• For each symmetry , construct a permutation
  predicate

Image of variable xi under ?
PP(?) size5n clauses0.5n2 13.5n literals
12
Linear-Sized PPs
PP(?) size5n clauses0.5n2 13.5n literals
PP(?) size4n clauses14n literals
13
Linear-Sized Tautology-Free PPs

• Variables that map to themselves (i.e.
  )lead to
• Assume maps to itself

14
Linear-Sized Tautology-Free PPs

• Variables that map to themselves (i.e.
  )lead to
• Assume maps to itself

15
Linear-Sized Tautology-Free PPs

• Variables that map to themselves (i.e.
  )lead to
• Assume maps to itself

16
Linear-Sized Tautology-Free PPs

• Variables that map to themselves (i.e.
  )lead to
• Assume maps to itself

17
Partial Symmetry-Breaking (1)

• Full symmetry breaking may not speed up search
  because
• Exponential number of symmetries
• Their SBPs may be redundant
• Partial symmetry breaking provides a better
  trade-off
• Consider first k-variables from each permutation
• e.g. if k1

18
Partial Symmetry-Breaking (1)

• Full symmetry breaking may not speed up search
  because
• Exponential number of symmetries
• Their SBPs may be redundant
• Partial symmetry breaking provides a better
  trade-off
• Consider first k-variables from each permutation
• e.g. if k1

1
19
Partial Symmetry-Breaking (2)

• Instead of breaking all symmetries, break only
• Generators
• Generators and their powers
• Generators and their pair-wise compositions

Group of symmetries
20
Experimental Results
ofbits thatmap tothemselves
Generators consisted of cycles of size 2 only
21
Experimental Results
Break generators only
22
Experimental Results
Total size of generator-only SBPs using various
SBP constructions
23
Experimental Results
Total search runtimes for all instances when only
k bits are considered from each generator(using
linear tautology-free construction)
24
Experimental Results
SBP statistics for various symmetry-breaking
candidatesusing linear tautology-free
construction
25
Conclusions

• Introduced more efficient CNF constructions of
  symmetry-breaking predicates
• Constructions lead to
• Empirical speedups
• Smaller memory requirements
• Described options for partial symmetry-breaking

http//vlsicad.eecs.umich.edu/BK/Slots/shatter/
26
Thank You!
27
Reduction to Graph Automorphism

• CNF formula ? colored graph
• Linear time and space
• Find graphs colored symmetries
• Worst-case exponential time
• Interpret graph symmetries found as symmetries of
  the CNF formula
• Permutational symmetries
• Phase-shift symmetries

Clauses A (-a ? b ? c) B (a ? -b ? -c) C (-b
? c)
Symmetry(a -a)(b -c)(-b c)
28
Identifying Equivalence Classes on Set of Truth
Assignments
29
Identifying Equivalence Classes on Set of Truth
Assignments
30
Identifying Equivalence Classes on Set of Truth
Assignments
31
Identifying Equivalence Classes on Set of Truth
Assignments
ab
c
32
Symmetry-Breaking Predicates

• To restrict search
• Add clauses to the original CNF formula
• (symmetry-breaking clauses)
• They will pick at least one representative
  (including lex-leaders) from each equivalence
  class and prune search space

ab
c
Lex-leader of equivalence class
33
Example
34
Full Symmetry Breaking

• Lex-leader formula Crawford et al. 96.Given a
  group of symmetries defined
  over totally-ordered variables


Impractical
Permutation Predicate quadratic in the number of
variables n
Number of permutations in symmetry group is
exponentially large
. . .
35
Efficient SBP Constructions (1)

• Elimination of tautologies
• Bits that map to themselves
• Last bit in each cycle
• Bits occurring after phase-shift variables

k eliminated bits Permutation Predicate
quadratic in n-k
. . .
36
Efficient SBP Constructions (2)

• Linear construction of permutation predicates
  through chaining

k eliminated bits Permutation Predicate
linear in n-k
. . .
37
Partial Symmetry Breaking (1)

• To avoid exponential number of clauses
• Create permutation predicates for subset of
  permutations

Generators or Powers of Generators or Composition
of Generators
. . .
38
Partial Symmetry Breaking (2)

• To avoid exponential number of clauses
• Consider first k, instead of all, bits in a
  permutation

e.g. consider only first 5 bits in each
permutation
. . .
39
Shatter Flow Diagram
CNF instance
40
Symmetries in Search Space
41
Symmetry Detection and Breaking Flow
CNF instance
? (ab)(bc)(ca)
Identify Symmetries
Break Symmetries
?1 (ac)(bc)(ca)?2 (ca)(abc)
SAT Solver
Our focus
42
Symmetry Detection and Breaking Flow
CNF instance
DetectSymmetries
? (ab)(bc)(ca) (ac)(!bc)
?1 (ac)(bc)(ca)?2 (ca)(abc)
? (ab)(bc)(ca)
BreakSymmetries
Our focus
43
Symmetry Detection and Breaking Flow
CNF instance
? (ab)(bc)(ca)
?1 (ac)(bc)(ca)?2 (ca)(abc)
? (ab)(bc)(ca) (ac)(!bc)
44
Linear-Sized Tautology-Free PPs

• Variables that map to themselves (i.e.
  )lead to
• Assume maps to itself

45
Motivation

• Many powerful SAT solvers are currently available
• Yet, many EDA instances remain hard to solve
• Recent work pointed out that breaking symmetries
  can speed up search
• In 1996, Crawford et al.
• Laid theoretical foundation for detecting and
  breaking symmetries in CNF formulas
• In 2002, Aloul et al.
• Extended the framework to handle phase shift
  symmetries and their composition with
  permutational symmetries

46
Outline

• Basic definitions
• Symmetry-Breaking Predicate (SBP) construction by
  Crawford et al.
• Efficient SBP constructions
• Experimental results
• Conclusions

47
Permutations and Generators

• Number of symmetries can be exponentially large
• Represent the group of symmetries implicitly
• Elementary group theory proves
• If redundant generators are avoided
• A group with N elements can be represented by at
  most log2(N) generators
• Generators provide exponential compression of
  solution space
