LISA

1
LISA

• A Mission to detect and observe Gravitational
  Waves

O. Jennrich, ESA/ESTECon behalf of the LISA
Science Team
2
What are Gravitational Waves?

• Gravitational waves are predicted by GR
  (Einstein, 1915)
• Propagate with the speed of light
• Quadrupole waves, two polarisations
• Bondi (1957) GW are physical, i.e. they carry
  energy, momentum and angular momentum
• Small coupling to matter, hence almost no
  absorption or scattering in the Universe
• Small amplitude, small effects
• Ideal tool to observe
• distant objects
• centre of galaxies
• Black Holes
• early Universe

3
Sources of GW

• Any mass distribution that is accelerated in a
  non-spherical symmetric way (waving hands,
  running trains, planets in orbit,)
• Large masses necessary
• Neutron star binary system, Black Holes,

4
Hulse-Taylor Binary PSR191316

• Observed loss of energy matches prediction of GW
  emission to betterthan 0.3
• Indirect evidence of gravitational waves
• Outside any detector band

5
The Effect of a Gravitational Wave
? GW change the distance between free-falling
test masses
6
What are the sources?

• Useful frequency range stretches over 8 decades

• Asymmetrical collapse of a supernova core

• Coalescence of compact binary systems (NS-NS,
  NS-BH)

• Inspiralling white dwarf binaries

• Compact binaries (early evolution)

• BH formation, BH-BH coalescence, BH binaries

• Ground based detectors observe in the audio band

• Only a space borne detector can overcome the
  seismic barrier

7
LISA Verification Binaries

• Galactic binaries (100pc 1000pc)
• Instrument verfication sources
• Guranteed detection!

8
LISA Verification Binaries
9
At the Edge of a Black Hole

• Capture by Massive Black Holes
• By observing 10,000 or more orbits of a compact
  object as it inspirals into a massive black hole
  (MBH), LISA can map with superb precision the
  space-time geometry near the black hole
• Allows tests of many predictions of General
  Relativity including the no hair theorem

10
Evidence for Black Holes

• Stellar motions in the vicinity of Sgr A.
• The orbital accelerations of stars close to the
  Galactic centre allow placing constraints on the
  position and mass of the central supermassive
  black hole

11
Mergers of Massive Black Holes

• Massive black hole binaries produce gravitational
  waves in all phases of their evolution
• Signal-to-noise of 1000 or more allows LISA to
  perform precision tests of General Relativity at
  ultra-high field strengths

12
Evidence for (S)MBH binaries

• During the collision of Galaxies MBH will interact

• After merging, MBH binaries can exist

13
Evolution of (S)MBH binaries
14
Evolution of (S)MBH binaries
15
Evolution of (S)MBH binaries
16
Evolution of (S)MBH binaries
17
Evolution of (S)MBH binaries
18
Evolution of (S)MBH binaries
19
Evolution of (S)MBH binaries
20
Evolution of (S)MBH binaries
21
Evolution of (S)MBH binaries
22
Evolution of (S)MBH binaries
23
Evolution of (S)MBH binaries
24
Evolution of (S)MBH binaries
25
Evolution of (S)MBH binaries
B Schutz (AEI)
26
GW from SMBH

• Time series of the GW amplitude

1022
h?
0
-10-22
1022
h
0
-10-22
S Hughes (CalTech)
27
LISA Science Goals

• Merging supermassive black holes
• Merging intermediate-mass/seed black holes
• Gravitational captures
• Galactic and verification binaries
• Cosmological backgrounds and bursts

• Determine the role of massive black holes in
  galaxy evolution
• Make precision tests of Einsteins Theory of
  Relativity
• Determine the population of ultra-compact
  binaries in the Galaxy
• Probe the physics of the early universe

K. Thorne (Caltech)
NASA, Beyond Einstein
NASA/CXC/MPE/S. Komossa et al.
28
LISA Mission Concept

• Cluster of 3 spacecraft in a heliocentric orbit
• Trailing the Earth by 20 (50 Million kilometer)
• Equilateral triangle with 5 Million kilometer arm
  length
• Inclined with respect to the ecliptic by 60

29
The LISA Orbit

• Constellation counter-rotates during the course
  of one year

30
The LISA Orbit
31
LISA layout

• Diffraction widens the laser beam to many
  kilometers
• 0.7 W sent, 70 pW received

reference laser beams
main transponded laser beams
32
LISA optical scheme

• one-way measurements
• Each received laser is individually recombined
  with a local laser
• Phasemeasurement occurs locally
• Additional measure-ments on the back-side of
  the proof masses

33
LISA layout

• Diffraction widens the laser beam to many
  kilometers
• 0.7 W sent, 70 pW received

reference laser beams

• Michelson with a 3rd arm, Sagnac
• Capable to distinguish bothpolarizations of a GW
• Orbital movementprovidesdirectionality

main transponded laser beams
34
Angular Resolution with LISA

• Using phase modulation due to orbital motion is
  equivalent to aperture synthesis
• Gives diffraction limit ?? ?/ 1 AU
• Measurements on detected sources - ?? 1
  1o - ?(mass,distance) ? 1

35
LISA layout
reference laser beams
main transponded laser beams

• Laser beams reflected off free-flying test
  masses

36
Ensuring free-fall
37
Ensuring free-fall
38
Ensuring free-fall
39
Ensuring free-fall
40
Ensuring free-fall
41
Ensuring free-fall
42
Ensuring free-fall
43
Ensuring free-fall
44
Ensuring free-fall
45
Ensuring free-fall
46
Ensuring free-fall
47
Ensuring free-fall
48
Ensuring free-fall
49
Ensuring free-fall
50
Ensuring free-fall

• Drag-free control ?10-15 m/(s2 ?Hz)
• Not truly drag-free, hence named DRS
• Needs tight control of
• Magnetic cleanliness
• Electro-static noise (patch field effect,
  charging, )
• Gravity gradient
• Ground tests can only demonstrate ?10-13 m/(s2
  ?Hz)
• LISA PF as technology demonstrator

51
LPF mission goals

• Demonstrate free-fall quality to 10-14 m/(s2 ?Hz)
• Demonstrate feasibility of performing laser
  interferometry as close as possible to 10-11
  m/?Hz
• Assess reliability and longevity of key
  components (thrusters, capacitive sensors,
  optics, lasers)

52
LISA PF Spacecraft
53
LPF orbit
54
LISA layout
55
Spacecraft Layout
56
Spacecraft Layout
57
Spacecraft Layout
58
Payload layout
59
Optical layout
60
LISA Interferometry

• Each beam (reference and main) is separately
  heterodyned with the local laser on a photodiode

• 12 signals 6 from the main beams plus 6 from
  the reference beams
• Beat signals from the reference beams are used
  to phase-lock the lasers in the same spacecraft
• Armlength changes slowly over a range of several
  1000 km per year due to orbital mechanics
• Fringe rate of several MHz makes interferometer
  self calibrating based on laser wavelength
• No calibration procedure necessary during
  operation
• Need Ultrastable Oscillator to remove Doppler
  shift before transmission to the ground
• USO transmitted as laser sideband (??2 GHz) to
  be stabilised on armlength

61
LISA Interferometry

• 18 beat signals
• 6 beat signals from main beams
• 6 beat signals from reference beams
• 6 beat signals from USO sideband signals
• Linear combinations of signals
• Cancel laser and USO noise and keep instrumental
  noise and the GW signal
• Cancel the GW signal and laser and USO noise and
  keeps the instrumental noise
• LISA can distinguish a stochastic gravitational
  wave background from instrumental noise

62
Instrumental Noise
Acceleration noise 10-15 m/(s2 ?Hz)Quality of
drag-free control, gravity gradient noise
Armlength penalty 5 Million kilometer

• Shot noise 70 pW ? 10-5 cycles/?Hz

63
LISA Launch and Cruise

• Delta IV launches all three spacecraft

• Each spacecraft is attached to its own propulsion
  module
• Propulsion Module ?V 1.22 km/sec
• Propulsion module incorporates a bipropellent (N2
  O4 / hydrazine) system and a Reaction Control
  System for attitude control

• 13 month cruise phase

64
Status of LISA today

• Proposed to ESA 1993, approved as a Cornerstone
  Mission 1996
• Collaborative ESA/NASA mission with a 50/50
  sharing ratio
• ESA Responsibility for the payload IT, 50 of
  the payload (nationally funded)
• NASA 3 S/C, launcher, ground segment (DSN),
  mission ops
• Science ops will be shared
• Data analysis by two independent teams (Europe
  and US)
• Launch foreseen in the 2012/2013 timeframe
• LISA PF in 2008
• Approved by ESAs SPC in June 04 (160 M)
• Europe LISA Technology Package (LTP)
• US Disturbance Reduction System (DRS)

65
