Title: HPSDR High Performance Software Defined Radio


1
HPSDRHigh Performance Software Defined Radio
  • Presentation by Kevin M0KHZ for WARC

2
OK so whats all this about
  • 1st youll be hearing a lot about this in the
    near future!
  • Tonight from me in the radio monthly
    periodicals
  • But what is it?
  • In my opinion ( many others) the future of
    amateur radio!

3
HPSDR
  • The HPSDR is an open source (GNU type) hardware
    and software project intended as a "next
    generation" Software Defined Radio (SDR) for use
    by Radio Amateurs.
  • It is being designed and developed by a group of
    SDR enthusiasts with representation from
    interested experimenters worldwide. The
    discussion list membership currently stands at
    over 200 and includes such SDR enthusiasts as
    Phil N8VB, Lyle KK7P, Bill KD5TFD, and Phil
    VK6APH.

4
Plug play
  • The rationale behind the project is to break the
    overall design up into a number of modules. Each
    module is designed by an individual or group and
    connects to other modules using a pre-defined and
    common bus -- rather like plugging boards into a
    PC motherboard.

5
Just like lego!
  • This modular approach enables perspective users
    to incorporate just the modules that interest
    them as well as designing their own variants if
    desired. The approach also enables new ideas and
    circuits to be tested by replacing an existing
    module. Since the majority of modules will be
    retained such experimentation can be done with
    minimum disruption to an existing, working system.

6
Block diagram
7
Open source design
  • In a "nutshell", open source is a term that is
    applied to a philosophy, in that the production
    and organization of a project or system is
    created through open and cooperative efforts
  • Open source software refers to computer software
    available with its source code and under an "open
    source license" to study, change and improve its
    design and functionality

8
Open source design
  • The users are treated like co-developers, are
    encouraged to submit additions to the software,
    code fixes, bug reports, documentation etc.
    Having more co-developers increases the rate at
    which the software evolves. Furthermore, each end
    user's machine provides an additional testing
    environment. This new testing environment offers
    the ability to find and fix a new bug quickly
  • This GPL philosophy extends to the hardware for
    this HPSDR cooperative project

9
Rapid development, excited times
  • For the very latest scoop, join the HPSDR
    discussion list (reflector). You'll find
    information on the http//hpsdr.org website on
    how to subscribe to this email list

10
ATLAS - Backplane
  • The Atlas is a passive backplane that all other
    modules plug into. The circuit board has
    provision for up to six DIN41612 connectors at
    0.8 inch spacing. An ATX 20 pin power connector
    can be placed on the board so that 12v, 5v, 3.3v
    etc. supplies from a standard PC power supply can
    be used to power the system
  • The DIN connector spacing and board size have
    been chosen such that the backplane can be fitted
    into a standard PC enclosure.

11
So what does it look like
12
Current Status
  • In late May, the first production order for 400
    boards was sent out. The cost of the bare board
    for this run will be 10 plus shipping. Shipment
    is expected in mid-June.
  • Be aware that these boards are NOT an assembled
    unit. They are only bare boards and the purchaser
    will need to buy the DIN connectors and other
    parts to populate the board, and will need to
    manage the assembly of the Atlas.

13
JANUS - ADC/DAC Board
  • The Janus module is a very high performance,
    dual, full duplex, A/D and D/A converter board
  • While the M-Audio Delta 44 has become the
    de-facto standard for A/D sound cards for use
    with a SDR, there are a number of advantages to
    rolling your own. These include having complete
    control of any software drivers needed to
    communicate with the A/D chips as well as
    optimization of sampling rates and bit depths for
    individual signals. It's also possible to cost
    effectively develop a board which approaches the
    performance of professional high end sound cards.

14
ADC bake off
  • The results of the ADC bake-off are in and the
    AK5394A is the clear winner for our particular
    application due to its flat noise floor at 192kps
  • The measured figures of the prototype Janus using
    the AK5394A are
  • Noise Floor -160dBm (in an 11Hz FFT bandwidth)
    Dynamic Range 120dB
  • Extremely impressive!

15
A photograph of the first assembled Alpha board
16
OZYmandias - HPSDR Host Interface Control
  • The OZY module is an FPGA based interface
    controller card that provides the input and
    output connections to the real world. The use of
    an Altera Cyclone II FPGA provides numerous
    control lines for interfacing the various boards
    connected to the Atlas backplane
  • OZY also provides a high speed USB 2.0 interface
    to the controlling PC
  • The FPGA also provides the necessary control
    logic and data formatting for the Janus board as
    well serial and parallel interfaces for user
    defined I/O.

17
Additional features
  • One highly desirable feature of the OZY board
    will be the ability to measure the various high
    frequency crystal oscillators used by the HPSDR
    by using the 1 pps clock from a GPS receiver. The
    GPS clock will be used to gate the various
    oscillators and report the count to the PC via
    the USB interface. Since the PC will have prior
    knowledge of exactly what these frequencies
    should be, then any errors can be corrected in
    software. The result will be a radio with
    extremely high frequency accuracy and stability
    -- a boon for microwave operators.

18
Proposed board layout for Ozy
19
MERCURY - 0-30MHz Direct Sampling Receiver
  • Perhaps the most exciting of all the modules, the
    Mercury board will enable direct sampling of the
    0-65MHz spectrum. Based on a Linear Technology
    LTC2208 130MSPS 16-bit A/D converter, the board
    will contain it's own FPGA to undertake Digital
    Down Conversion (DDC) to 250 kSPS or less for
    transfer over the Atlas bus to the USB interface
    on the OZY board.
  • Full HF spectum analyser!

20
MERCURY development environment
21
SASQUATCH - DSP back-end
  • The Sasquatch board is a hardware DSP back-end
    intended for use by constructors who would like
    to operate the HPSDR stand-alone rather than
    attached to a PC. The board may even allow real
    "knobs" and "buttons" to be attached rather that
    the "soft" controls of a PC based SDR
  • The board, presently in the planning phase, has
    the following features
  • - TI TMS320C6726 32-bit Floating Point DSP-
    FPGA- Flash Memory for self-booting- Connector
    for JTAG-based emulator- Analog digital I/O-
    Power consumption should be under 1 watt

22
From Lyle KK7P
  • Sasquatch initially will use an Actel Flash-based
    FPGA. Not merely to be different Lyle would
    normally use an Altera part for consistency with
    the rest of the project -- but because the board
    is really a prototyping/development board for the
    AMSAT (www.amsat.org) Software Defined
    Transponder (SDX). In space, RAM-based FPGAs,
    like the Altera, have to be constantly monitored
    to prevent single-event upsets (SEU) from
    reconfiguring the logic. Flash based parts are
    not nearly as susceptible.

23
GIBRALTAR - GPS-disciplined Frequency Standard
  • Work has already started on a PCB that integrates
    the GPS, Reflock II, and 10 MHz OCXO (Steve,
    N7HPR is looking at the Crystek
    CO27VH15DE-12-10.000.
  • The goal is to design the board such that all the
    parts can be readily purchased. Not relying on
    surplus GPSs and OCXOs.
  • This entire lash up will be tested in N8UR's
    timing lab. The GPS footprint would accomidate
    the Oncore UT/VP and M12 GPSs.
  • So if you can populate which ever one you have on
    hand, purchase a new M121M.

24
PROTeus - Prototyping Board
  • Discussions are ongoing about the need for a
    prototyping board. Besides plenty of through hole
    pads, it would be nice to have some common SMT
    pads on there too.
  • This would aid breadboarding future inhancements
    / developing your own ideas

25
HORTON - Receiver Module
  • Proposed name for a receiver module integrating
    the Janus ADC with a QSD on a board for a version
    of the HPSDR RX board.
  • Also under consideration for use in the HORTON is
    the Analog Devices AD7760 a 24 Bit 2.5 MSPS ADC
    with DDC performed in a Cyclone II FPGA. Under
    consideration for use in a QSD is an Analog
    Devices RF ADG901 Analog Switch in absorptive
    mode configured as a current mode I/Q mixer.

26
Horton
27
PINOCCHIO - Extender Card
  • Pinocchio is an extender card to allow
    measurements and troubleshooting of an active
    card in an ATLAS backplane. Test points are
    provided to allow access to every backplane
    signal, and the test points are located well
    above the standard module height.

28
PINOCCHIO
29
CASMIR - 0MHz to 2.5GHz Transmitter Card
  • CASMIR is a transmitter card with two versions
    HF - 0MHz-30MHz VHF/UHF - 50MHz-2400MHz remote
    port for tower mounting

30
HF CASMIR
  • Output bandpass filters from Amplitronix and
    Sawtek/TriQuint are being studied. Local
    Oscillators would be generated from the 10MHz
    reference on the ATLAS bus.

31
VHF/UHF CASMIR
  • The design is using the Analog Devices modulators
    or vector multipliers. Output bandpass filters
    from Amplitronix and Sawtek/TriQuint are being
    studied. Local Oscillators would be generated
    onboard the MAX II FPGA from the 10MHz reference
    on the ATLAS bus.

32
CASMIR SYSTEM REQUIREMENTS
  • CASMIR shall support transmitter frequency
    coverage from 0 MHz to 24GHz
  • CASMIR shall support a frequency stability of
    better than 1 part in 109 over a 24 hour
    average
  • CASMIR shall have an amplitude stability of /-
    0.5 dB
  • CASMIR shall have defined power outputs over the
    defined frequency coverage
  • CASMIR shall support a load impedance of 50 ohms
  • CASMIR shall support a signal to noise ratio of
    100 dB
  • CASMIR shall create spurs no greater than 100 dB
  • CASMIR shall support a frequency lock-up time of
    20ms
  • CASMIR shall support adjustment of frequency
    while transmitting
  • CASMIR shall support frequency resolution of 1Hz

33
PC User interface
34
Has that wetted your appetite?
  • For the very latest scoop, join the HPSDR
    discussion list (reflector). You'll find
    information on the http//hpsdr.org website on
    how to subscribe to this email list
