Introduction to Geographic Information Systems GIS

1
Introduction to Geographic Information Systems
(GIS)
Note this presentation includes material from
Dr. Dionne Law, Dr. Marc Serre, and others.
2
Organization of presentation

• History of GIS
• Basics of GIS
• GIS Approaches to Investigations
• Limitations
• GIS data at the New Jersey Department of
  Environmental Protection

3
Part I History of GIS
4
History of GIS

• Battle of Yorktown
• French cartographer had hinged overlays to show
  troop movements
• Irish Railway Commission (mid 1800s)
• Atlas showing overlay of population, traffic
  flow, geology, topography on same base map
• John Snows Cholera Investigation

5
John Snows Cholera Investigation
6
History of GIS
7
History of GIS
8
History of GIS
9
Summary

• GIS has been around a long time
• Well established tool in cartography, land
  resources, geography, earth sciences, ecology,
  planning, business, many other fields
• Only recently has GIS been discovered by Public
  Health

10
Part II Basics of GIS
11
Geographic Information Systems (GIS)

• GIS facilitates visualization and analysis of
  spatial data
• Spatial data are stored in map layers

12
Coordinate Systems

• Spatial data are referenced to locations on the
  earths surface using coordinate systems
• Ensure all map layers share a common coordinate
  system
• Recognized global coordinate systems consist of
• A Spheriod a mathematical description of the
  earths shape
• A Map Projection a mathematical conversion from
  spherical to planar coordinates

13
Map Projection
14
Map Projection
15
Scale

• Tells how map distance relates to real world
  distance
• Map Scale ratio of map distance to actual
  ground distance
• 110,000 (1 map cm 10,000 real cm)
• Small scale (1100) vs. large scale (110)
• Scale Bar graphic display of map scale

16
Resolution

• The accuracy with which a given map scale can
  depict the location and shape of map features
• Larger the map scale, the higher the resolution
• As map scale decreases, resolution diminishes and
  feature boundaries are smoothed, simplified, or
  not shown at all.
• Rule of thumb error 2 of map scale
• Resolution plays a large role in GIS, especially
  in raster-based modeling

17
Raster-based GIS

• Data stored in a regularized grid of cells
  covering an area
• Grid cells called picture elements or pixels
• Nodes, Arcs, Areas

18
Vector-based GIS

• Image and data stored separately
• Data attribute table
• Image points, lines, polygons

19
Summary

• GIS facilitates visualization and analysis of
  spatial data
• Spatial data are stored in map layers
• Most GIS programs are raster- or vector- based
• Raster - data and image stored together in
  regularized grid made of pixels
• Vector - data and image stored separately
  points, lines and polygons

20
Part III GIS Approaches Investigations
21
Approaches to GIS

• Step 1 Define the question
• Step 2 Determine data needs
• Step 3 Collect and prepare data
• Step 4 Analyze data

22
Step1 Define the Question

• What areas are vulnerable to a 100 year flood?
• How many people live in these areas?
• Where do we need to implement locally based flood
  mitigation efforts?

23
Step 2 Determine data needs

• What map layers are needed?
• population estimates, streets, census tracts,
  county, digital elevation model, land cover, 100
  year floodplain, flood control data, climatic
  data?
• What data is already available?
• population estimates, streets, census tracts,
  county, digital elevation model, land cover, 100
  year floodplain?, remote sensing data?
• What data needs to be collected, or digitized?
• historic flood damage, flood control and
  mitigation data, location of emergency services

24
Step 3 Prepare spatial data

• Existing digital data
• complete, clean, up-to-date, formatted,
• share common projection and coordinate system
• pieced together, clipped
• New digital data
• geocoding damage address matching, GPS
• digitizing
• manipulate existing data

25
Step 4 Data Analysis

• Manipulation
• Clip and paste together area of interest
• Construct watershed from digital elevation models
• Construct drainage/river network

• Overlays
• Superimpose two or more map layers
• For display and analysis purposes
• Overlay census data with floodplain data

26
Step 4 Data Analysis

• Buffers
• Identify areas 5km, 10km, 15km from river network

• Queries
• Estimate potential number of people living in
  high flood risk areas

27
Step 4 Data Analysis

• Network Analysis
• Construct evacuation routes
• Estimate travel times for emergency response
  vehicles

• Modeling
• prediction storm path
• estimation damage estimates for structures and
  infrastructure
• simulation emergency preparedness

28
(No Transcript)
29
Summary

• GIS can enhance emergency preparedness and
  response locally, nationally, globally
• Strengthen data collection, management and
  analysis
• Monitor changes over time
• Develop early warning systems
• Plan and monitor response programs
• Communicate to decision makers and the public

30
Part IV Limitations
31
Three good rules to follow

• Never assume a spatial database is free of error.

• Develop methods for assessing data quality
  whenever possible.
• Always get the metadata file.
• - describes content and quality of spatial
  database

32
Limitations

• Accuracy and completeness
• spatial data
• non-spatial data
• Currency of data
• When were the data collected?
• Last updated?
• Time sensitive?
• Appropriate for the analysis?

33
Limitations (continued)

• Geocoding
• Address matching
• urban vs. rural environments
• Representation of disease
• residential address vs. social location
• Precision
• Scale of source map
• Modifiable Area Unit Problem
• spatial distribution of a factor changes
  significantly depending on how it is aggregated
• census tract vs. zip code vs. county

34
Limitations (continued)

• Disease etiology
• Proximity vs. exposure
• Confidentiality
• Use smaller-scale maps
• Remove the street network on the map
• Displace point features

35
Summary

• Need to be aware of the sources of error and
  limitations associated with GIS.
• However
• Errors can be minimized
• Most limitations are function of data available,
  not GIS

36
Conclusion

• GIS is an investment
• hardware, software, and know-how costs
• GIS is a powerful multidisciplinary tool that
  presents opportunities for collaborations and
  coordination between government, academia,
  industry, and the public

37
Part VGIS data at the New Jersey Department of
Environmental Protection
38
New Jersey Department of Environmental Protection

• NJDEP
• http//www.nj.gov/dep/
• NJDEP - GIS
• http//www.nj.gov/dep/gis/
• NJDEP - Water Monitoring Standards
• http//www.state.nj.us/dep/wmm/
• NJDEP - Water Monitoring Standards Bureau of
  freshwater biological monitoring
• http//www.state.nj.us/dep/wmm/bfbm/

39
NJDEP - GIS

• The NJDEP GIS Department (http//www.nj.gov/dep/
  gis/)
• provides GIS files for state administrative
  areas, hydrology, geology, land use, etc., such
  as
• Counties
• Digital Elevation Grid
• Hydrography
• Watersheds
• Water Quality Monitoring Stations

40
NJDEP - Water Monitoring Standards

• The NJDEP Office of Water Monitoring Standards
• (http//www.state.nj.us/dep/wmm/)
• oversees the Bureau of Fresh Water and Biological
  Monitoring .
• This bureau is in charge of monitoring the
  ambient conditions of the state's fresh and
  ground water resources. This monitoring includes

• regular sampling through a statewide network
  consisting of 115 surface water monitoring
  stations,
• 820 benthic macroinvertebrate biological stream
  monitoring stations,
• 100 fish assemblage biological stream monitoring
  stations, and
• 150 ground water stations.

41
The Raritan Basin in New Jersey
54 Monitoring Stations Across 3 Watershed
Management Areas
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
Water quality data for the Raritan river basin

• Monitoring Station Data was gathered for 3
  Watershed Management Areas (WMA)
• N/S Branch Raritan (8)
• Lower Raritan (9)
• Millstone (10)
• Dataset was obtained from two sources
• NJ DEP/USGS Water Quality Network1
• EPA STORET Database2
• Dataset contains 6 water quality parameters
• Discharge, Dissolved Oxygen, Ammonia,
  NitrateNitrite, Phosphate, Temperature
• Additional Parameters can be added as needed
• Measurements were taken approximately 4
  times/year from 1990-2002
• Values were log-transformed depending on
  distribution

1http//waterdata.usgs.gov/nj/nwis/qw
2http//www.epa.gov/STORET
46
Phosphate data (mg/L) over the Raritan
The movie of the data illustrate its space/time
variability
47
Challenges

• Sparse network of monitoring sites
• Monitoring data may have varying measurement
  errors
• High variability of the data over space and time
• The relevant spatial distance metric is a
  combination across land and along river
  metric
• Limited resources prevents use of deterministic
  water quality models, but a stochastic version
  may provide useful knowledge

48
Conclusion

• In the State of New Jersey, GIS provides a set of
  basic functions allowing to query and extract
  monitoring data with health concerns. The arcGIS
  software will provide the necessary basic
  functions of GIS.
• The monitoring data varies over space and time,
  therefore we need advanced functions of Temporal
  GIS to map their distribution at unsampled
  locations. The BMElib software of space/time
  Geostatistics will provide the necessary advanced
  functions of Temporal GIS

49
ESRI arcGIS at UNC

• UNC GIS software includes ESRI arcGIS version
  9.0, 9.1, 9.2
• Technical Support http//www.unc.edu/atn/gis
• research_at_unc.edu (919) 962-HELP
• Data Sources http//gis.unc.edu/
• Amanda C. Henley, GIS Librarian
  amanda.henley_at_unc.edu [phone]
