Training Neural Networks

1
Training Neural Networks

• Robert Turetsky
• Columbia University rjt72_at_columbia.edu
• Systems, Man and Cybernetics Society
• IEEE North Jersey Chapter
• December 12, 2000

2
Objective

• Introduce fundamental concepts in Artificial
  Neural Networks
• Discuss methods of training ANNs
• Explore some uses of ANNs
• Assess the accuracy of artificial neurons as
  models for biological neurons
• Discuss current views, ideas and research

3
Organization

• Why Neural Networks?
• Single TLUs
• Training Neural Nets Back propagation
• Working with Neural Networks
• Modeling the neuron
• The multi-agent architecture
• Directions and destinations

4
Why Neural Networks?
5
The Von Neumann architecture

• Memory for programs and data
• CPU for math and logic
• Control unit to steer program flow

6
Von Neumann vs. ANNs
Von Neumann
Neural Net

• Follows Rules
• Solution can/must be formally specified
• Cannot generalize
• Not error tolerant

• Learns from data
• Rules on data are not visible
• Able to generalize
• Copes well with noise

7
Circuits that LEARN

• Three types of learning
• Supervised Learning
• Unsupervised Learning
• Reinforcement Learning
• Hebbian networks reward good paths, punish
  bad paths
• Train neural net by adjusting weights
• PAC (Probably Approximately Correct) theory
  Kerns Vazirani 1994, Haussler 1990

8
Supervised Learning Concepts

• Training set ? Input/output pairs
• Supervised learning because we know the correct
  action for every input in ?
• We want our Neural Net to act correctly in as
  many training vectors as possible
• Choose training set to be a typical set of inputs
• The Neural net will (hopefully) generalize to all
  inputs based on training set
• Validation Set Check to see how well our
  training can generalize

9
Neural Net Applications

• Miros Corp. Face recognition
• Handwriting Recognition
• BrainMaker Medical Diagnosis
• Bushnell Neural net for combinational automatic
  test pattern generation
• ALVINN Knight Rider in real life!
• Getting rich LBS Capital Management predicts the
  SP 500

10
History of Neural Networks

• 1943 McCullough and Pitts - Modeling the Neuron
  for Parallel Distributed Processing
• 1958 Rosenblatt - Perceptron
• 1969 Minsky and Papert publish limits on the
  ability of a perceptron to generalize
• 1970s and 1980s ANN renaissance
• 1986 Rumelhart, Hinton Williams present
  backpropagation
• 1989 Tsividis Neural Network on a chip

11
Threshold Logic Units

• The building blocks of
• Neural Networks

12
The TLU at a glance

• TLU Threshold Logic Unit
• Loosely based on the firing of biological neurons
• Many inputs, one binary output
• Threshold Biasing function
• Squashing function compresses infinite input into
  range of 0 - 1

13
The TLU in Action
14
Training TLUs Notation

• ? Threshold of TLU
• X Input Vector
• W Weight Vector
• s X Wie if s ? ?, op 1 if s lt ?, op
  0
• d desired output of TLU
• f output of TLU with current X and W

15
Augmented Vectors

• Motivation Train threshold ? at the same time as
  input weights
• X ? W ? ? is the same as X ? W - ? ? 0
• Set threshold of TLU 0
• Augment W W w1, w2, wn, -?
• Augment X X x1, x2, .. xn, 1
• New TLU equation X W ? 0(for augmented X and
  W)

16
Gradient Descent Methods

• Error Function How far off are we?
• Example Error function
• ? depends on weight values
• Gradient Descent Minimize error by moving
  weights along the decreasing slope of error
• The Idea iterate through the training set and
  adjust the weights to minimize the gradient of
  the error

17
Gradient Descent The Math

• We have ? (d - f)2
• Gradient of ?
• Using the chain rule
• Since , we have
• Also
• Which finally gives

18
Gradient Descent Back to reality

• So we have
• The problem ?f / ?s is not differentiable
• Three solutions
• Ignore It The Error-Correction Procedure
• Fudge It Widrow-Hoff
• Approximate it The Generalized Delta Procedure

19
Training a TLU Example

• Train a neural network to match the following
  linearly separable training set

20
Behind the scenes Planes and Hyperplanes
21
What can a TLU learn?
22
Linearly Separable Functions

• A single TLU can implement any Linearly separable
  function
• AB is Linearly separable
• A ? B is not

23
NEURAL NETWORKS

• An Architecture for Learning

24
Neural Network Fundamentals

• Chain multiple TLUs together
• Three layers
• Input Layer
• Hidden Layers
• Output Layer
• Two classifications
• Feed-Forward
• Recurrent

25
Neural Network Terminology
26
Training ANNs Backpropagation

• Main Idea distribute the error function across
  the hidden layers, corresponding to their effect
  on the output
• Works on feed-forward networks
• Use sigmoid units to train, and then we can
  replace with threshold functions.

27
Back-Propagation Birds-eye view

• Repeat
• Choose training pair and copy it to input layer
• Cycle that pattern through the net
• Calculate error derivative between output
  activation and target output
• Back propagate the summed product of the weights
  and errors in the output layer to calculate the
  error on the hidden units
• Update weights according to the error on that
  unit
• Until error is low or the net settles

28
Back-Prop Sharing the Blame

• We want to assign
• Wij weights of i-th sigmoid in j-th layer
• Xj-1 inputs to our TLU (outputs from previous
  layer)
• cij learning rate constant of i-th sigmoid in
  j-th layer
• ?ij sensitivity of the network output to
  changes in the input of our TLU
• Important equation

29
Back-Prop Calculating ?ij

• For the output layer ?ij ?k
• ?ij ?k (d-f)?f/ ?sk
• ?ij (d-f)f(1-f) for sigmoid
• Therefore Wk lt- Wk ck (d - f) f (1 -f ) Xk-1
• For the hidden layers
• See Nilsson 1998 for calculation
• Recursive Formula base case ?k (d-f)f(1-f)

30
Back-Prop Example

• Train a 2-layer Neural net with the following
  input
• x10 1, x20 0, x30 1, d 0
• x10 0, x20 0, x30 1, d 1
• x10 0, x20 1, x30 1, d 0
• x10 1, x20 1, x30 1, d 1

31
Back-Prop Problems

• Learning rate is non-optimal
• One solution Learn the learning rate
• Network Paralysis Weights grow so large that
  fij(1-fij) --gt 0, and the net never learns
• Local Extrema Gradient Descent is a greedy
  method
• These problems are acceptable in many cases, even
  if workarounds cant be found

32
Back-Prop Momentum

• We want to choose a learning rate that is as
  large as possible
• Speed up convergence
• Avoid oscillations
• Add momentum term dependent on past weight
  change

33
Another Method ALOPEX

• Used for visual receptive field mapping by
  Tzanakou and Harth,1973
• Originally developed for receptive field mapping
  in the visual pathway of frogs
• The main ideas
• Use cross-correlation to determine a direction of
  movement in gradient field
• Add a random element to avoid local extrema

34
WORKING WITHNEURAL NETS

• AI the easy way!

35
ANN Project Lifecycle

• Task identification and design
• Feasibility
• Data Coding
• Network Design
• Data Collection
• Data Checking
• Training and Testing
• Error Analysis
• Network Analysis
• System Implementation

36
ANN Design Tradeoffs

• A good design will find a balance between these
  two extremes!

37
ANN Design Balance Depth

• Too few hidden layers will cause errors in
  accuracy
• Too many errors will cause errors in
  generalization!

38
CLICK!

• Modeling the neuron

39
Wetware Biological Neurons
40
The Process Neuron Firing

• Each electrical signal received at a synapse
  causes neurotransmitter release
• The neurotransmitter travels along the synaptic
  cleft and received by the other neuron at a
  receptor site
• Post-Synaptic-Potential (PSP) either increases
  (hyperpolarizes) or decreases (depolarizes) the
  polarization of the post-synaptic membrane (the
  receptors)
• In hyperpolarization, the spike train is
  inhibited. In depolarization, the spike train is
  excited.

41
The Process Part 2

• Each PSP travels along the dendrite of the new
  neuron, and spreads itself over the cell body
• When the effects of the PSP reaches the
  axon-hillock, it is summed with other PSPs.
• If the sum is greater than a certain threshold,
  the neuron fires a spike along the axon
• Once the spike reaches the synapse of an efferent
  neuron, the process starts in that neuron

42
The neuron to the TLU

• Cell Body (Soma) accumulator plus its threshold
  function
• Dendrites inputs to the TLU
• Axon output of the TLU
• Information Encoding
• Neurons use frequency
• TLUs use value

43
Modeling the Neuron Capabilities

• Humans and Neural Nets are both
• Good at pattern recognition
• Bad at mathematical calculation
• Good at compressing lots of information into a
  yes/no decision
• Taught via training period
• TLUs win because neurons are slow
• Wetware wins because we have a cheap source of
  billions of neurons

44
Do ANNs model neuron structures?

• No Hundreds of types of specialized nerons, only
  one TLU
• No Weights to neural threshold controlled by
  many neurotransmitters, not just one
• Yes Most of the complexity in the neuron is
  devoted to sustaining life, not information
  processing
• Maybe There is no real method for
  backpropagation in the brain. Instead, firing of
  neurons increases connection strength

45
High Level Agent Architecture

• Our minds are composed of a series of
  non-intelligent agents
• The hierarchy, interconnections, and interactions
  between the agents creates our intelligence
• There is no one agent in control
• We learn by forming new connections between
  agents
• We improve by dealing with agents at a higher
  level, ie creating mental scripts

46
Agent Hierarchy Playing with Blocks
From the outside, Builder knows how to build
towers. From inside, Builder just turns on other
agents.
47
How We Remember K-Line Theory
48
New Knowledge Connections

• Sandcastles in the sky Everything we know is
  connected to everything else we know
• Knowledge is acquired by making connections new
  between things we already know

49
Learning Meaning

• Uniframing Combining several descriptions into
  one
• Accumulating Collecting incompatible
  descriptions
• Reformulating modifying a descriptions
  character
• Transforming bridging between structures and
  functions or actions

50
The Exception Principle

• It rarely pays to tamper with a rule that nearly
  always works. It is better to complement it with
  an accumulation of exceptions
• Birds can Fly
• Birds can fly unless they are penguins and
  ostriches

51
The Exception Principle Overfitting

• Birds can fly, unless they are penguins and
  ostriches, or if they happen to be dead, or have
  broken wings, or are confined to cages, or have
  their feet stuck in cement, or have undergone
  experiences so dreadful as to render them
  psychologically incapable of flight
• In real thought, finding exceptions to everything
  is usually unnecessary.

52
Minskys Princples

• Most new knowledge is simply finding a new way to
  relate things we already know
• There is nothing wrong with circular logic or
  having imperfect rules
• Any idea will seem self-evident... once youve
  forgotten learning it.
• Easy things are hard Were least aware of what
  our minds do best

53
TO THE FUTURE AND BEYOND

• Why you should be nice
• to your computer

54
Im lonely and Im bored.Come play with me!
55
Computers are Dumb

• Deep Blue might be able to win at chess, but it
  wont know to come in from the rain.
• Computers can only know what theyre told, or
  what theyre told to learn
• Computers lack a sense of mortality and a
  physical self with which to preserve
• All of this will change when computers can reach
  consciousness

56
I, Silicon Consciousness

• Kurzweil By 2019, a 1000 computer will be
  equivalent to the human brain.
• By 2029, machines will claim to be conscious. We
  will believe them.
• By 2049, nanobot swarms will make virtual reality
  obsolete in real reality.
• By 2099, man and machine will have completely
  merged.

57
You mean to tell me?????

• We humans will gradually introduce machines into
  our bodies, as implants
• Our machines will grow more human as they learn,
  and learn to design themselves
• The Neo-Luddite scenarios
• AI succeeds in creating conscious beings. All
  life is at the mercy of the machines.
• Humans retain control workers are obsolete. The
  power to decide the fate of the masses is now
  completely in the hands of the elite.

58
Neural Networks Conclusions

• Neural Networks are a powerful tool for
• Pattern recognition
• Generalizing to a problem
• Machine learning
• Training Neural Networks
• Can be done, but exercise great care
• Still has room for improvement
• Understanding and creating consciousness?
• Still working on it )
