Powertrains Differential Applications

1
PowertrainsDifferential Applications

• By Lauren Graham

2
Objective

• To expand your understanding of the
• differentials function within the powertrain
• and what its used for.

3
Powertrain
Dictionary Def An assembly of gears and
associated parts by which power is transmitted
from an engine to a driving axle.
Made up of

• Differential
• Transmission
• Engine
• Drive Shaft
• Wheels

4
Differential
Functions

• Engine power to wheels
• Gear reduction
• Changes rotation speed of tires
• Reduces strain on vehicle

5
Application

• different types of differentials are ideal for
  different situations
• Most everyday automobiles use open differentials
• O ff-roading uses limited slip differentials
• Racing uses limited slip differentials

6
References
http//www.plastics-car.com/s_plasticscar/sec_inne
r.asp?CID480DID1426
http//dictionary.reference.com/search?r2qpower
20train
http//auto.howstuffworks.com/differential7.htm
http//web.mit.edu/2.972/www/reports/differential/
differential-2.gifimgrefurl/
http//www.scania.com/about/environment/powertrain
/
