Pushing the Envelope: Planning, Propositional Logic, and Stochastic Search

1
Pushing the Envelope Planning, Propositional
Logic, and Stochastic Search

• By Henry Kautz and Bart Selman of ATT
  Laboratories.
• Presentation by Richard Smiley.

2
First, some definitions

• Propositional logic I have a ladder and Im at
  my house.
• Stochastic search A random, but directed search
  (more detail to come).
• Fluent A time-varying condition, such as the
  location of a box.
• SAT Propositional satisfiability problem.
• These problems scale much better than First-Order
  Logic problems.

3
Simulated Annealing

• An example of Stochastic Search
• Simulated Annealing exploits an analogy between
  the way a metal cools and freezes into a minimal
  energy crystalline structure (the annealing
  process) and the search for a minimised goal
  state in a search process.
• Unlike hill-climbing approaches (which always
  follow a steady descent in minimization
  problems), SA is much less likely to become
  trapped in local minima.
• The SA algorithm employs a random search that not
  only accepts changes that decrease the energy
  function (as expected this function might
  represent the cost of a trip between two cities,
  say), but also some changes that increase the
  function value, thus allowing SA to jump out of
  local minima.

Copied from http//www.compapp.dcu.ie/tonyv/CA3-A
I/AI-Lectures/ai3.rtf
4
A New Style of Encoding

• Include time in the operators
• pickup(A,3)
• each action takes 1 tick on the clock. Action
  will be finished at time 4.
• on(A,B,3)
• whether A is on B at time 3.
• Before execution, the length is determined by a
  binary search of execution possibilities.
• If optimal plan is of length 7, search proceeds
  through plans of length 2, 4, 8 (plan found), 6
  (no plan found), and finally 7.

5
A Little More on SAT Encoding

• Compiler takes plan, guesses a plan length, and
  generates a propositional logic formula.
• Simplifier uses various techniques to shrink the
  CNF forumula.
• Solver uses systematic or stochastic methods to
  find an assignment, which the decoder turns into
  a solution plan.

6
Representing Arbitrary Constraints

• pickup(x,i) ??y.stack(x,y,i1)
• Every pickup is immediately followed by a stack.
• clear(x,i)?y.on(y,x,i)
• Saying x is clear is equivalent to saying that
  there doesnt exist any y that is on x.

7
Encoding Problems The Graphplan Method

• Graphplan works by converting a STRIPS-style
  specification into a planning graph.
• A solution is a subset of the planning graph that
  contains both the start and goal conditions, and
  contains no two operators in the same level that
  conflict.
• Each fact at layer i implies the disjunction of
  all the operators at level i-1 that have it as an
  add-effect.
• in(A,R,3)?(load(A,R,L,2)?load(A,R,P,2)?maintain(in
  (A,R),2))
• Operators imply their preconditions.
• load(A,R,L,2)?(at(A,L,1)?at(R,L,1))
• Conflicting actions are mutually exclusive
• load(A,R,L,2)?move(R,L,P,2)

8
A Sample Graph
9
Linear Encodings

• An action implies both its preconditions and
  effects
• Exactly one action occurs at each time instant
• The initial state is completely specified
• Classical frame conditions (if an action doesnt
  change the truth condition of a fact, then the
  fact remains true or remains false when the
  action occurs)
• Replace predicates that take 2 or more arguments
  (plus a time argument) with ones that take a
  single argument (plus time).
• move(x,y,z,i)(object(x,i)?source(y,i)?destination
  (z,i)
• Yields O(3n²) propositions rather than O(n4)

10
(No Transcript)
11
State-Based Encodings

• Has the advantages of the previous two encodings,
  plus some extra refinements
• (in(x,y,i)?in(x,y,i1))??z.load(x,y,z,i)
• (in(a,r,2)?in(a,r,3))?(load(a,r,l,2)?
  load(a,r,p,2))
• So far, this hasnt helped anything. But now,
  the states have some built-in consistency checks.
  We can eliminate propositions and simplify
  axioms to the point that we can completely
  eliminate propositions that refer to actions, so
  that only fluents are used.

12
Now, instead of the load axioms, we have

• at(obj,loc,i) ? at(obj,loc,i1)
  ??x?truck?airplane. in(obj,x,i1)? at(x,loc,i)?
  at(x,loc,i1)
• In English If an object is at a location, it
  either remains at that location or goes into some
  truck or plane that is parked at that location.
• This replaces load-airplane and load-truck.
• This method also eliminates the need for
  drive-truck and fly-airplane. State validity
  checks make these happen automatically.

13
Benefits of State-Based Encoding

• A solution to a problem is a sequence of states.
• The missing actions are derived from the gaps
  between states. Finding them is easy it only
  involves finding an unordered plan of length 1.
• Can solve state-based encodings of problems that
  no other domain-independent planner can solve.
• No explicit frame axioms, preconditions, or
  conflicts everything is represented in relations
  between fluents.

14
The Results

• Both Systematic and Stochastic methods used for
  testing the encodings.
• Systematic Tableau, one of the fastest and most
  complete SAT procedures.
• Stochastic Walksat, a randomized greedy local
  search
• Method Pick a random truth assignment, and flip
  the variable that minimizes the number of clauses
  that are satisfied by the current assignment, but
  which would become unsatisfied if the variable
  were flipped.
• Stochastic because this method is only applied
  half the timethe other half, a random variable
  is flipped to true.

15
The Results
To prove optimality, you must perform a
systematic search of all plans of length less
than the found plan, and show that no shorter
plans exist.
