Auditory PerceptionandSound Models

• Cecilia R. Aragon
• IEOR 170
• UC Berkeley
• Spring 2006

2
Acknowledgments

• How the Ear Functions, http//www.archive.org/de
  tails/HowtheEa1940
• Brian Bailey, http//www-faculty.cs.uiuc.edu/bpba
  iley/teaching/2006-Spring/cs414/index.html
• Dan Russell, http//www.kettering.edu/drussell/de
  mos.html
• James Hillenbrand, http//homepages.wmich.edu/hil
  lenbr/AuditoryPerception.ppt
• Lawrence Rosenblum, http//www.faculty.ucr.edu/ro
  senblu/lab-index.html (McGurk effect)
• Andrew Green, http//www.uwm.edu/ag/teach_pdf/lec
  turenotes/perception/

3
Outline

• How the Ear Functions
• Physical Dimensions of Sound
• Perceptual Dimensions of Sound
• Sound Intensity and the Decibel Scale
• Pitch Perception
• Loudness Perception
• Timbre Perception
• Digitization of Sound

4
How the Ear Functions

• http//www.archive.org/details/HowtheEa1940

5
Physical Dimensions of Sound
6
Waves

• Periodic disturbances that travel through a
  medium (e.g. air or water)
• Transport energy
• What is a Wave? Dan Russell, http//www.ketterin
  g.edu/drussell/Demos/waves-intro/waves-intro.html


7
Sound

• A longitudinal, mechanical wave
• caused by a vibrating source
• Pack molecules at different densities
• cause small changes in pressure
• Model pressure differences as sine waves

8
Sound Waves

• Pure Tones - simple waves
• Harmonics - complex waves consisting of
  combinations of pure tones (Fourier analysis) -
  the quality of tone or its timbre (i.e. the
  difference between a given note on a trumpet and
  the same note on a violin) is given by the
  harmonics

9
Changes in Air Pressure
10
Process of Hearing (Transduction)
11
Frequency (temporal) Theory

• Periodic stimulation of membrane matches
  frequency of sound
• one electrical impulse at every peak
• maps time differences of pulses to pitch
• Firing rate of neurons far below frequencies that
  a person can hear
• Volley theory groups of neurons fire in
  well-coordinated sequence

12
Place Theory

• Waves move down basilar membrane
• stimulation increases, peaks, and quickly tapers
• location of peak depends on frequency of the
  sound, lower frequencies being further away

13
Physical Dimensions of Sound

• Amplitude
• height of a cycle
• relates to loudness
• Wavelength (w)
• distance between peaks
• Frequency ( ? )
• cycles per second
• relates to pitch
• ? w velocity
• Most sounds mix many frequencies amplitudes

Sound is repetitive changesin air pressure over
time
14
Perceptual Dimensions of Sound
15
Auditory Perception
Auditory perception is a branch of
psychophysics. Psychophysics studies
relationships between perception and physical
properties of stimuli. Physical dimensions
Aspects of a physical stimulus that can be
measured with an instrument (e.g., a light meter,
a sound level meter, a spectrum analyzer, a
fundamental frequency meter, etc.) Perceptual
dimensions These are the mental experiences that
occur inside the mind of the observer. These
experiences are actively created by the sensory
system and brain based on an analysis of the
physical properties of the stimulus. Perceptual
dimensions can be measured, but not with a meter.
Measuring perceptual dimensions requires an
observer (e.g., a listener).
16
Visual Psychophysics
Physical Properties Perceptual Dimensions
of Light Hue
Wavelength
Brightness Luminance Shape
Contour/Contrast Auditory
Psychophysics
Physical Properties Perceptual
Dimensions of Sound Pitch

Fundamental Frequency Loudness
Intensity
Timbre (sound quality) Spectrum
Envelope/Amp Env
17

• The Three Main Perceptual Attributes of Sound
• Pitch (not fundamental frequency)
• Loudness (not intensity)
• Timbre (not spectrum envelope or amplitude
  envelope)

The terms pitch, loudness, and timbre refer not
to the physical characteristics of sound, but to
the mental experiences that occur in the minds of
listeners.
18
Perceptual Dimensions

• Pitch
• higher frequencies perceived as higher pitch
• humans hear sounds in 20 Hz to 20,000 Hz range
• Loudness
• higher amplitude results in louder sounds
• measured in decibels (db), 0 db represents
  hearing threshold

19
Perceptual Dimensions (cont.)

• Timbre
• complex patterns added to the lowest, or
  fundamental, frequency of a sound, referred to as
  spectrum envelope
• spectrum envelopes enable us to distinguish
  musical instruments
• Multiples of fundamental frequency give music
• Multiples of unrelated frequencies give noise

20
Sound Intensity and the Decibel Scale
21
Sound Intensity

• Intensity (I) of a wave is the rate at which
  sound energy flows through a unit area (A)
  perpendicular to the direction of travel
• P measured in watts (W), A measured in m2
• Threshold of hearing I0 is at 10-12 W/m2
• Threshold of pain is at 1 W/m2

22
Decibel Scale

• Describes intensity relative to threshold of
  hearing based on multiples of 10

23
Decibels of Everyday Sounds
24
Interpretation of Decibel Scale

• 0 dB threshold of hearing (TOH)
• 10 dB 10 times more intense than TOH
• 20 dB 100 times more intense than TOH
• 30 dB 1000 times more intense than TOH
• An increase in 10 dB means that the intensity of
  the sound increases by a factor of 10
• If a sound is 10x times more intense than
  another, then it has a sound level that is 10x
  more decibels than the less intense sound

25
Loudness from Multiple Sources

• Use energy combination equation
• where L1, L2, , Ln are in dB

26
Exercises

• Show that the threshold of hearing is at 0 dB
• Show that the threshold of pain is at 120 dB
• Suppose an electric fan produces an intensity of
  40 dB. How many times more intense is the sound
  of a conversation if it produces an intensity of
  60 dB?
• One guitar produces 45 dB while another produces
  50 dB. What is the dB reading when both are
  played?
• If you double the physical intensity of a sound,
  how many more decibels is the resulting sound?

27
Pitch Perception
28
Pitch and Fundamental Frequency All else being
equal, the higher the F0, the higher the
perceived pitch.
Lower F0, lower pitch
Higher F0, higher pitch
29
Pitch Perception
The ear is more sensitive to F0 differences in
the low frequencies than the higher frequencies.
This means that 300 vs. 350 ¹ 3000 vs.
3050 That is, the difference in perceived pitch
(not F0) between 300 and 350 Hz is NOT the same
as the difference in pitch between 3000 and 3050
Hz, even though the physical differences in F0
are the same. 300-350 3000-3050
30
Music Perception

• Tone height A sound quality whereby a sound is
  heard to be of higher or lower pitch
  monotonically related to frequency
• Tone chroma A sound quality shared by tones that
  have the same octave interval
• Musical helix Can help visualize musical pitch

31
Harmonic Frequencies
1f

• Strings or pipes (trombone, flute organ) all have
  resonant frequencies.
• They may vibrate at that frequency or some
  multiple of it
• All instruments and voices carry some harmonics
  and dampen others

2f1 octave
3f
4f2 octaves
8f3 octaves
Length of string or pipe
32
Loudness Perception
33
Loudness and Intensity All else being equal, the
higher the intensity, the greater the loudness.
Higher intensity, higher loudness
Lower intensity, lower loudness
34
The relationship between intensity and
loudness Doubling intensity does not double
loudness. In order to double loudness, intensity
must be increased by a factor of 10, or by 10 dB
10 x log10 (10) 10 x 1 10 dB. This is
called the 10 dB rule. Two signals differing by
10 dB
(500 Hz sinusoids)
Note that the more intense sound is NOT 10 times
louder even though it is 10 times more
intense. The 10 dB rule means that a 70 dB signal
is twice as loud as a 60 dB signal, four times as
loud as a 50 dB signal, eight times as loud as a
40 dB signal, etc. A 30 dB hearing loss is
considered mild -- just outside the range of
normal hearing. Based on the 10 dB rule, how much
is loudness affected by a 30 dB hearing
loss? (Answer 1/8th. But note that this does not
mean that someone with a 30 dB loss will have 8
times more difficulty with speech understanding
than someone with normal hearing.)
35
Loudness Perception
Loudness is strongly affected by the frequency of
the signal. If intensity is held constant, a
mid-frequency signal (in the range from
1000-4000 Hz) will be louder than lower or
higher frequency signals. 125 Hz, 3000 Hz, 8000
Hz The 3000 Hz signal should appear louder than
the 125 or the 8000 signal, despite the fact that
their intensities are equal.
36
Loudness and Pitch

• More sensitive to loudness at mid frequencies
  than at other frequencies
• intermediate frequencies at 500hz, 5000hz
• Perceived loudness of a sound changes based on
  the frequency of that sound
• basilar membrane reacts more to intermediate
  frequencies than other frequencies

37
Audibility Thresholds
38
Fletcher-Munson Contours
Each contour represents an equal perceived sound
39
Human Auditory Spectrum

• lt 20 Hz - infrasound
• gt 20 KHz - ultrasound
• human auditory range decreases with age
• TV 17.7 KHz horizontal scanning frequency
• ultrasonic cleaning devices, burglar alarms
  (20-40 KHz)
• CD 20 KHz cutoff, LP 60-80 KHz

40
Exposure to Loud Noise
41
Timbre Perception
42
Timbre Timbre, also known as sound quality or
tone color, is oddly defined in terms of what it
is not When two sounds are heard that match for
pitch, loudness, and duration, and a difference
can still be heard between the two sounds, that
difference is called timbre. For example a
clarinet, a saxophone, and a piano all play a
middle C at the same loudness and same duration.
Each of these instruments has a unique sound
quality. This difference is called timbre, tone
color, or simply sound quality. There are also
many examples of timbre difference in speech. For
example, two vowels (e.g., /å/ and /i/) spoken at
the same loudness and same pitch differ from one
another in timbre. There are two physical
correlates of timbre spectrum
envelope amplitude envelope
43
Timbre and Spectrum Envelope
Timbre differences between one musical instrument
and another are partly related to differences in
spectrum envelope -- differences in the relative
amplitudes of the individual harmonics. In the
examples above, we would expect all of these
sounds to have the same pitch because the
harmonic spacing is the same in all cases. The
timbre differences that you would hear are
controlled in part by the differences in the
shape of the spectrum envelope.
44
Six Synthesized Sounds Differing in Spectrum
Envelope
Note the similarities in pitch (due to constant
F0/harmonic spacing) and the differences in
timbre or sound quality.
45
Vowels Also Differ in Spectrum Envelope
Shown here are the smoothed envelopes only (i.e.,
the harmonic fine structure is not shown) of 10
American-English vowels. Note that each vowel
has a unique shape to its spectrum envelope.
Perceptually, these sounds differ from one
another in timbre. Purely as a matter of
convention, the term timbre is seldom used by
phoneticians, although it applies just as well
here as it does in musical acoustics. In
phonetics, timbre differences among vowels are
typically referred to as differences in vowel
quality or vowel color.
From Hillenbrand, J.M, Houde, R.A., Clark, M.J.,
and Nearey, T.M. Vowel recognition from harmonic
spectra. Acoustical Society of America, Berlin,
March, 1999.
46
Aperiodic sounds can also differ in spectrum
envelope, and the perceptual differences are
properly described as timbre differences.
47

• Amplitude Envelope
• Timbre also affected by amplitude envelope
• sometimes called the amplitude contour or energy
  contour of the sound wave
• the way sounds are turned on and turned off

Leading edge attack
Trailing edge decay The attack
especially has a large effect on timbre.
48
Music examples(timbre differences related to
amplitude envelope)
Plucked vs. bowed stringed instruments The
damping pedal on a piano The difference in sound
quality between a hammered string (e.g., a piano)
and a string that is plucked by a quill (e.g., a
harpsichord).
The timbre differences that distinguish one
musical instrument from another appear to be more
closely related to differences in amplitude
envelope -- and especially the attack -- than to
the shape of the spectrum envelope (although both
play a role). For example, when the amplitude
contour of an oboe tone is imposed on a violin
tone, the resulting tone sounds more like an oboe
than a violin.
White, G.D. The Audio Dictionary, 1987, Seattle
University of Washington Press.
49
Same melody, same spectrum envelope (if
sustained), different amplitude envelopes (i.e.,
different attack and decay characteristics). Note
differences in timbre or sound quality as the
amplitude envelope varies.
50
Timbre differences related to amplitude envelope
also play a role in speech. Note the differences
in the shape of the attack for /b/ vs. /w/ and
/S/ vs. /tS/.
abrupt attack
more gradual attack
abrupt attack
more gradual attack
51
Hearing Lips and Seeing Voices(The McGurk Effect)

• http//www.faculty.ucr.edu/rosenblu/lab-index.htm
  l

52
Digitization of Sound
Steinmetz and Nahrstedt
53
Digitization

• Microphones, video cameras produce analog signals
  (continuous-valued voltages)
• To get audio or video into a computer, we must
  digitize it (convert it into a stream of numbers)

• So, we have to understand discrete sampling (both
  time and voltage)

54
Discrete Sampling

• Sampling -- divide the horizontal axis (the time
  dimension) into discrete pieces. Uniform sampling
  is ubiquitous.
• Quantization -- divide the vertical axis (signal
  strength) into pieces. Sometimes, a non-linear
  function is applied.
• 8 bit quantization dividesthe vertical axis into
  256levels. 16 bit gives you65536 levels.

55
Sampling (in time)

• Measure amplitude at regular intervals
• How many times should we sample?

56
Nyquist Theorem

• Suppose we are sampling a sine wave. How often do
  we need to sample it to figure out its frequency?

• If we sample at 1 time per cycle, we can think
  it's a constant.

57
Nyquist Rate

• If we sample at 1.5 times per cycle, we can think
  it's a lower frequency sine wave.
• Nyquist rate -- "For lossless digitization, the
  sampling rate should be at least twice the
  maximum frequency response."

58
Digital Audio

• Standard music CD
• Sampling Rate 44.1 kHz
• 16-bit samples
• 2-channel stereo
• Data transfer rate 2?16?44,100 1.4 Mbits/s
• 1 hour of music 1.4?3,600 635 MB
