Title: Interrupt driven I/O


1
Interrupt driven I/O
2
MIPS RISC Exception Mechanism
  • The processor operates in
  • user mode
  • kernel mode
  • Access to additional set of registers and to
    user-mode restricted memory space available when
    the processor operates in kernel mode.
  • The MIPS RISC architecture includes the notion of
    co-processors. If the floating point co-processor
    is not present it can be emulated by a software.

3
Co-processors
  • The co-processor C1 execute floating point
    instructions and contain floating point
    registers.
  • If the coprocessor C1 does not exist and an
    instruction specifies a floating point register,
    a trap occurs. The exception handler can identify
    the operation specified and may invoke software
    routines to achieve the effect of the specified
    operation.
  • The co-processor C0 is always present and
    contains registers useful for handling exceptions
    but is not accessible in user mode. C0 includes
    the status register, cause register, BadVaddr,
    and EPC (exception program counter).

4
Co-processor 0
5
Cause Register
  • The cause register contains information about
    pending interrupts and the kinds of exception
    that occurs.
  • The contents of the cause register can be copied
    into an ordinary register and have the individual
    bits tested to determine what caused an exception
    to occur.
  • mfc0 26, 13
  • The above instruction moves data from coprocessor
    0 register 13(cause register) to general purpose
    register 26

6
Cause Register
7
Status Register
  • The status register contains information about
    the status of features of the computer that can
    be set by the processor while in kernel mode

indicates whether the processor was in kernel
or user mode when the last exception occurred
indicates whether current status is kernel or user
8
Status Register
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Mode Enable Mode Enable Mode Enable
Old Prev Cur
Mode 1user, 0kernel Enable 1on, 0off
9
EPC (exception program counter)
  • Contains the address of the instruction that was
    executing when the exception was generated.
  • Control can be made to return to this location to
    continue the program.
  • The contents of EPC can be transferred to a
    general register via the following instruction
  • mfc0 Rt, 14

10
Exception Handler
  • The MIPS R32 architecture fixes the starting
    address of the exception handler to 0x8000 0180.
  • A jump table consists of a list of procedure
    addresses to be called to deal with the various
    exception conditions.
  • In an interrupt, the PC had already been
    incremented and EPC would contain the correct
    return address.
  • In a syscall, the EPC contains the address of the
    syscall itself, thus the exception handler must
    first increment the return address by one before
    the return.

11
Handling an exception
  • An exception has occurred. What happens?
  • The hardware
  • copies PC into EPC (14 on cop0) and puts correct
    code into Cause Reg (13 on cop0)
  • Sets PC to 0x80000180, process
  • enters kernel mode
  • Exception handler (software)
  • Checks cause register (bits 5 to 2 of 13 in cp0)
  • jumps to exception service routine for the
    current exception

12
OS Issues
  • When an interrupt is serviced the processor must
    be able to execute without being interrupted. It
    must have the capability of temporarily disabling
    the interrupt atomically.
  • If an interrupt occurs while an interrupt service
    is ongoing, it is simply deferred and considered
    a pending interrupt. It is serviced after the
    current request terminates.
  • The MIPS RISC architecture does not allow user
    programs to access beyond 0x8000 0000 (the upper
    half of the memory). The exception handler is in
    this part of memory and only executed in kernel
    mode.

13
OS Issues
  • Changing the mode back to the mode before the
    exception occurs is accomplished via the
    instruction eret
  • Old ? Previous ? Current
  • The mode information is stored in the Status
    Register and can only be written in the kernel
    mode. It can be read in user mode.

14
OS Issues
  • Enabling and disabling of interrupts can be done
    either by applying an interrupt mask (IPM) to
    bits 10-15, or the enable bit of the Status
    Register.
  • The execution of eret enables interrupts

15
OS Issues
  • A reentrant exception handler is written such
    that it is itself interruptible.
  • Interrupts and traps are assigned priorities.
  • A check is made for pending interrupt requests
    after every instruction.
  • If there is a pending interrupt request, the
    priority is checked. If it has a higher priority
    than the currently running code, it serviced
    first, otherwise it is ignored.

16
Enabling interrupts
  • By default, interrupts are disabled in SPIM
  • To use respond to interrupts, a program must
  • Enable interrupts
  • Status register
  • Enable the interrupt for the specific device
  • Status register
  • Instruction the device controller to cause
    interrupts
  • Device control memory mapped address

17
Software Interrupt Driven I/O
  • Exceptions come in two varieties
  • Interrupts are generated by hardware
  • I/O device
  • Clock
  • Power down
  • Traps are generated by code execution
  • Division by zero
  • Illegal memory address
  • System call

18
Interrupt driven I/O structure
  • Our programs have all run in kernel mode only
  • Code to service an interrupt must be called from
    location 0x8000180
  • We must return to the address at which the
    interrupt occurred

kernel
0xffffffff 0x80000080 0x80000000 0x1000000
0 0x00400000 0x00000000
stack
code
19
Interrupt driven I/O structure
  • A queue is needed for both input and output
  • Input
  • Characters are added when a keyboard interrupt
    occurs
  • Characters are removed when the input function is
    called
  • Output
  • Characters are removed when a display interrupt
    occurs
  • Characters are added when a keyboard interrupt
    occurs
  • Echoing
  • Characters are added when the output function is
    called
  • The output function must initiate the first
    display handler call
  • Thereafter, interrupts occur when the display
    becomes ready

20
Interrupt driven I/O structure
User data
input function (syscall 8)
input
output function (syscall 4)
echo
output
21
Protecting the buffers
  • The input and output buffers may be modified in
    response to an interrupt
  • This could occur while the CPU is in the middle
    of executing user code which reads from the input
    buffer or writes to the output buffer
  • To prevent this destructive concurrent access, we
    must disable interrupt while accessing the
    buffers
  • Explicitly and status with 0xfffffffe
  • Implement I/O functions as system calls
