Biological Terrorism

1

Biological Terrorism Smallpox
5/9/01
2
History

• Caused by variola virus
• Most deaths of any infectious disease
• 500 million deaths in 20th Century
• 2 million deaths in 1967
• Known in ancient times
• Described by Ramses
• Natural disease eradicated
• Last U.S. case 1949 (imported)
• Last international case 1978
• Declared eradicated in 1979

Photo National Archives
3
Bioweapon Potential

• Features making smallpox a likely agent
• Can be produced in large quantities
• Stable for storage and transportation
• Known to produce stable aerosol
• High mortality
• Highly infectious
• Person-to-person spread
• Most of the world has little or no immunity

4
Bioweapon Potential

• Prior attempted use as bioweapon
• French and Indian Wars (1754-1767)
• British gave Native Americans infected blankets
• Outbreaks ensued, some tribes lost 50
• Allegations of use in U.S. Civil War
• Alleged use by Japanese in China in WWII

5
Bioweapon Potential

• Current concerns
• Former Soviet Union scientists have confirmed
  that smallpox was successfully weaponized for use
  in bombs and missiles
• Active research was undertaken to engineer more
  virulent strains
• Possibility of former Soviet Union virus stock in
  unauthorized hands

6
Bioweapon Potential

• Nonimmune population
• lt20 of U.S. with substantial immunity
• Availability of virus
• Officially only 2 stocks (CDC and Russia)
• Potential for more potent attack
• Combined with other agent (e.g. VHF)
• Engineered resistance to vaccine

7
Bioweapon Potential

• Delivery mechanisms
• Aerosol
• Easiest to disperse
• Highest number of people exposed
• Most contagious route of infection
• Most likely to be used in bioterrorist attack
• Fomites
• Theoretically possible but inefficient

8
Epidemiology

• All ages and genders affected
• Incubation period
• From infection to onset of prodrome
• Range 7-17 days
• Typical 12-14 days

9
Epidemiology

• Transmission
• Airborne route known effective mode
• Initially via aerosol in BT attack
• Then person-to-person
• Hospital outbreaks from coughing patients
• Highly infectious
• lt10 virions sufficient to cause infection
• Aerosol exposure lt15 minutes sufficient

10
Epidemiology

• Person-to-person transmission
• Secondary Attack Rate (SAR)
• 25-40 in unvaccinated contacts
• Relatively slow spread in populations (compared
  to measles, etc.)
• Higher during cool, dry conditions
• Historically 3-4 contacts infected
• May be 10-20 in unvaccinated population
• Very high potential for nosocomial spread
• Usually requires face-to-face contact

11
Epidemiology

• Transmission via fomites
• Contaminated hospital linens/laundry
• May have been successfully used as weapon in
  French-Indian War

12
Epidemiology

• Infectiousness Rash is marker
• Onset approx one day before rash
• Peaks during first week of rash
• ? Carrier state possible
• Some data show virus detectable in saliva of
  contacts who never become infected
• Unclear if they can transmit infection, but
  theoretically possible

13
Epidemiology

• Infectious Materials
• Saliva
• Vesicular fluid
• Scabs
• Urine
• Conjunctival fluid
• Possibly blood

14
Epidemiology

• Role of index case severity
• Does not predict transmissibility
• Does not predict severity of 2 cases
• Role of prior vaccination
• Immunity wanes with time
• Maintain partial immunity for many years
• Partial immunity reduces disease severity
• Reduces transmissibility (less virus shed)

15
Epidemiology

• Mortality
• 25-30 overall in unvaccinated population
• Infants, elderly greatest risk (gt40)
• Higher in immunocompromised
• May be dependent on ICU facilities
• Dependent on virus strain
• Dependent on disease variant

16
Epidemiology

• Factors that allowed smallpox eradication
• Slow spread
• Effective, relatively safe vaccine
• No animal/insect vectors
• No sig. carrier state (infected die or recover)
• Infectious only with symptoms
• Prior infection gives lifelong immunity
• International cooperation

17
Microbiology

• Variola virus the agent of smallpox
• Orthopoxviridae family
• 2 strains of variola
• Variola major
• Variola minor
• Vaccinia
• Used for current vaccine
• Namesake of vaccine
• Cowpox used by Jenner in first vaccine
• Monkeypox rare but serious disease from monkeys
  in Africa

18
Microbiology

• Variola major
• Classic smallpox
• Predominant form in Asian epidemics
• Highest mortality (30)

19
Microbiology

• Variola minor
• Same incubation period, mode of transmission,
  clinical presentation
• Causes milder disease
• Less severe prodrome and rash
• Mortality 1
• Discovered in 20th century
• Started in S. Africa
• Was most predominant form in N. America

20
Microbiology

• Environmental survival
• Longest (gt24hr) in low temp/low humidity
• Inactive within few hours in hi temp/humidity
• Dispersed aerosol
• completely inactivated within 2 days of release

21
Pathogenesis

• Virus lands on respiratory/oral mucosa
• Macrophages carry to regional nodes
• Primary viremia on Day 3
• Invades reticuloendothelial organs
• Secondary viremia on Day 8

22
Pathogenesis

• White Blood Cells infected
• WBCs migrate capillaries, invade dermis
• Infects dermal cells
• Influx of WBCs, mediators cause vesicle
• Systemic inflammatory response
• Triggered by viremia
• Sepsis, multiorgan failure, often DIC

23
Pathogenesis

• Severity of disease
• Not influenced by severity of source case
• Probably related to degree of viremia
• Inoculation dose
• Longer exposure, higher concentration at release
• Virulence of variola
• strain, engineered resistance
• Host immune status
• Type of rash predictive of outcome
• More severe rashes poorer outcomes

24
Clinical Features

• Three stages of disease
• Incubation
• Asymptomatic
• Prodromal
• Nonspecific febrile illness, flu-like
• Eruptive
• Characteristic rash

25
Clinical Features

• Incubation Stage
• From time of infection to onset of symptoms
• Average 12-14 days (range 7-17)
• Important for epidemiologic investigation
• Considered non-infectious during this stage
• Virus sometimes culturable

26
Clinical Features

• Prodromal Stage
• Common symptoms
• High fever, prostration, low back myalgias, HA
• Occasional symptoms
• Vomiting, abdominal pain, delirium
• Duration typically 3-5 days
• End of stage heralded by mucosal lesions
• Mucosal lesions onset of infectiousness

27
Clinical Features

• Eruptive Stage (Rash)
• May start with transient defervescence
• Characteristic rash
• Centrifugal (in order of appearance severity)
• Initially oral mucosa borders pre-eruptive stage
• Head, face
• Forearms, hands, palms
• Legs, soles, /- trunk

28
Classic Centrifugal Rash of Smallpox Involving
Face and Extremities, Including the Soles.
Photo National Archives
29
Classic Centrifugal Rash of Smallpox Involving
Face and Extremities.
Photo National Archives
30
Clinical Features

• Rash stages of development
• All lesions in one region at same stage
• Starts macular, then papular
• Deep, tense vesicles by Day 2 of rash
• Turns to round, tense, deep pustules
• Pustules dry to scabs by Day 9
• Scabs separate

31
Classic Smallpox Rash, Demonstrating Same
Development Stage (Pustular) of All Lesions in a
Region
Photo National Archives
32
Clinical Features

• Scarring
• From separated scabs
• Fibrosis, granulation in sebaceous glands
• Pink, depressed pock marks
• Prominent on face, usually gt5 lesions
• Permanent

33
Clinical Features

• Rash variations
• Sine eruptione variant
• Prodrome without rash
• Clinically less severe

34
Clinical Features

• Modified variant
• Previously vaccinated with partial immunity
• Milder rash, better outcome, faster resolution

Photo National Archives
35
Clinical Features

• Rash variations
• Ordinary (Classic presentation) variant
• gt90 all cases
• Subdivided based on confluence of lesions
• Discrete (lt10 mortality)
• Semiconfluent (25-50 mortality), most common
• Confluent (50-75 mortality)

36
Discrete Type of Classical Smallpox Rash
Photo National Archives
37
Confluent Type of Classical Smallpox Rash
Photo National Archives
38
Clinical Features

• Rash variations
• Flat (Malignant) variant
• Uncommon
• Prodrome more sudden, severe
• More likely severe abdominal pain
• Rash never forms pustules/scabs
• Leathery in appearance
• Sometimes hemorrhagic or exfoliating
• DDX acute abdomen, hemorrhagic varicella
• gt90 mortality

39
Clinical Features

• Rash variations
• Hemorrhagic
• Rare
• Prodrome more acute and severe
• Bleeding diathesis before onset of rash
• Rash is also hemorrhagic
• Pregnant women at highest risk (?immune state)
• Higher risk of transmission (more fluid shedding)
• DDX meningococcemia, DIC
• Mortality 100

40
Clinical Features

• In an outbreak setting atypical or variant rashes
  must be considered smallpox until proven otherwise

41
Clinical Features

• Complications
• Sepsis/toxemia
• Usual cause of death
• Associated with multiorgan failure
• Usually occurs during 2nd week of illness
• Encephalitis
• Occasional
• Similar to demylination of measles, varicella

42
Clinical Features

• Complications
• Secondary bacterial infections uncommon
• Staphylococcus aureus cellulitis
• Responds to appropriate antibiotics
• Corneal ulcers
• A leading cause of blindness before 20th Century
• Conjunctivitis rare
• During 1st week of illness

43
Diagnosis

• Clinical diagnosis
• Sufficient in outbreak setting
• gt90 have classical syndrome
• Prodrome followed by rash
• Rarely, variants can be difficult to recognize
• Hemorrhagic mimics meningococcemia
• Malignant more rapidly fatal
• Sine eruptione prodrome without rash
• Partially immune milder, often atypical

44
Diagnosis

• Traditional confirmatory methods
• Electron microscopy of vesicle fluid
• Rapidly confirms if orthopoxvirus
• Culture on chick membrane or cell culture
• Slow, specific for variola
• Newer rapid tests
• Available only at reference labs (e.g. CDC)
• PCR, RFLP

45
Diagnosis

• Specimen procurement/handling
• By recently successfully immunized person
• Open vesicle with blunt end of blade
• Collect with cotton swab
• Place swab into sealed vacuum blood tube
• Place tube in larger jar, tape lid

46
Diagnosis

• Differential Diagnosis
• Chickenpox (varicella)
• Vesicles shallow, in crops, varied stages
• Centripetal, spares palms/soles
• Other orthopox viruses
• Monkeypox only in Africa, monkey contact
• Vaccinia after exposure to vaccine
• Cowpox rare, only in UK

47
Treatment

• Management of cases
• Supportive
• Post-exposure prophylaxis
• Vaccine
• Vaccinia immunoglobulin
• Primary prophylaxis
• Vaccine

48
Treatment

• Managing confirmed or suspected cases
• No specific effective antiviral treatment
• Supportive care is critical
• Electrolytes / Volume / Ventilation / Pressors
• Antibiotics only for secondary infections
• e.g. S. aureus cellulitis
• Isolation
• Vaccinate (in case diagnosis is wrong)

49
Post-Exposure Prophylaxis

• Vaccine
• Protective if given within 3-4 days exposure
• Reduces incidence 2-3 fold
• Decreases mortality by 50
• Vaccinia immune globulin (VIG)
• 3 fold decrease in incidence and mortality
• Passive immunity for 2 weeks
• Very limited supply (at CDC)

50
Post-Exposure Prophylaxis

• Antivirals
• Cidofovir
• Limited experimental data
• May be beneficial in first 2 days post-exposure
• Available IV only
• Significant renal toxicity

51
Prevention

• Vaccination History
• Variolation
• Inoculation with infectious smallpox
• Scabs or pustular material
• 1 mortality
• Immunized were infectious - outbreaks
• Provided full immunity
• Originated in Eastern countries in ancient times
• Started in U.S. by Rev. Cotton Mather 1721

52
Prevention

• Vaccination - History
• Introduced by Jenner
• Inoculated boy with pustular fluid from cowpox
• 1st immunization using virus of similar disease
• Initially passed arm-to-arm
• Also passed syphilis, hepatitis
• Eventually passed calf-to-calf on scarified leg
• Immunity not lifelong

53
Prevention

• Vaccine modern times
• Vaccinia virus
• Related to cowpox and variola
• Source calf lymph
• Now cell culture methods available
• Strains
• Lister used by WHO for eradication campaign
• New York Board of Health only U.S. strain
• Newer more attenuated Japanese strain

54
Prevention

• Vaccine administration
• Jet gun
• Rapid
• High maintenance
• Bifurcated needle
• High efficacy, sterilizable, simple, rapid
  (1500/day)
• Uses less vaccine
• Mainstay for the WHO eradication campaign

Photo National Archives
55
Prevention

• Vaccination policies
• Last mandated in U.S. in 1972
• World travelers until 1979
• Laboratory workers
• Stability
• Freeze-dried lasts decades
• Current stock probably still potent

56
Prevention

• Supply
• 7-15 million doses in U.S. as of 1999
• gt20 years old
• Stock controlled by CDC
• Production
• No current active production
• New vaccine production scheduled for 2004

57
Prevention

• Vaccine efficacy
• Nearly complete protection for responders
• Effective for all ages except neonates
• Reduces secondary attack rate 10 fold
• Highest efficacy
• Those who are vaccinated 3-4 times
• Successful vaccination in previous 3 years
• Also protects from monkeypox

58
Prevention

• Duration of efficacy single dose
• Probably 5-10 years
• Some immunity gt20 years
• Lower morbidity mortality (3 fold)
• Revaccination leads to gt30 years protection
• Neutralizing antibody used as marker

59
Prevention

• Successful vaccination reaction (take)
• Pruritic hyperemic papule Day 3-4
• Jennerian vesicle by Day 7-9
• Dries by Day 14
• Marks immunity
• If no vesicle, revaccinate from different lot

60
Prevention

• Vaccine adverse effects
• Pregnancy
• Rare fetal vaccinia
• No known malformations
• Mild symptoms nearly universal
• 1º take reaction in all successful vaccinations
• Mild tender axillary lymphadenopathy common
• 70 infants have prolonged fever

61
Prevention

• Serious complications
• Occur in 74-250 per million (1/10,000)
• 3-4 fold higher risk in infants lt1 y.o.
• Highest risk in primary vaccinees

62
Prevention

• Types of reactions
• Severe cutaneous
• Most common
• Associated with vaccinia viremia
• Encephalitis
• 1 in 300,000
• 25 mortality, survivors usually neuro sequelae
• Similar to measles, varicella
• Fever, headache, lethargy, paralysis, meningitis,
  coma
• No effective treatment

63
Prevention

• Types of reactions
• Vaccinia gangrenosum/necrosum
• Original lesion spreads and does not heal
• Mortality 100 in untreated, 20-36 treated
• Highest risk in immunocompromised
• Treatment
• Vaccinia immunoglobulin (VIG)
• Thiosemicarbazone

64
Prevention

• Types of reactions
• Eczema vaccinatum
• Vaccinees or their contacts with h/o eczema
• Vaccinial lesions away from inoculation site
• Mortality 30-40 in children lt2yo
• Treatment - VIG reduces mortality 5-fold

65
Prevention

• Types of reactions
• Generalized vaccinia
• Distant vaccinial lesions
• 6-9 days after vaccine
• Usually mild, self-limited
• Autoinoculation
• Touching vesicle then others or self (eyes)

66
Prevention

• Vaccinia immunoglobulin
• Limited stock available via CDC
• Uses
• Post-exposure prophylaxis
• Vaccine adverse effects very effective
• Pre-vaccine prophylaxis
• Very effective for hi-risk vaccinees
• For all severe adverse effects except
  encephalitis
• Doesnt alter vaccine efficacy

67
Prevention

• No absolute contraindications to vaccinate
• Relative contraindications (Hi Risk Groups)
• History of eczema or chronic skin disorder
• Age lt1 y.o.
• Pregnant
• Immunosuppressed (HIV, malignancy)
• Use VIG if hi-risk must be vaccinated

68
Prevention

• Summary of vaccine strategy in outbreak (unless
  vaccinated in last 3-5 years)
• All confirmed or suspected cases
• All contacts of confirmed/suspected cases
• All hospital personnel of hospitalized cases
• All other patients in hospital with cases
• Home care-givers
• Mortuary workers handling deceased cases
• Prophylactic VIG for hi-risk groups

69
Infection Control

• Vital component of outbreak management
• Transmission is key
• No animal/arthropod vectors
• No known asymptomatic reservoirs
• carrier state hypothetical but not confirmed
• Higher rate in cool, dry conditions

70
Infection Control

• Transmission
• Overall secondary attack rate 25-40
• Historically 3-4 cases per index patient
• Outbreak in mostly nonimmune population
• Anticipate 10-20 cases per contact
• All body fluids infectious
• Respiratory secretions main culprit
• Cough dramatically increases transmission

71
Infection Control

• Period of infectiousness
• Onset usually 1 day before rash
• associated with mucosal lesions
• sometimes transient defervescense at end of
  prodromal stage
• Lasts until all lesions scabbed over
• Longer duration with more severe cases

72
Infection Control

• Isolation of Cases
• Home isolation is preferable
• Avoids nosocomial spread
• Droplet and inoculation protection
• Contact precautions glove, gown, face shield
• Aerosol protection
• Negative pressure room, HEPA filter
• Assign immune persons for care

73
Infection Control

• Management of Case Contacts
• Carefully identify true contacts
• Exposure to a case patient after fever onset
• Contact with secretions OR
• Face-to-face contact OR
• In nosocomial setting with a case
• Includes ALL hospital patients and staff
• Except for nosocomial, large group exposure
  unlikely usually bedridden by fever onset

74
Infection Control

• Management of Case Contacts
• Vaccination
• Proven benefit given within 3-4 days of exposure
• Observation for 17 days
• Twice daily temperature check
• Isolation if fever gt 38.0º C

75
Infection Control

• Handling of specimens
• BSL4 laboratory containment only
• Disposal of linens/laundry
• Dispose in biohazard containers
• Autoclave before laundering
• Launder in hot water bleach
• Cremation recommended for corpses

76
Infection Control

• Surveillance and containment critical
• Correct identification of those at risk
• Conservation of vaccine
• Target only those with true risk
• Limited national supply
• Components
• Aggressive case-seeking
• Aggressive contact-seeking observation

77
Decontamination

• Original aerosol release setting
• Likely no decontamination applicable
• Rapid dispersion of virus
• lt6 hours in higher heat, humidity
• Most gone by 24 hours even under ideal conditions
• Completely dissipated by 2 days
• Delayed onset of symptoms (at least 1 week)
• Virus long gone by time of index case recognition
  in covert release

78
Decontamination

• If known recent release
• HEPA filtration
• Sterilization of surfaces
• Standard disinfectants such as bleach

79
Smallpox Essential Pearls

• Smallpox has been weaponized
• Case fatality will likely approach 30
• Clinical diagnosis
• Asymptomatic incubation period 7-17 days
• Prodrome with high fever 3-5 days
• Eruptive phase with typical rash
• Centrifugal (head, face, hands/palms, feet/soles)
• Vesicles all same stage of development

80
Smallpox Essential Pearls

• Highly infectious
• Not infectious prior to fever onset
• Infectiousness starts one day before rash
• Lasts until all lesions scabbed over
• Secondary attack rate 25-40
• Expect 10-20 2º cases per index case
• No specific treatment, only supportive

81
Smallpox Essential Pearls

• Case identification isolation essential
• Droplets / secretions (contact isolation)
• Aerosols (negative pressure isolation)
• Isolate at home if possible (quarantine)
• Post-exposure prophylaxis for contacts
• Vaccine (with VIG for hi-risk groups)
• Fever observation x 17days, isolate if gt38.0

82
Smallpox Essential Pearls

• Report any suspected smallpox cases to your State
  and Local Health Departments
