Etiquette Equity in Automated Aerospace Systems

• Kevin M. Corker
• Human Automation Integration Laboratory (HAIL)
• San Jose State University
• 11/15/02

2
Acknowledgements

• Sponsored by
• NASA Aviation Safety Program
• Dr. Irving Statler technical monitor,
• FAA Office of ATM Architecture
• Mr. Steve Bradford, Chief Scientist, technical
  monitor
• FAA Office of Chief Scientist for Human Factors,
• Drs. Mark Rodgers and Dr. Paul Krois, technical
  monitors

3
Structure of Discussion

• Evolution of an etiquette argument
• Automation and etiquette
• Econometric Equity model of etiquette
• Advanced automation and aiding impact
• Process, Goal State and Priorities
• Conclusion and Computational Structures

4
Automation Issues

• Impact

• Introduction of automation changes the role of
  the operators in the system increases target
  capability
• Workload and sources for error are distributed
  not eliminated
• Common Sources of Error in use of automation
• Decision bias
• Mistrust Distrust lead Over Under-reliance
• Monitoring errors
• System authority, autonomy, trust and agents
  role
• How is automation used, rather then how was it
  designed to be used ?
• Any number of accidents and incidents determined
  to be associated with automated systems
• Lack of feedback
• Unidentified interrelations, side effects
• Divergent priority and valuation processes

5
Evolution of an etiquette argument

• Evolutionary Psychology the development of a
  process of moralistic aggression whose purpose it
  is to educate individuals to the standards
  expected (Badcock, 2000)
• Breaches in etiquette evoke a response that is
  disruptive, moralistic and (occasionally)aggressiv
  e
• Social Psychology Ability to monitor ones own
  and others states of emotion and process to use
  that information to guide ones thinking and
  actions (Salovey and Mayer, 1990)
• Cognitive Psychology Dedicated, functionally
  specialized interacting mechanisms (Cosmides and
  Tooby, 1992)
• Guide behavior and thought w/to recurrent
  adaptive problems posed by the social world

6
Dedicated Practiced Logic
If there is a D on one side there is a 3 on the
other
If a person is drinking beer they must be 21
years of age
7
Etiquette and Automation

• Human to Computer Courtesy computer performance
  assessment experiments (Reeves Nass, 1996)
• Theory of mind Cognitive entities experience
  mental states like our own (Premack Woodruff,
  1978)
• Automated Autism lack of awareness of mental
  emotional embeddedness as symptomatic of autism
  mind-blind (Baron-Cohen and Howlin, 1989)
• Computer to Human Affect (Picard, 1997)

8
Etiquette In Aerospace

• Theses
• One purpose for etiquette is to support secondary
  communication among interactive agents with
  reference to
• Conflict free access to scarce resources
• Present process, goal state priorities
• In capacity constrained air traffic management,
  access to command control processes is both
  necessary and limited
• In automation aiding automation response
  dependence of system-operator state is essential

9
Joint Cognitive Systems Analysis

• Apply cognitive engineering principles to the
  joint cognitive system
• What role will the system provide the operator in
  nominal and off-nominal operation?
• What behavioral data have we when the human is in
  that role?
• What design augments or offsets that behavior?

• What role will the system provide the automation
  in nominal and off-nominal operation?
• What performance data have we when the automation
  is in that role?
• What design augments or offsets that behavior?

10
Automation Analysis

• High Full Automation information selection
  analyses decision and implementation
• Automation informs human/organization on the
  basis of rules
• Executes actions automatically then informs
  human/organization
• Allows human/organization override on a limited
  time schedule
• Mid Executes computer generated plan if
  human/organization approves
• Automation provides best single alternative
• Automation narrows the available field of
  alternatives
• Automation provides a complete set of
  alternatives
• Low All information selection analyses decision
  and implementation performed by
  human/organization

Parasuraman, Sheridan, and Wickens, 2000
11
Dimensions of Automation Impact on Aero-transport
Information Information Decision Action
Acquisition Analysis Selection Implementation
High
Low
12
Automated Flight Deck Response to Off Nominal
Conditions
Weiner, 1985
13
Separation Standard Required
14
(No Transcript)
15
Data Link Vs. Voice Error in Standard and
Missed Communication
Lozito et al., 1999
16
Data vs. Voice Communication Time In Clarification
Lozito et al., 1999
17
Automation Aiding System

• Present Flight Data in Digital Form
• Provide an exploration capability for
  alternative flight paths
• Provide conflict prediction based on trajectory
  synthesis (20 min look ahead)
• Current flight path as filed and radar track
• Planned Flight Path
• Flight Deck Aiding System (60-40 sec look ahead)

18
Etiquette Equity

• Access can be decomposed into two elements
• Internal Delay Costs Cost incurred by user (x)
  in accessing and using a service
• External Delay Costs Cost incurred by all other
  users of that service as a function of user (x)
  occupancy of the resource

• Strategy for Demand Management Cost Equity is to
  shift the external costs to internal costs
• E.g. by the imposition of a congestion fee
  (Vickers, 1969, Daniel, 1995)

19
Etiquette Equity(adapted from Andreatta
Odoni, 2002)

• Behaviors that support courtesy impose a cost
  to the operator that engages in them
• Total Cost to user (Xi) DC CF
• Where DC is the direct cost for access to the
  command and control system (attention, bandwidth,
  SA, etc.)
• And CF is a courtesy fee which is the added cost
  to participate through the etiquette of operation

• Intended Result
• - Distribution of external costs equitably
  (cooperative queue management)

20
Pollaczek-Khintchine Expression
xi ci Wqi (x) Sj1 cjlj (xj)dWq(xmean)/dli(x
i) Ki
21
Error Reduction Correlated to Number of
Communication Types
Mjos, 2001
22
Etiquette and Aerospace Systems

• Current automated ATM systems do not support
  etiquette functions in human-human interaction
• Communication is asynchronous, loop closure is
  delayed (e.g. digital data link)
• Contract State Assurance is missing (shot clock
  and flash dash procedures)
• Queue Management Functions are missing
• Mechanisms for mediation are clumsy (data link
  stand-by message)
• Automation is blind to system-operator state

• Hypothesized Result Class of error Response
  under load

23
Etiquette-based Automation Strategies

• Shared Cost for Access to Scarce Executive
  Function
• State-sensitive Intervention Strategies
• Interruptive Signaling and Adaptive Response
• Automation and Human Goal States as Scheduling
  Mechanism
