Sentence Processing using a Simple Recurrent
Network

• EE 645 Final Project
• Spring 2003
• Dong-Wan Kang

5/14/2003
2
Contents

1. Introduction - Motivations
2. Previous Related Worksa) McClelland
   Kawamoto(1986)b) Elman (1990, 1993, 1999)c)
   Miikkulainen (1996)
3. Algorithms (Williams and Zipser, 1989) - Real
   Time Recurrent Learning
4. Simulations
5. Data Encoding schemes
6. Results
7. Discussion Future work

3
Motivations

• Can the neural network recognize the lexical
• classes from the sentence and learn the
  various
• types of sentences?
• From cognitive science perspective
• - comparison between human language learning

• and neural network learning pattern
• - (e.g.) Learning English past tense
  (Rumelhart
• McClelland,1986), Grammaticality judgment
  (Allen
• Seidenberg,1999), Embedded
  sentences(Elman 1993,
• Miikkulainen1996, etc.)

4
Related Works

• McClelland Kawamoto (1986)
• - Sentences with Case Role Assignments and
  semantic features by using backpropagation
  algorithm
• - output 2500 case role units for each
  sentence
• - (e.g.)
• input the boy hit the wall
  with the ball.
• output Agent Verb Patient
  Instrument other features
• - Limitation poses a hard limit on the
  number of input size.
• - Alternative Instead of detecting the
  input patterns displaced in
• space, detect the patterns which were in
  time (sequential inputs).

5
Related Works (continued)

• Elman (1990,1993, 1999)
• - Simple Recurrent Network Partially Recurrent
  Network using Context units
• - Network with a dynamic memory
• - Context units at time t hold a copy of the
  activations of the hidden units from the previous
  time step at time t-1.
• - Network can recognize sequences.

input Many years ago
boy and girl

output years ago
boy and girl
6
Related Works (continued)

• Miikkulainen (1996)
• - SPEC architecture
• (Subsymbolic Parser for Embedded Clauses ?
  Recurrent Network)
• - Parser, Segmenter, and Stack
• process the center and tail embedded
  sentences 98,100 sentences with 49 different
  sentence by using case role assignments

- (e.g.) Sequential Inputs input ,
the girl, who, liked, the dog, saw, the boy,
output , the girl, saw, the boy
the girl, liked, the dog
case role (agent, act, patient)
(agent, act, patient)
7
Algorithms

• Recurrent Network
• - Unlike feedforward networks, they allow
  connections both ways between a pair of units and
  even from a unit to itself.
• - Backpropagation through time (BPTT) unfolds
  the temporal
• operation of the network into a layered
  feedforward network at
• every time step. (Rumelhart, et al.,
  1986)
• - Real Time Recurrent Learning (RTRL) two
  versions (Williams and Zipser, 1989) 1)
  update weights after processing sequences is
  completed.
• 2) on-line update weights while
  sequences are being presented.
• - Simple Recurrent Network (SRN) partially
  recurrent network in
• terms of time and space. It has context
  units which store the
• outputs of the hidden units (Elman, 1990).
  (It can be modified from
• RTRL algorithm.)

8
Real Time Recurrent Learning

• Williams and Zipser (1989)
• - This algorithm computes the derivatives of
  states and
• outputs with respect to all weights as the
  network
• processes the sequence.
• Summary of Algorithm
• In recurrent network, for any unit
  connected to any other and the input at
  node i at time t, the dynamic update rule is

9
RTRL (continued)

• Error measure
• with target outputs defined for
  some ks and ts
• if
  is defined at time t
•
  otherwise
• Total cost function
• , t 0,1, , T,
  where
•


10
RTRL (continued)

• The gradient of E separate in time, to do
• gradient descent, we define
• The derivative of update rule
• where initial condition t 0,

11
RTRL (continued)

• Depending on the way of updating weights, there
  can be two versions of RTRL.
• 1) Update the weights after the sequences are

• completed at (t T ).
• 2) Update the weights after each time step
  on-line
• Elmans tlearn simulator program for Simple
  Recurrent Network (which Im using for this
  project) is implemented based on the classical
  backpropagation algorithm and the modification of
  this RTRL algorithm.

12
Simulation

• Based on Elmans data and Simple Recurrent
• Network(1990,1993, 1999), simple sentences
  and
• embedded sentences are simulated by using
  tlearn
• neural network program (BP modified version
  of RTLR
• algorithm) available at http//crl.ucsd.edu/in
  nate/index.shtml.
• Question
• 1. Can the network discover the lexical
  classes from word order?
• 2. Can the network recognize the relative
  pronouns and predict them?

13
Network Architecture

• 31 input nodes
• 31 output nodes
• 150 hidden nodes
• 150 context nodes
• black arrow
• distributed and learnable
• dotted blue arrow
• linear function and
• one-to-one connection with hidden nodes

14
Training Data

• Lexicon (31 words)

• Grammar (16 templates)

NOUN-HUM man woman boy girl NOUN-ANIM cat
mouse dog lion NOUN-INANIM book rock
car NOUN-AGRESS dragon monster NOUN-FRAG glass
plate NOUN-FOOD cookie bread sandwich VERB-INTRAN
think sleep exist VERB-TRAN see chase
like VERB-AGPAT move break VERB-PERCEPT smell
see VERB-DESTROY break smash VERB-EAT
eat ----------------------------- RELAT-HUM
who RELAT-INHUM which
NOUN-HUM VERB-EAT NOUN-FOOD NOUN-HUM
VERB-PERCEPT NOUN-INANIM NOUN-HUM VERB-DESTROY
NOUN-FRAG NOUN-HUM VERB-INTRAN NOUN-HUM
VERB-TRAN NOUN-HUM NOUN-HUM VERB-AGPAT
NOUN-INANIM NOUN-HUM VERB-AGPAT NOUN-ANIM
VERB-EAT NOUN-FOOD NOUN-ANIM VERB-TRAN
NOUN-ANIM NOUN-ANIM VERB-AGPAT NOUN-INANIM NOUN-AN
IM VERB-AGPAT NOUN-INANIM VERB-AGPAT NOUN-AGRESS
VERB-DESTROY NOUN-FRAG NOUN-AGRESS VERB-EAT
NOUN-HUM NOUN-AGRESS VERB-EAT NOUN-ANIM NOUN-AGRES
S VERB-EAT NOUN-FOOD
15
Sample Sentences Mapping

• Simple sentences 2 types
• - man think (2 words)
• - girl see dog (3 words)
• - man break glass (3 words)
• Embedded sentences - 3 types (RP Relative
  Pronoun)
• 1. monster eat man who sleep (RPsub,
  VERB-INTRAN)
• 2. dog see man who eat sandwich (RP-sub,
  VERB-TRAN)
• 3. woman eat cookie which cat chase (RP-obj,
  VERB-TRAN)
• Input-Output Mapping (predict next input
  sequential input)
• INPUT girl see dog man
  break glass cat
•


• OUTPUT see dog man break
  glass cat

16
Encoding scheme

• Random word representation
• - 31-bit vector for each lexical item, each
  lexical item is
• represented by a randomly-assigned
  different bit.
• - not semantic feature encoding

sleep 0000000000000000000000000000001
dog 0000100000000000000000000000000
woman 0000000000000000000000000010000
17
Training a network

• Incremental Input (Elman, 1993)
• Starting small strategy
• Phase I simple sentences (Elman, 1990, used
  10,000 sentences)
• - 1,564 sentences generated(4,636 31-bit
  vectors)
• - train all patterns learning rate 0.1, 23
  epochs
• Phase II embedded sentences (Elman, 1993, 7,500
  sentences)
• - 5,976 sentences generated(35,688 31-bit
  vectors)
• - loaded with weights from phase I
• - train (1,564 5,976) sentences together
• learning rate 0.1, 4 epochs

18
Performance

• Network performance was measured by Root Mean
  Squared Error
•

•
  the number of input
  patterns
• RMS error
  target output
  vector
•

•
  actual
  output vector
• Phase I After 23 epochs, RMS 0.91
• Phase II After 4 epochs, RMS 0.84
• Why can RMS not be lowered? The prediction task
  is
• nondeterministic, so the network cannot
  produce the unique output
• for the corresponding input. For this
  simulation, RMS is NOT
• the best measurement of performance.
• Elmans simulation RMS 0.88 (1990),
• Mean Cosine
  0.852 (1993)

19
Phase I RMS 0.91 after 23 epochs
20
Phase II RMS 0.84 after 4 epochs
21
Results and Analysis

• ltTest results after phase IIgt
• Output Target
• which (target which )
• ? (target lion )
• ? (target see )
• ? (target boy ) ?
• ? (target move )
• ? (target sandwich )
• which (target which )
• ? (target cat )
• ? (target see )
• ? (target book )
• which (target which )
• ? (target man )
• see (target see )
• ? (target dog )?

• Arrow(?) indicates the start of the sentence.
• In all positions, the word which is
• predicted correctly! But most of words
• are not predicted including the word
• who is not. Why? ? Training Data
• Since the prediction task is non-
• deterministic, predicting the exact next
• word can not be the best performance
• measurement.
• We need to look at hidden unit
• activations of each input, since they
• reflect what the network has learned
• about classes of inputs with regard to
• what they predict. ?Cluster Analysis, PCA

22

• Cluster
• Analysis
• The network
• successfully
• recognizes
• VERB, NOUN,
• and some of
• their subcategories.
• WHO and
• WHICH has
• different
• distance
• VERB-INTRAN
• failed to fit in
• VERB
• ltHierarchical

23
(No Transcript)
24
Discussion Conclusion

• 1. The network can discover the lexical classes
  from word order. Noun and Verb are different
  classes except the VERB-INTRAN. Also,
  subclasses for NOUN are classified correctly, but
  some subclasses for VERB are mixed. This is
  related to the input example.
• 2. The network can recognize and predict the
  relative pronoun, which,
• but not who Why? Because the sentences for
  who is not RP-obj, so who is just
  considered as one of normal subject in simple
• sentences.
• 3. The organization of input data is important
  and sensitive to the recurrent network, since it
  processes the input sequentially and on-line.
• 4. Generally, recurrent networks by using RTRL
  recognized sequential
• input, but it requires more training time and
  computation resources.

25
Future Studies

• Recurrent Least Squared Support Vector Machines,
  Suykens, J.A.K. Vandewalle, J., (2000).
• - provides new perspectives for time-series

• prediction and nonlinear modeling
• - seems more efficient than BPTT, RTRL SRN

26
References

• Allen, J., Seidenberg, M. (1999). The emergence
  of grammaticality in connectionist networks. In
  Brian MacWhinney (Ed.), The emergence of language
  (pp.115-151). Hillsdale, NJ Lawrence Erlbaum.
• Elman, J.L. (1990). Finding structure in time.
  Cognitive Science, 14, 179-211.
• Elman, J. (1993). Learning and development in
  neural networks the importance of starting
  small. Cognition, 48, 71-99.
• Elman, J.L. (1999). The emergence of language A
  conspiracy theory. In B. MacWhinney (Ed.)
  Emergence of Language. Hillsdale, NJ Lawrence
  Earlbaum Associates.
• Hertz, J., Krogh, A., Palmer, R.G. (1991).
  Introduction to the Theory of Neural Computation.
  Redwood City, CA Addison-Wesley.
• MacClelland, J. L., Kawamoto A. H. (1986).
  Mechanisms of sentence processing Assigning
  roles to constituents of sentences. (273-325). In
  J. L. McClelland D. E. Rumelhart (Eds.),
  Parallel distributed processing Explorations in
  the microstructure of cognition. Cambridge, MA
  MIT Press.
• Miikkulaninen R. (1996). Subsymbolic case-role
  analysis of sentences with embedded clauses,
  Cognitive Science, 20, 47-73.
• Rummelhart, D., Hinton, G. E., and Williams, R.
  (1986). "Learning Internal Representations by
  Error Propagation," Parallel and Distributed
  Processing Exploration in the Microstructure of
  Cognition, Vol. 1, D. Rumelhart and J. McClelland
  (Eds.), MIT Press, Cambridge, Massachusetts,
  318-362
• Rumelhart, D.E., McClelland, J.L. (1986). On
  learning the past tense of English verbs. In J.L.
  McClelland D.E. Rumelhart (Eds.), Parallel
  distributed processing Explorations in the
  microstructure of cognition. Cambridge, MA MIT
  Press.
• Williams, R. J., Zipser, D. (1989). A learning
  algorithm for continually running fully recurrent
  neural networks. Neural Computation, 1, 270--280.
