L'E'E'D' Education

1
Greening Police Facilities
2
Kingston Police Headquarters Project
L.E.E.D. GOLD CERTIFIED Leadership in Energy
Environmental Design
3

• The new Kingston Police Headquarters building
  constitutes a dramatic departure from the status
  quo in the design of police facilities.

4

• While many facilities focus only on security,
  ours also is an expression in brick and mortar of
  ways in which we can reduce environmental impacts
  and wisely use such resources as land, water,
  energy, and raw materials.

5

• The green building features incorporated into our
  facility demonstrate that building technologies
  and construction processes can be part of the
  solution to many of the environmental challenges
  facing society.

6
How did the Women and Men in Blue go GREEN?
7
City of Kingston Strategic Plan

• THE ENVIRONMENT
• We will create a sustainable community by
  conducting ourselves, individually and
  collectively, in a manner such that the net
  effect of our actions is a positive one. This
  will be measured by the ability of present and
  future generations to use and enjoy the world. We
  respect and protect our man-made and natural
  environments and we manage them through a
  collective commitment. Our pledge is to achieve
  improvements in the quality of air, water, and
  land through the protection, prevention, and
  remediation of the environment. We recognize the
  importance of our ecology and we know that
  positive change will come about through increased
  community awareness of the environmental
  challenges that we face.

8
City of Kingston L.E.E.D. Policy

• 4 May 2004
• "Council requires that all large municipal
  building and retrofit projects undertake an
  assessment of the Leadership in Energy
  Environmental Design (L.E.E.D.) as a design goal
  for Councils consideration before finalization
  of the project design."

9
What is L.E.E.D. Green Building Rating System ?

• The Canada Green Building Council (CaGBC) exists
  to accelerate the design and construction of
  Green Buildings across Canada. CaGBC has chosen
  L.E.E.D. as the accreditation of choice for green
  building in Canada. http//www.cagbc.ca/

10
What is L.E.E.D. Green Building Rating System ?

• The purpose is to promote a mainstream change in
  the industry toward sustainable facilities. One
  of the first steps the Council took was the
  adoption of a green building rating system. That
  system is L.E.E.D. which stands for Leadership in
  Energy and Environmental Design.

11
What is L.E.E.D. Green Building Rating System ?

• The rating system is based on a series of
  prerequisites and credits. The design team must
  verify that all of the prerequisites and a
  portion of the credits have been met.

12
What is L.E.E.D. Green Building Rating System ?

• Most of the credits are performance based, which
  means that they measure the degree of improvement
  relative to a recognized standard, rather than
  requiring the use of specific design strategies
  or technologies.

13
What is L.E.E.D. Green Building Rating System ?
Chart from Enermodal Engineering web site
www.enermodal.com
14
Design Charette

• July 2004
• The L.E.E.D. Police facility design was
  developed through a multi-disciplinary charette
  process and was approved by the design team, the
  Police Services Board and City Council.

15
Design Charette

• July 2004
•   With 42 L.E.E.D. credits targeted for
  implementation the L.E.E.D. Police facility was
  positioned to obtain a Gold designation (L.E.E.D.
  Gold 39 - 51 credits).

16
Energy Efficiency and Green House Gas Reduction

• These energy gains are made through the inclusion
  of upgrades to the envelope and lighting and
  mechanical systems.

17
Energy Efficiency and Green House Gas Reduction

• In comparison to the base-line (industry
  standard) the L.E.E.D. Police facility will
  result in an annual reduction of approximately
• 573,187 kwh electricity (39 reduction)
• 140,535 m3 natural gas (67 reduction) for an
  estimated total annual reduction of approximately
  444 tonnes of green house gas emissions (52
  reduction CO2 equivalents).

18
Natural Light Lantern

• Interior
• offices benefit
• from natural light

19
Windows

• Light shades,
• Solar Ban 60 and
• Solara glazing,
• operable windows

20
Water Efficiency

•  It is estimated that in comparison to the
  base-line (industry standards) the water use of
  this building will be approximately 77 (21,773
  m3 reduction) more efficient for indoor use and
  100 (12,007 m3 reduction) more efficient for
  outdoor use.

21
Water Efficiency

• This water efficiency is achieved by the
  inclusion of a rainwater cistern for toilets,
  ultra-low flow faucets, ultra-low flow
  showerheads and automatic controls on faucets.
  The landscaping includes drought resistant
  vegetation without an irrigation system.

22
Rainwater Cistern

• 30,000 L
• rainwater collection
• tank for all
• toilets

23
Landscaping

• Draught
• resistant
• grass and 64
• trees planted.
• Saved 6
• mature trees.

24
Materials and Resources

• 93 of construction waste was diverted from the
  landfill.
• Preference was given to recycled content
  materials.
• The majority of materials used in construction
  was manufactured within 800km of the site.

25
Construction Recycling

• 93
• Construction
• waste recycled

26
Recycled Materials

• Recycled
• Rubber used in
• Firearms range

27
Sustainable Sites

• The site provides for public transportation
  access, bicycle storage, showers and change
  rooms.
• Recycling Program
• Preferred carpool parking is included into the
  design.
• The project rehabilitated a brownfield area
  recognized within the Community Improvement Plan.

28
Recycling Centers

• All suites
• have recycling
• centers and a
• recycling program

29
Car Pool Program

• Preferred
• parking for
• participants

30
Facility Overview

• This 11,249 m² (121,000 sq.ft.) high risk, post
  disaster facility is a three storey (basement,
  ground and partial second floor) concrete frame
  with masonry veneer. This state-of-the-art
  sustainable building contains a variety of areas
  including administration, police vehicle storage,
  vehicle maintenance, training facilities/firearms
  range, detention facilities, forensic
  identification laboratories, community room as
  well as other areas related to daily police
  activities.

31
Green Guard Furniture

• All furniture is
• L.E.E.D.
• compliant,
• low off-gasing

32
Public Entrance

• Energy
• efficient LED
• lights in
• landmark sign

33
Occupancy

• October 1, 2007
• relocate from
• old facility

34
Achievements

• Opening Ceremony January 28, 2008
• LEED GOLD CERTIFIED
• Status by Canada Green Building Council
• With 45 points
• Commercial Building Incentive Program (CBIP)
  Grant, Natural Resources Canada
• Green Municipal Fund Loan 8.3 million,
• Federation of Canadian Municipalities

35

• The Kingston Police are excited and proud to
  relocate to a modern facility that will not only
  provide an adequate police facility for the
  Kingston community but a sustainable building for
  the City of Kingston.
