Optical Diagnosis and Treatment in Barretts Esophagus

1
Optical Diagnosis and Treatmentin Barretts
Esophagus

• Dr Laurence Lovat
• National Medical Laser Centre
• University College London, UK

2
Esophageal Cancer Rates (Men, Age Standardised
Mortality/105)
20 10 0
USA
US SEER data, 2004
3
Esophageal Cancer Rates (Men, Age Standardised
Mortality/105)
20 10 0
London UK USA
Thames Cancer Registries US SEER data, 2004
4
Esophageal Cancer Rates (Men, Age Standardised
Mortality/105)
20 10 0
Scotland NW UK London UK USA
Scottish, NW UK, Thames Cancer Registries US
SEER data, 2004
5
The Questions

• How do we prevent death from esophageal
  adenocarcinoma?
• How do we detect patients at risk?
• How do we best treat patients?

6
The Questions

• How do we prevent death from esophageal
  adenocarcinoma?
• How do we detect patients at risk?
• How do we best treat patients?

7
Detecting patients at risk

• 80 of cases of esophageal adenocarcinoma arise
  within Barretts esophagus
• Screening
• Endoscopy
• Invasive
• Not of proven value
• Less invasive techniques
• Nothing proven

8
Detecting patients at risk

• Surveillance
• Lifetime risk of cancer lt10
• Need to target high risk groups

9
Markers of Risk
Acid reflux, Bile acids, Cytokines
Cell Cycle G1-S G2, apoptosis
Cell Interactions adhesion, catenins
?
10
Cancer Risk in Presence of Aneuploidy or
Tetraploidy gt6
All patients without HGD at baseline
RR25
Years
11
p16, p53, ploidy Biomarker Panel Progression to
EA
Biomarker panel (9pLOH, 17pLOH, abnormal ploidy)
Dysplasia grade Seattle Criteria
4 Biopsies per 1-2 cm plus Targeted Biopsies
HGD
Probability of Cancer
ltHGD
Time (months)
12
Endoscopic Detection of HGD
13
Morphological Changes in HGD
200 mm
Non-dysplastic intestinal metaplasia High
grade dysplasia
14
Elastic Scattering Spectroscopy(Optical biopsy)

• Point measurement
• Wavelength dependence
• Scattering efficiency of tissue
• Sensitive to morphological changes
• Size, shape and density of nuclei mitochondria
• cellular density

15
Elastic Scattering Spectroscopy
16
Optical Biopsy
17
Elastic Scattering Spectra
18
Elastic Scattering Barretts Oesophagus
V1V3 vs V4V5 Sensitivity 92 Specificity
70 Negative predictive value gt99
19
ESS Optical Biopsies

• Perform 17 random biopsies
• OR
• 17 optical measurements and 7 biopsies

• Model
• 92 dysplasia sites detected
• Negative test gt99.5 reliable

20
Taking Optical Biopsy Forward

• Detecting patients at high risk who do NOT have
  dysplasia
• Can OB detect patients at risk

21
Detecting Field Change Effect

• Animal model of colon cancer
• Aberrant crypt foci is the first visible change
• ESS detects fingerprint of microarchitectural
  abnormalities BEFORE aberrant crypt foci visible
• ( Roy et al, Gastroenterology (2004) 126 1071)
• Human Colorectal Cancer Risk Stratification
• 37 patients
• Colonoscopy in those with/without previous
  adenomas
• Similar findings to animal models
• ( Roy et al, DDW 2005)

22
The Questions

• How do we prevent death from esophageal
  adenocarcinoma?
• How do we detect patients at risk?
• How do we best treat patients?

23
Treatment for HGD in Barretts Oesophagus

• Oesophagectomy
• Morbidity 40 Mortality 5
• Elderly patients
• Need for minimally invasive therapy

24
Mucosal Ablation

• Thermal (hot/cold)
• Laser
• MPEC
• Cryotherapy
• Photochemical (PDT)

25
The Ideal of Mucosal Ablation

• Selective mucosal
• destruction
• Ambulatory therapy
• No side effects Strictures Photosensitivity Acu
  te Hypotension Buried glands

Thermal Photofrin ALA PDT PDT No No Yes Yes Mayb
e No10 minutes 20 minutes 40 mins
2-5 30 0 None 2-3 months 1
day No No Yes Frequent Rare Very rare
26
Courtesy Professor H Barr, Gloucester
27
Courtesy Professor H Barr, Gloucester
Oesophageal strictures 25
28
PDT Results Barretts Esophagus

• ALA for HGD and T1 Ca in Barretts
• 66 patients (35 HGD)
• Median follow up 37 months
• (Pech GI Endoscopy 2005)
• Disease Strictures
• Free
• HGD 89
• 0
• T1 Ca 68

29
Results (ALA)

• From October 1999
• 75 patients treated
• (most after 2002)
• All had high grade dysplasia (V4)
• 3 studies
• High dose ALA (60mg/kg)
• Light dose ranging (low, medium, high light dose)
• RCT ALA 30 mg/kg with red v green light
• RCT ALA 60 mg/kg with red v green light

30
ALA 60 mg/kg (high dose)Red Light at various
doses
Log Rank P 0.008
31
ALA 30 mg/kg (low dose)Red v Green Light
Log Rank P 0.07
32
Rescue with high dose ALAand various light doses
Log Rank P 0.03
33
ALA PDT

• 75 patients treated
• Best regime 80 clearance HGD at 2 years
• Toxicity (all at 60mg/kg)
• 4 patients severe hypotension
• (prevented by rehydration and avoiding
  psychotropic drugs)
• 3 patients aspiration pneumonia
• 8 patients transient fever
• 2 patients asymptomatic jaundice, cleared in 5
  days

34
ALA PDT

• Looks promising but there are toxicity issues

35
Foscan Mucosal Selectivity
3.5
3.0
2.5
SELECTIVITY RATIO Between MUCOSA AND MUSCLE
2.0
1.5
1.0
0.5
0.0
4 hours
24 hours
4 days
36
Verteporfin photosensitiser(2mg/kg, activated at
15 minutes)

• 430 nm or 690 nm
• Experiments to assess
• Effects on pancreas

37
Duodenal PDT Histology
Mucosal ulceration
Loop of duodenum
Normal duodenum
38
Duodenal collagen resistant to damage
39
The Ideal of Mucosal Ablation

• Selective mucosal
• destruction
• Ambulatory therapy
• No side effects Strictures Photosensitivity Acu
  te Hypotension Buried glands

Verteporfin PDT Yes? Yes? 15
minutes 0? None? No? Very rare?
40
Conclusions

• Optical methods might be developed to detect
  patients at highest risk
• New PDT approaches to treat HGD in BE
• Can optical methods be used to assess the outcome
  of PDT?
