Carrier Ethernet over GPON and EP2P

1
Carrier Ethernetover GPON and EP2P
Metro Ethernet Forum

• Arie Goldberg
• Omnitron Systems Technology, Inc.
• agoldberg_at_omnitron-systems.com

2
Agenda

• Introduction to the Metro Ethernet Forum
• Driving forces for Carrier Ethernet
• Carrier Ethernet Services and Applications
• Five MEF attributes
• MEF Technical Documents and Certification
• EP2P and GPON Comparison
• First Mile and OAM
• EP2P and GPON Architectures / Implementations
• EP2P and GPON and the MEF 5 attributes
• Summary QA

3
Introduction to the Metro Ethernet Forum (MEF)
4
Metro Ethernet Forum

• Mission Statement
• The MEFs mission is to accelerate the worldwide
  adoption of Carrier-class Ethernet networks and
  services.
• What we do
• The MEF develops technical specifications and
  implementation agreements to promote
  interoperability and deployment of Carrier
  Ethernet worldwide.
• International Membership, November 2007
• 138 companies, 2/3 Vendors, 1/3 Service Providers

5
MEF Industry Leadership
Specifications and Liaison
Marketing Carrier Ethernet
Certification Program
6
Metro Ethernet Forum

• Process and Execution
• Five Attributes
• Specifications, Implementation Agreements, Test
  Specifications
• Vendor Equipment Certification
• Service Providers services Certification

7
Demand Drivers for Carrier Ethernet
On-line Government
Healthcare date Tele-medicine
Education Remote learning



NEW tools! Apps!


Backhaul Apps



Commerce, On-line
Business, Tele-workers, On-line
Financial Services, On-line
8
Stakeholders of Carrier Ethernet

• Service Providers
• Carrier Ethernet in the Metro Network
• Reduce Complexity of Network - Converged services

• Reducing CAPEX and OPEX
• Ethernet is less complex / expensive than legacy
  ATM/SONET/TDM
• Use Ethernet as a backhaul technology for access
  technologies
• Enables new revenue streams by providing new
  services
• Customers are demanding bandwidth - Ethernet
  services!

• Enterprises/SMBs
• Converged network services for business
  applications
• Data, VoIP, Video, conf, offsite-storage
• Need new applications
• Reduced technical complexity
• Reduced telecomm/IT costs
• Standardize on Ethernet
• Reduces Network management complexity
• Reduces requirements of telecomm/IT expertise /
  support cost
• Bandwidth transport (up to 10Gbps)
• High speed, low latency flexible service
• Easy incremental / scalability / upgrades of
  services

9
Services / Subscribers of Ethernet Services
HD TV TVoD, VoD
Gaming, Business Backup, ERP
Voice gateway
Voice/Video Telephony
Wireless Backhaul PSTN
Internet
Metro Carrier Ethernet
Mobile Backhaul
Access Carrier Ethernet over GPON
Enterprise Business Services
Small/Medium Business
Residential Triple-Play
10
MEF Service Types

• E-Line Service used to create
• Ethernet Private Lines (EPL)
• Virtual Private Lines
• Ethernet Internet Access
• EP2P upper layer services (IP-VPNs etc)

Point-to-Point EVC
UNI
UNI
Multi-point to Multi-point EVC
UNI
UNI

• E-LAN Service used to create
• Multipoint L2 VPNs
• Transparent LAN Service
• Multicast networks

UNI
UNI
Rooted Multipoint EVC

• E-Tree Service used to create
• P2MP Broadcast Services

UNI
UNI
11
Global Ethernet Services
Point-to-Point EVC
UNI
UNI
Point-to-Point EVC
UNI
Carrier B
NNI
UNI
Carrier A
Multi-point to Multi-point EVC
UNI
UNI
12
The 5 Attributes of the Carrier Ethernet
13
The Five Attributes of Carrier Ethernet

• Carrier Ethernet is a ubiquitous, standardized,
  carrier-class SERVICE defined by five
  attributes that distinguish Carrier Ethernet
  from familiar LAN based Ethernet
• It brings the compelling business benefit of the
  Ethernet cost model to achieve significant
  savings

Carrier Ethernet
Carrier Ethernet Attributes

• Standardized Services

• Scalability

• Reliability

• Quality of Service

• Service Management

14
The 5 Attributes Carrier Ethernet (1)
Attribute 1 Standardized Services

• Ubiquitous services provided locally globally
  via providers.
• E-Line, E-LAN, E-Tree provide transparent,
  private line, virtual private line and
  multi-point to multi-point LAN services.
• Using standardized equipment.
• Accommodates existing customer LAN equipment.
• Accommodates existing transport infrastructure
  technology including TDM.
• Enables converged voice, video data networks.

15
The 5 Attributes Carrier Ethernet (2)
Attribute 2 Scalability

• Enables different levels and variety of business,
  information, communications and entertainment
  applications with voice, video and data.
• Spans Access Metro to National Global
  Services.
• Utilizes a variety of physical infrastructures
  implemented by different Service Provider types.
• Supports a wide choice and granularity of
  bandwidthand quality of service options.

16
The 5 Attributes Carrier Ethernet (3)
Attribute 3 Reliability

• The ability for the network to detect recover
  from incidents without impacting customers.
• Meeting the most demanding quality and
  availability requirements.
• Rapid recovery time when problems do occur as
  low as 50ms.

17
The 5 Attributes Carrier Ethernet (4)
Attribute 4 Quality of Service

• Wide choice and granularity of bandwidth and
  quality of service options.
• Service Level Agreements (SLAs) that deliver
  end-to-end performance matching the requirements
  for voice, video and data over converged business
  and residential networks.
• Provisioning via SLAs that provide end-to-end
  performance based on committed information rate
  (CIR), frame loss, delay and delay variation
  characteristics.

18
The 5 Attributes Carrier Ethernet (5)
Attribute 5 Service Management

• The ability to monitor, diagnose and centrally
  manage the network, using standards-based vendor
  independent implementations.
• Carrier-Class OAM.
• Rapid service provisioning.

19
MEF Documents and Certification
20
Technical Document Types

• Technical Specification
• Document detailing the agreed upon definitions,
  scope, methods and procedures for a component of
  Carrier Ethernet
• Implementation Agreement
• A document describing an agreement as to how
  options in existing technical specifications or
  other standards bodies work shall be implemented
• Test Specification
• A document describing how attributes of Carrier
  Ethernet technical specifications will be tested
  for compliance against those specifications
• Also called Abstract Test Suite
• Position Statement
• An Outgoing Liaison with other standards
  organizations describing the MEF

21
Completed Specifications
22
Completed Specifications
23
Ethernet Standards Summary
Ethernet OAM
Architecture/Control
Ethernet Services
Ethernet Interfaces
Standards Body

• 802.3ah EFM OAM
• 802.1ag CFM
• 802.1AB - Discovery
• 802.1ap VLAN MIB

• 802.3 MAC
• 802.3ar Congestion Management
• 802.1D/Q Bridges/VLAN
• 802.17 - RPR
• 802.1ad Provider Bridges
• .1ah Provider Backbone Bridges
• .1ak Multiple Registration Protocol
• .1aj Two Port MAC Relay
• .1AE/af MAC / Key Security
• .1aq Shortest Path Bridging

-

• 802.3 PHYs
• 802.3as - Frame Expansion

IEEE

• MEF 7 EMS-NMS Info Model
• MEF 15 NE Management Req
• OAM Req Framework
• OAM Protocol Phase 1
• Performance Monitoring

• MEF 4 Generic Architecture
• MEF 2 Protection Req Framework
• MEF 11 UNI Req Framework
• MEF 12 - Layer Architecture

• MEF 10 Service Attributes
• MEF 3 Circuit Emulation
• MEF 6 Service Definition
• MEF 8 PDH Emulation
• MEF 9 Test Suites
• MEF 14 Test Suites
• Services Phase 2

• MEF 13 - UNI Type 1
• MEF 16 ELMI
• E-NNI

MEF

• Y.1730 Ethernet OAM Req
• Y.1731 OAM Mechanisms
• G.8031 Protection
• Y.17ethqos QoS
• Y.ethperf - Performance

• G.8010 Layer Architecture
• G.8021 Equipment model
• G.8010v2 Layer Architecture
• G.8021v2 Equipment model
• Y.17ethmpls - ETH-MPLS Interwork

• G.8011 Services Framewrk
• G.8011.1 EPL Service
• G.8011.2 EVPL Service
• G.asm Service Mgmt Arch
• G.smc Service Mgmt Chnl

• G.8012 UNI/NNI
• G.8012v2 UNI/NNI

ITU

• TMF814 EMS to NMS Model

-
-
-
TMF
24
EP2P and GPON Carrier Ethernet and the Five
Attributes
25
The Access / First Mile Technology Neutrality
26
First Mile / Access Link OAM (802.3ah)
Link OAM 802.3ah

NID
CE
CE
NID
UNI
UNI
UNI-N
UNI-C

• Link OAM Monitors and Reports UNI Link Faults and
  Performance
• Discovery
• Remote Loopback
• Fault Detection (hard faults e.g. link breaks /
  unidirectional, dying gasp)
• Link Performance Monitoring (soft errors,
  threshold based alarms)
• Collecting Performance Statistics (via OAM
  Extensions)

27
Service OAM (Y.1731/802.1ag)

UNI
UNI
CE
CE
OP B
OP A
Operator A MEG
Operator B MEG
EVC MEG
Subscriber MEG (Maintenance Entity Group)

• Service OAM Monitors and Reports Per Service
  end-to-end Performance
• 802.1ag end-to-end fault detection and
  management.
• Y.1731 end-to-end performance monitoring.
• Support multi-level details for different
  stakeholders
• Customer, Service Provider, Operator
• Performance Monitoring
• Delay, Jitter, Loss, Availability
• Enable SLA monitoring, documenting, policing

28
EP2P as Ethernet Access Network

Ethernet Layer Topology
Access Bridge
NID
Metro CarrierEthernet
UNI
NNI

• Access Bridge
• Traffic Aggregation
• Network Interface Device (NID)
• Service (EVC, CoS, Rate-Limiting) Mapping
• Ethernet Link OAM (with Access Bridge and CPE)
• End-to-End Service OAM
• Provides the User-to-Network Interface

29
GPON as Ethernet Transport Access Network
Access Bridge
NID
Ethernet Layer Topology

Metro CarrierEthernet
UNI
NNI
Transport Layer Topology

GPON OLT
GPON ONT

• GPON provides transport
• Transparent to the Ethernet service traffic
• Link OAM
• Ethernet Link OAM - not available between Bridge
  and NID
• Can use GPON Link OAM

30
GPON as Ethernet Service Access Network

Ethernet Layer Topology
NNI
Metro CarrierEthernet
UNI
GPON OLT
GPON ONT

• GPON network participates in MEF Implementation
  Agreement
• OLT participates in NNI requirements
• Traffic Aggregation
• Link Aggregation
• ONT participate in UNI requirements
• Business ONT (w/ NID features)
• Service (EVC, CoS, Rate-Limiting) Mapping

31
Standardized Services
EP2P
GPON
GPON ONT
UNI
GPON OLT
NID
NID
UNI
UNI
UNI
32
Scalability
EP2P
GPON
20 Km max
150 Km max
Distance
33
Quality of Service
EP2P
GPON
Dedicated Bandwidth 10Mbps to 10Gbps
Bandwidth
2.5 Gigabit Shared Bandwidth
34
Reliability
EP2P
GPON
X
X
X
X
X
X
Link Redundancy with Geographic Path Diversity
35
Service Management
EP2P
GPON
SNMPvX TELNET
OMCI
36
In Summary Comparison of 5 Attributes
EP2P Ethernet
GPON
Standardized Service
E-Line, E-LAN
E-Line, E-LAN
Scalability
Wide BW upgrade options, wide distance reach
Limits BW upgrade options
Quality of Service
More BW options, TDM emulation
Native TDM
Reliability
Per user / multi-user faults, weak redundancy
Per user faults, Strong Redundancy options
Service Management
Link OAM only
Link and Service OAM
37

• Summary
• MEF is First Mile technology neutral
• Each First-Mile access method has strengths and
  weaknesses
• Service Providers choice should be based on its
  specific market requirements and economics
• End users choice should be based on its specific
  needs
• QA

38

• Thank you
• More at www.metroethernetforum.org
