Title: Energy: Conservation, Work, and Transformations


1
Energy Conservation, Work, and Transformations
2
Part 1
  • Law of Conservation of Energy

http//www.thingofthemonth.com/images/uploads/newt
3
Energy
  • Energy is a scalar quantity that describes the
    ability to do work.
  • There are many forms of energy.
  • Energy is measured in Joules (J).

4
The Law of Conservation of Energy
  • Energy can not be created or destroyed.

5
Roller Coaster Analysis
http//picdit.wordpress.com/page/2/
  • The ball has the greatest potential energy (PE
    mgh) right before the moment of release.
  • It is not moving so it has no kinetic energy.
  • Therefore, the potential energy at this point is
    the total energy available in the system.

6
Energy Conservation
  • Kinetic energy (KE 1/2mv2) at the lowest point
    of the roller coaster should be equal to the
    total energy of the system because there is no
    potential energy at that point (h0)
  • Kinetic energy at the lowest point of the roller
    coaster should equal potential energy at the
    release point.

7
Why dont the calculations match?
  • Both air resistance and friction act on the ball,
    transforming some of the kinetic energy to
    thermal energy (heat).

8
Conclusion
  • Energy is never created or destroyed, but it does
    change its form.

9
Part 2
http//www.coolschool.ca/lor/SC9/unit16/U16L04/Sim
  • Work-Energy Theorem and Machines

http//tutor4physics.com/workliftbox.gif
10
Work
  • A transfer of energy that occurs when a force
    makes an object move in a direction parallel to
    the force.

11
  • FORMULA
  • W F X d
  • (Joules) (Newtons)
    (meters)
  • Work Force X Distance

12
EXAMPLEIf the force is 20N and the distance is
2m, Work F X dW 20N X 2mW 40 Joules
13
Work-Energy Theorem
  • The net work done on an object equals its change
    in kinetic energy.

14
FORMULA
  • W ?KE KEf KEi
  • Work Change in Kinetic Energy
  • Both Work and Energy are measured in Joules (J)

15
Power
  • amount of work done in a certain amount of time.

16
  • FORMULA
  • P W ? t
  • (Watts) (Joules)
    (seconds)
  • Power Work Divided by Time

17
EXAMPLEIf work is 20J and the time is
10s,Power W ? TP 20J ?10sP 2 Watts
18
Machine
  • A device that makes work easier.

19
The Six Simple Machines
20
Compound Machine
  • A machine made up of more than one simple
    machine.
  • The apple corer/peeler contains wedges, a wheel
    and axle, a lever, and a screw.

http//www.kitchenutensilsstore.com/sites/dmbalko/
_files/Image/apple-corer-peeler.jpg
21
How Do Machines Make Work Easier?
  • Since work equals force times distance, you can
    do the same amount of work by applying
  • small force, long distance
  • OR
  • large force, short distance

22
  • FOR EXAMPLE
  • If you have a force of 2N and a distance of 50m,
  • WORK FORCE X DISTANCE
  • WORK 50N X 2m
  • WORK 100 JOULES
  • If you have a force of 100N and a distance of 1m,
  • WORK FORCE X DISTANCE
  • WORK 100N X 1m
  • WORK 100 JOULES

23
  • If you increase the distance,
  • the amount of force needed to do the
  • work is reduced.

24
Mechanical Advantage
  • Describes the factor by which the effort force is
    multiplied by the machine

25
Pulley Station
  • Increasing the number of pulleys and support
    strings increased the distance over which the
    force was applied.
  • This caused an increase in mechanical advantage.

http//www.miniscience.com/projects/pulley/
26
How much of the input work is changed into useful
output work by the machine.
Efficiency
27
  • FORMULA
  • W0 X 100
  • WI
  • EFFICIENCY WORK OUTPUT X 100
  • WORK INPUT

28
THE EFFICIENCY OF A MACHINE IS ALWAYS LESS THAN
100 BECAUSE SOME ENERGY IS CONVERTED TO HEAT DUE
TO FRICTION.
29
EXAMPLEIf the input work is 100J and the
output work is 50J, EFFICIENCYWORK OUTPUT X
100 WORK INPUT
EFFICIENCY 50J X 100
100J EFFICIENCY 0.5J X 100 50
30
  • HOMEWORK
  • PROBLEMS
  • Copy the following problems and complete them for
    homework.

31
1. When you and a friend move a 45kg couch to
another room, you exert a force of 75N over 5m.
How much work did you do? (DONT FORGET UNITS)
32
2. How much power is required to push a car for
10 seconds if the amount of work done during that
time is 5500 Joules? (DONT FORGET UNITS)
33
3. What is the efficiency of a machine which has
the input work of 20J and the output work of 5J?
(DONT FORGET UNITS)
34
  • 4. Initially, a 2 kg ball is flying through the
    air at a speed of 10 m/s. The speed of the ball
    is reduced to 8 m/s by air resistance. How much
    work is down on the ball by air resistance?

35
Part 3
  • Energy Transformations

http//www.eia.doe.gov/kids/energyfacts/science/im
ages/EnergyTransformations.gif
36
Types of Energy
37
Station 1
  • Food contains chemical energy
  • We eat food to obtain energy.

http//thebarefootkitchenwitch.typepad.com/the_bar
efoot_kitchen_witc/2008/02/valentines-da-1.html
38
Station 2
  • The rubber band will go flying if you stretch and
    then release it.
  • This is a conversion of elastic potential energy
    to kinetic energy.

http//magic.about.com/od/libraryofsimpletricks/ss
/rubberband_3.htm
39
Station 3
  • The rubber ball has gravitational potential
    energy when you hold the ball.
  • Gravitational PE is converted to kinetic energy
    when you drop it.

http//www.dkimages.com/discover/previews/783/4371
40
Station 4
http//www.thesciencefair.com/Merchant2/graphics/0
0000001/CrookesRadiometer_M.jpg
http//www.holymeatballs.org/2007/06/sl_gk_light_b
ulb_system.html
  • Radiant energy from the light bulb is converted
    into kinetic energy to make the flags of the
    radiometer spin.
  • The light bulb also converts electrical energy
    from the outlet to radiant and thermal energy.

41
Station 5
http//www.amazon.com/Genecon-Hand-Generator/dp/B0
00701AZC
http//www.holymeatballs.org/2007/06/sl_gk_light_b
ulb_system.html
  • The mechanical energy of spinning the hand
    generator handle is converted to electrical
    energy.
  • The electrical energy is then converted to
    radiant and thermal energy, lighting the light
    bulb.

42
Station 6
  • Chemical energy in the battery is converted to
    electrical energy that travels down the wire and
    is converted to kinetic energy when the handle of
    the hand generator spins.

http//www.amazon.com/Genecon-Hand-Generator/dp/B0
00701AZC
http//www.focusonprice.com/images/JD014.jpg
43
Station 7
  • The chemical energy of the gasoline is converted
    to thermal energy and kinetic energy as the car
    moves around the track.

http//www.pistonheads.com/Noble/default.asp?story
Id11930
44
Station 8
  • Chemical Energy in the lemon is converted to
    electrical energy.

http//hilaroad.com/camp/projects/lemon/lemon_batt
ery.html
45
Station 9
  • Radiant energy is converted to electrical energy
    to power the calculator.

http//www.pocketcalculatorshow.com/calculator/ind
ex7.html
46
Station 10
  • The roller coasters gravitational potential
    energy at the top of the hill is converted to
    kinetic energy on the way down.

http//picdit.wordpress.com/page/2/
