TruSecure

1
How do you think about risk? The state of
Internet Security
Dr. Peter Tippett
2
ICSA.net Corporate Overview
3
ICSA Uniquely Positioned To Provide Internet
Security

• ICSA.net - Customer solutions and support for
  continuous and dynamic Internet security
  assurance
• Leverages expertise and framework from ICSA Labs
• Publishes Information Security Magazine
• Over 200 companies rely on ICSAs TruSecure
  process

• ICSA Labs - Set Standards, Perform Research,
  Track and Measure Risks, Lead Industry,
  Test and Certify Products
• Anti-Virus Products 100
• Firewall Products 100
• Malicious Mobile Code 100
• Internet Service Providers 80 of Backbone
• Cryptography Products 100 IPSec
• Intrusion Detection Systems 80
• Commercial Biometrics Products

4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
ICSA Studies Show Internet Security is Weak and
Breaches are Costly

• 28 new high priority security vulnerabilities
  logged and distributedeach month by ICSA Labs
• 200-300 new viruses are released each month with
  about 5 making it to the wildlist
• 93 million is the estimated cost of the Melissa
  virus to US businesses

13
Todays Corporate SecurityWorse Than Expected
ICSA Vulnerability Study May 1999

• Over 70 of sites with firewalls still vulnerable
  to known attacks
• Over 60 of sites susceptible to denial of
  service attacks
• Over 80 dont know whats on their network and
  visible over the Internet
• Over 80 have insufficient security policies

14
Complexity
Vulnerability
15
Risk Threat Vulnerability EventCost

• Threat
• The likelihood that a security event will happen
  in a given time span or the rate.
• Security Event Rate (per month, hour etc.)
• Composed of world-wide rate modified by local
  Target Index, other factors.
• The threat of purse-snatching by breaking the
  passenger window of a car with a heavy object
  was zero nationwide in 1960 (it never happened)
• The threat became significant in Miami in 1970
• The threat in Iowa City is still zero.

16
Risk Threat Vulnerability EventCost

• Vulnerability
• A given target is either vulnerable or not to a
  particular well defined threat (0 or 1).
• A given target is variably vulnerable to a class
  of threats. (Vulnerability between 0 and 1)
• A given organization is composed of numerous
  targets which, as a group, are variably
  vulnerable to a given threat category
  (Vulnerability Index)
• Car passenger windows have always been vulnerable
  to breakage by heavy bricks moving fast enough
• Since there was no threat until 1970, there was
  no risk until 1970.

17
Risk Threat Vulnerability EventCost

• EventCost
• Security Events result from a threat successfully
  exercised against a vulnerable system.
• The total costs of all of the ramifications of a
  security event are made up of numerous factors
  and include both hard and soft costs.
• Total sum of all ramifications of a security
  event called EventCost Dollars per SecurityEvent

18
Risk Threat Vulnerability EventCost

• If Threat 0Vulnerability 0or EventCost
  0There is no Risk
• Risk per Year
• Of these, we have
• good control over Vulnerability,
• some control over EventCost and
• minimal control over Threat Rate

19
Risk
20
All Risks are Not Equal
Cost / Impact
21
ICSAs Five Categories of Risk

• Electronic
• (External / Internal)
• Hacking, Sniffing
• Spoofing
• Malicious Code
• Viruses, Worms
• Java, ActiveX
• Trojans
• Physical / Human
• Theft, Social Engineering
• Sticky-note
• Terminal hijack

• Privacy
• employee
• customer data
• corporate data
• DownTime
• DoS attacks
• Bugs
• Power
• Civil Unrest
• Natural Disasters

22
Controls Doing Something About Risk
ICSA Control Matrix
Objective of the Control
Protect
Detect
Recover
AdministrativeHuman Factors
Technical Application/Service
Category
Technical System / Platform
TechnicalNetwork / Logical
Physical Environment
23
Controls Themselves Have Costs

• Software, hardware, training costs
• Infringement costs
• User / network management time (costs)
• Reduction of opportunity costs

24
What kind of controls actually work?

• Most security strategies are based upon
• Very strong controls
• Static in nature
• Made to last without changes
• Heavily based on policy and user education
• Tend to be infringing on time, users, resources
  (and patience)
• Tend to be costly

25
Static Controls

• Not only costly, but --- Effectiveness declines
  over time
• B1
• C2
• Completely Re-engineer the system
• Comprehensive Local Risk Assessments
• Simple Local risk assessments
• Tiger team assessments

26
Minimizing total costs
27
Synergistic Controls Increased effectiveness,
less infringing
Objective of the Control
Protect
Detect
Recover
Physical
Your Data Systems
Environment
Technical
Network / Logical
Category
Technical
System / Platform
Technical
Application/Service
Administrative
Human / Policy
28
Line up Synergistic Controls Each With
Independent Effectiveness (I)
Why is this effective?
Total efficacy - at constant level of
effectiveness 50 60 70
80 90
serial screens
1 2 3 4 5
50.0 75.0 87.5 93.8 96.9
60.0 84.0 93.6 94.7 99.0
70.0 91.0 97.3 99.2 99.8
80.0 96.0 99.2 99.8 100.0
90.0 99.0 99.9 100.0 100.0
29
Security Assurance Dynamic Risk Reduction
30
Line up Synergistic Controls Each With
Independent Effectiveness (II)
Example 1
Serial policies
Effectiveness
Level of risk reduction
Simple, broad security practices, high compliance
rate Keep sys admins abreast of current threats,
vulnerabilities, and corrective
actions Frequently verify compliance of
technical and other practices
80 80 80
5 - fold 25 - fold 125 - fold
or or or
80.0 96.0 99.2
31
Most want very strong, static controls, made to
last
Resistance to threat as ()
Dynamic,Synergistic methods
Fundamental System design
1/mo
Audits Assessments
2/mo
Tiger Team
4/mo
21
22
23
24
Months
32
Dynamic Security Assurance Life Cycle (1 of 2)
Real,Prevalent, Costly, Risks
Analysis of Potential Risks
11 Risk Categories
Exceedingly Rare
Postulated, Theoretical
w/o Significant Impact
Elucidation of Possible Controls
33
Dynamic Security Assurance Life Cycle (2 of 2)
Public Vetting
Controls
Practical, Attainable Now-Oriented Security
Practices
34
Security Needs a Web Approach
35
Requirements For Security That Works
36
(No Transcript)
37
Internet Security That Works
38
The TruSecure Security Solution

• A fully integrated suite of products services
  providing real-time security assurance.
• A proven solution based on years of research from
  the trusted authority on security.

39
TruSecure Continuous Real-time Internet Security
Security roadmap for IP-enabled companies
Comprehensive verification, measurement and
support
continuous
continuous
Updates, alerts and recommendations
Cost-effective process to protect against
important vulnerabilities

• 24x7 Vigilance
• Biweekly e-mail monitor
• Information on emerging threats
• Ad hoc alerts released as needed
• Security analysts available to help with sudden
  emergencies

40
TruSecure Most Cost-Effective Solution
Cost Effectiveness
Scope

• Maximizes effectiveness of existing security
  products
• No new products required
• Provides evaluation and configuration
  recommendations for installed products
• Off-loads security research from internal IS
  department, freeing them to shift focus to other
  tasks

41
TruSecure Deliverables

• SecureGuide
• TruSecure Monitor
• Security Analyst Support
• Perimeter Check
• Intranet Assessment
• Onsite Visit
• Performance Reports
• Certification
• Emergency Alerts
• Repeated Assessments
• Open Communication

Human / Policy
Application / Service
OS / Platform
Network / Logical
Environment / Physical
42
TruSecure Unmatched Support For Multi-Vendor
Environments

• Trusted relationships with all of the leading
  security vendors (over 120)
• Backed by 10 years of product testing and
  certification programs
• Deep understanding of all security products,
  their strengths and limitations

43
Why TruSecure Works Better
44
Chosen by over 200 Corporations
45
TruSecure Effective Security

• Addresses real and current vulnerabilities
• Provides concrete and timely recommendations for
  addressing security issues
• Takes advantage of existing people and in-place
  security products
• Reevaluates security implementation on a regular
  basis to monitor progress

46
TruSecure Effective Security That Works!
87 Improvement for TruSecure Sites

• Measures and evaluates current vulnerabilities
• Provides concrete recommendations (Secure
  Guide) for addressing security issues
• Takes advantage of existing people and in-place
  security products
• Re-evaluates security implementation on a regular
  basis to monitor progress

100
90
80
70
60
50
40
30
20
Test Only
10
0
Day 30
Day 120
47
TruSecure Smart Security that Works

• Enables Technology Deployment
• Superior Risk Management
• Improved ROI on Security Investments
• Conscious Business Decisions on Risk Reduction
• Continuous Effective Security
