Emergency Stabilization Techniques

1
Emergency Stabilization Techniques

• A. Kirsten Lawson, DVM, DACVECC
• Puget Sound Veterinary Referral Center, PLLC
• 27th January 2008

2
Hershey

• 2yr MN Labrador
• HBC
• Carried into clinic by owners

3
Hershey Primary scan

• Airway clear
• Breathing pant
• MM pale, moist
• CRT 3-4 seconds
• HR 210
• Pulses weak, thready femoral pulse
• Lung fields audible on right, inaudible on left
• Non-ambulatory swollen left thigh with dangling
  lower limb.

4
Hershey Primary assessment

• Shock Hypovolemic
• Pain
• Suspect pneumo- or hemothorax on left
• Suspect left femur fracture

5
Hershey Initial treatment

• Pain medication
• IV fluids
• Thoracocentesis

6
Hershey Pain Control

• OPIODS
• Only realistic option in a trauma case. NSAIDs,
  sedatives, anesthetic agents should not be used
  in an unstable patient.
• Hydromorphone/oxymorphone ideal because they can
  be given IV with minimal risk of anaphylaxis. If
  morphine is given go IM or very slow IV

7
Hershey Pain control

• Partial Agonists
• Butorphanol is very effective if given at high
  enough doses (0.4mg/kg), however very short
  acting maybe only 2-4 hours.
• Advantages less likely to induce vomiting, will
  not induce panting (may be ideal if thoracic
  trauma is present)

8
Hershey Pain control

• Non-opioids if the animal is frantic and
  sedation is also needed, try diazepam/midazolam.
• NO Acepromazine marked vasodilation,
  contraindicated for an unstable patient.

9
Hershey Pain Control

• Roughly 65 pound dog about 30 kgs.
• Concern for thoracic trauma
• Butorphanol
• 12mg IV

10
Hershey IV Fluids

• IV catheter LARGE BORE minimum of 18g in this
  dog, short not more than 4 inches (i.e. no
  central lines)
• Balanced electrolyte solution (NormR, Plasmalyte,
  LRS) or normal saline solution (0.9NaCl)

11
Hershey IV Fluids

• Shock Dose?
• NO

12
Hershey IV Fluids

• Downsides to the shock dose of IVF
• Normo/hypertension can lead to pop the clot
  phenomenon
• Edema can lead to decreased tissue perfusion
• Altered electrolytes especially high chloride
  if using saline
• Possibly hypotension from acetate buffered fluids
  (unlikely)

13
Hershey IV Fluids

• End Point Resuscitation
• What end points controversial.
• Blood pressure (or pulse pressure if BP cannot
  be measured
• Normalize Heart rate
• Mm, crt
• Urine output, mentation, oxygen delivery
• 20ml/kg crystalloids 5ml/kg colloids
  (hetastarch or dextran70)
• Repeat to effect

14
Hershey IV Fluids

• Hypotensive resuscitation for trauma avoid
  further hemorrhage
• No more than 90mmHg systolic
• Normalize/improve CRT

15
Hershey IV Fluids

• 600ml Norm R 150ml Hetastarch IV
• Crt 2 seconds, mm light pink
• HR 150
• BP 84mmHg
• STOP

16
Hershey Thoracocentesis

• Should you always tap first or radiographs
  first?
• Depends on degree of cyanosis/dyspnea and
  confidence in diagnosis based off auscultation
  alone.
• Cons to tap without rads not without risk
  could cause lung laceration or laceration of an
  intercostal vessel. Also localize tap based on
  air (tap caudodorsal) vs fluid (tap
  cranioventral).

17
Hershey - thoracocentesis

• Pneumothorax more common than hemothorax in
  trauma cases
• Thoracocentesis on left between in dorsal 8th
  intercostal space.
• 700ml of air, few drops of blood, then negative
  pressure

18
Hershey Secondary scan

• Mentally alert and responsive
• MM pink, moist, crt 1-2 seconds.
• RR varies from 30 to pant
• BP 94mmHg systolic, palpable distal pulses
• Audible lung sounds throughout both fields
• Non-painful abdominal palpation with no fluid wave

19
Hershey Secondary Scan

• Partial thickness abrasions on rear legs and
  caudal ventral abdomen.
• No external bleeding noted.
• Palpable left mid femoral fracture normal
  withdrawl and sensation
• No blood on rectal no overt pelvic instability
• Will stand on three legs with assistance and try
  to walk.

20
Hershey - Plan

• Radiographs thorax, abdomen, pelvis, left
  femur. Ideally two views each
• PCV/TP monitor q 6 to 8 hours
• Monitor RR, effort, mm color, CRT recheck
  rads/retap if concern for returning pneumothorax,
  also at risk for developing pulmonary contusions.
• Monitor urine output
• Monitor mentation

21
Hershey - Plan

• Continue IVF and monitoring
• Ideally stable x 24 hours prior to surgery for
  femoral fracture
• Hydromorphone, morphine, or MLK cri for pain
  control
• Splint only if spica which may be more
  trouble than its worth if surgery can be done in
  timely manner.

22
Ramses

• 6yr MN DSH
• Presenting complaint weak, not eating,
  declining over 2 days.

23
Ramses Primary Scan

• Obtunded, laterally recumbent
• Mm pale, tacky, crt 3-4 seconds, oral ulcers
  noted
• Severe bradycardia HR 90bpm, no palpable
  femoral pulses
• Severe hypothermia 87F
• Very large, firm, inexpressible bladder

24
Ramses Primary assessment

• Urethral Obstruction
• Bradycardia suspect hyperkalemia
• Obtunded suspect secondary to poor
  perfusion/shock state

25
Ramses Initial Treatment

• Treat Hyperkalemia
• Unblock
• IVF
• Pain control
• Active rewarming

26
Ramses Active rewarming

• Bair Hugger
• Warm water bottles, warm blankets caution with
  how hot they are and be especially aware in a
  mentally altered patient or physically
  handicapped patient who cannot move away from the
  heat source.
• Warm IVF (1min in microwave /- fluid line warmer)

27
Ramses Hyperkalemia Diagnosis

• ECG or lytes?
• ECG bradycardia, loss of P waves, spiked T
  waves and a sinoventricular rhythm

28
Ramses - Hyperkalemia

• Options
• Dextrose causes endogenous insulin release that
  drives K intracellularly
• HCO3 causes alkalosis to drive K
  intracellularly (risk hypernatremia, paradoxical
  cerebral acidosis)
• Ca Gluconate protects heart from high K. Give
  slow (over 10-20min) while watching ECG or
  ausculting heart/palpating pulses.

29
Ramses - Hyperkalemia

• Given 6mls 25 dextrose IV bolus (dilute 50
  dextrose with sterile water to decrease risk of
  hemolysis)
• Given 6mls CaGluconate over 15 minutes
• ECG went from sinoventricular rhythm to NSR with
  spiked T waves HR increased to 150, palpable
  weak femoral pulses, improved crt.

30
Ramses Pain control

• 2mg butorphanol IV
• Obtunded means still responsive to pain!

31
Ramses - Unblock

• Unblocked with tomcat catheter switched to soft
  indwelling catheter with closed collection system
  (clamps removed from line)
• No anesthesia needed if needed etomidate
• No ketamine! increases myocardial workload

32
Ramses IV Fluids

• Lytes obtained while giving calcium
• Na 128, K 10.3, Cl 97, BG 378
• Ideally balanced electrolyte solution if you
  know your sodium try to match it to minimize
  sodium shifts.
• LRS 120ml bolus (warm) (20ml/kg)

33
Ramses Secondary scan

• Improved mentation
• HR 160 with palpable femoral pulses
• Mm pink, crt 2-3 seconds
• Abdominal palpation unremarkable
• Previous rear limb amputation
• Can sit sternal on own and stand with assistance.

34
Ramses labs (pre-treatment)

• BUN gt 130
• Crea gt 12.1
• Phos gt 16.1
• tCa 7.1
• PCV/TP 43/7.4

35
Ramses secondary assessment

• Severe azotemia hopefully post-renal /-
  pre-renal
• Concern for continued shock state- still weak
  pulses (BP not checked-conserving finances),
  delayed crt and abnormal mentation

36
Ramses - IVF

• Has had 1 bolus more fluids?
• Yes and No
• Hypothermic cats often wont come out of shock
  until rewarmed and if given large amounts of
  fluid when hypothermic risk of fluid overload
  once temperature has normalized.
• However needs aggressive rehydration and diuresis
  60ml/hr

37
Ramses doing well

• Over next 3 hours
• Became normothermic
• HR remained 160 stronger femoral, distal pulses
• Mentation improved
• Crt normalized, improved color

38
Ramses - oops

• Grand Mal Seizure - hypoglycemia
• Why?
• Theory
• Massive endogenous insulin release from dextrose
  bolus
• Changed protocol now put cats on dextrose cri
  for at least 12 hours after dextrose bolus.
• 3ml 25 dextrose bolus and spiked fluids to 2.5
  dextrose

39
Ramses - labwork

• At time of seizure
• BG 33
• HCO3 6.6 severe metabolic acidosis
• Na 148
• K 6.1
• iCa wnl at 1.4

40
Ramses metabolic acidosis

• Likely due to both uremic acidosis and lactic
  acidosis
• Give Bicarbonate?
• Yes due as appeared volume replete and the
  acidosis was severe
• Another fluid bolus also given when ins and outs
  calculated and marked post-obstructive diuresis
  noted.

41
Ramses - Bicarbonate

• HCO3- deficit 0.5xBW(kg)x(10-current HCO3-)
• Give ½ of deficit as NaHCO3 over 3 to 6 hours in
  regular fluids then recheck.

42
Ramses - IVF

• Changed IVF to Norm R why?
• Trying to match Na levels some concern about
  abrupt shift due to free water loss with
  post-obstructive diuresis no way to
  prevent/predict check frequently.

43
Ramses - Labwork

• Recheck labs in 2.5 hours
• HCO3- 18.7
• Na 153
• K 3.9
• BG 115
• Discontinued NaHCO3, added 20mEq KCl/L

44
Ramses 24 hours

• Continued on diuresis, antibiotics, pain
  medication, measuring ins/outs
• Initial urine pH 8.0 fragments crystals
  unidentifiable likely struvite
• Recheck labs
• Normal renal values!
• BG 264
• Discontinued dextrose supplementation, removed
  urinary catheter

45
Ramses oops again

• Reblocked
• Needed propofol this time unblocked another
  24 hours on IVF, u. cath
• Straining after u. cath removal but able to
  urinate!
• Home finally!

46
Questions?
