Title: Temperature, Heat,


1
Chapter 21
  • Temperature, Heat, Expansion

2
Temperature, Heat Expansion
  • Atoms and molecules have kinetic energy
  • The average kinetic energy of these particles
    causes heat
  • To increase the KE of matterwarm the matter

3
Temperature
  • Temperaturethe quantity that tells how hot or
    cold something is compared with a standard
  • Almost all mater expands when its temperature
    increases and contracts when its temperature
    decreases
  • A common thermometer measures temperature by
    showing the expansion and contraction of a liquid
    in a glass tube using a scale

4
Temperature Scales
  • Celsiusmost widely used scale
  • 0 assigned to temperature in which water freezes
  • 100 assigned to temperature in which water boils
  • The gap between is divided into 100 equal
    partsdegrees
  • Fahrenheitthe US scale
  • 32 assigned to temperature in which water freezes
  • 212 assigned to temperature in which water boils
  • The gap between is divided into 180 equal
    partsdegrees
  • F 9/5 C 32 C 5/9 (F 32)
  • Kelvinthe SI scale
  • 0 assigned to the lowest possible
    temperatureabsolute zero
  • Absolute zero (-273ºC 0ºK)
  • a substance has no KE (no heat to give)
  • K C 273.15
  • 1ºC 1ºK

5
Temperature Kinetic Energy
  • Do molecules move faster in a cup of hot coffee
    or a cup of cold coffee?
  • Hot coffee Greater temperature ? more kinetic
    energy (speed)
  • In an ideal gastemperature is proportional to
    the average KE of the translational motion of
    molecules
  • Temperature is not a measure of total KE
  • In 3 cups of boiling water there is 3 times as
    much KE as 1 cup of boiling waterbut the
    temperatures are the same

6
Heat
  • Heat is the energy that flows because of
    temperature differences
  • No matter can contain heat
  • Heat is energy in transit from a body of higher
    temperature to a body of lower temperature
  • Temperature is the measure of internal energy of
    a substance
  • When heat is added to a substance, the internal
    energy (temperature) increases
  • Temperature is not the same thing as heat

Cup of very high-temperature water contains less
internal energy than large bucket of warm water
Consider boy holding a sparkler 2000oC sparks
dont bother him since they are so small very
little internal energy.
7
Heat
  • Objects or substances are in thermal contact when
    heat flows from one object to another
  • Heat flows from the higher temperature substance
    to the lower temperature substance (unless
    external work is done)
  • Not necessarily from object of high internal
    energy to low internal energy
  • If spark from sparkler lands in warm water (water
    has higher internal energy but less temp), heat
    flows from spark to water
  • The greater the temperature difference, the
    greater the heat flow
  • Greater heat flow if the amount of hotter
    substance is larger.

Here, add the same amount of heat, therefore
increase the internal energy of both the same.
But temperature in the one with less water rises
more.
8
Thermal Equilibrium
  • Objects are in thermal equilibrium after they
    reach the same temperature
  • Thermometer
  • Is in contact with a substance, heat flows
    between them until they have the same temperature
  • The temperature of the thermometer is the
    temperature of the substance
  • The thermometer has to be small enough that it
    doesnt affect the temperature of the object you
    want to measure
  • You can measure your bodys temperature with a
    thermometer but you cant measure the temperature
    of a drop of water with it
  • Contact between the thermometer and drop can
    change the drops temperature.
  • You heat a half-cup of tea and its temperature
    rises by 4ºC. How much will the temperature rise
    if you add the same amount of heat to a full cup
    of tea?
  • 2ºC
  • Where does the internal energy go when a cup of
    hot tea cools?
  • It goes into warming the surroundings. Soon the
    tea will be cooler and the surroundings warmer.
    They will achieve thermal equilibrium at a common
    intermediate temperature

9
Internal Energy
  • There are forms of energy in molecules other than
    translational (linear) KE
  • Rotational KE of molecules
  • KE due to internal movements of atoms within
    molecules
  • PE due to forces between molecules
  • All of these energies added together is called
    internal energy
  • A substance does not contain heat, it contains
    internal energy
  • When heat is absorbed or given off by an object,
    its internal energy changes.
  • It may warm up increase translational KE.
  • But not always it may change phase
  • add heat to ice - melts to water

10
Internal Energy
  • A 3.0 x 10-3 kg copper penny drops a distance of
    50.0 m to the ground. If 65 percent of the
    initial potential energy goes into increasing the
    internal energy of the penny, determine the
    magnitude of the internal energy increase.
  • The amount of internal energy needed to raise the
    temperature of 0.25 kg of water by 0.20ºC is
    209.3 J. How fast must a 0.25 kg baseball travel
    in order for its kinetic energy to equal this
    internal energy?

11
Measurements of Heat
  • Heat is flow of energy
  • measured in energy units (Joules)
  • calorie (or kilocalorie 1000 cal)
  • 1 calorie amount of heat required to change
    temp of 1 gram of water by 1oC.
  • 1 kilocalorie amount of heat required to change
    temp of 1 kilogram of water by 1oC.
  • 1 calorie 4.186 joules.
  • Sometimes kilocalorie is called Calorie, with
    capital C
  • Energy rating of foods/fuel is determined by
    burning them and measuring energy released.
  • 1 L of 30ºC water is mixed with 1 L of 20ºC
    water. What is the final temperature of the
    mixture?
  • 25ºC the internal energy lost by the warmer
    water is gained by the cooler water
  • You heat a cup of water on the campfire, raising
    its temp by 5oC. How long would it take to heat
    two cups of water 5oC on this campfire?
  • Twice as long there are twice as many
    molecules, so each molecule would, in the same
    time, gain an average of half as much energy.

12
Specific Heat Capacity
  • Different objects have different abilities to
    retain heat.
  • Heated apple pie the crust cools off quicker
    than the inside filling.
  • Toast cools off much quicker than a bowl of soup.
  • Similarly, same amounts of different objects
    require different amounts of heat to be raised to
    the same temperature
  • Why? Because the applied energy gets apportioned
    into different amounts of internal
    vibration/rotation or potential (doesnt raise
    temp), and jiggling (does raise temp).
  • Water takes much longer to bring from room
    temperature to boiling, than it takes same amount
    of oil to reach same temperature
  • We say water has a higher specific heat
    capacity (or just specific heat) than oil.

13
Specific Heat Capacity
  • Specific heat capacity ? thermal inertia
  • Resistance of substance to change in its
    temperature
  • The common unit for specific heat (c) is the
    J/kgºC (joule per kilogram degree celsius)
  • The transfer of heat from an object depends upon
    the objects mass, the specific heat, and the
    difference in temperature between the object and
    its surroundings
  • Q heat (joules)
  • m mass (kg)
  • c specific heat (J/kgºC)
  • T temperature (ºC)

14
Specific Heat Capacity
  • Hypothermia can occur if the body temperature
    drops to 35.0ºC,although people have been known
    to survive much lower temperatures. On January
    19, 1985, 2 year old Michael Trode was found in
    the snow near his Milwaukee home with a body
    temperature of 16.0ºC. If Michaels mass was 10.0
    kg, how much heat did his body lose, assuming
    that his normal body temperature is 37.0ºC and
    the specific heat of the human body is 3470
    J/kgºC?
  • Gwyns bowl is filled with 0.175 kg of 60.0ºC
    soup (mostly water) that she stirs with a 20.0ºC
    silver spoon with a mass of 0.0400 kg. The spoon
    slips out of her hand and slides into the soup.
    What equilibrium temperature will be reached if
    the spoon is allowed to remain in the soup and no
    heat is lost to the outside air? (cspoon 240.
    J/kgºC, cwater 4187 J/kgºC) Assume that the
    temperature of the bowl does not change.

15
Specific Heat
  • Water has exceptionally high specific heat
  • A small amount of water can absorb a lot of heat
    while only changing temperature a little
  • 1 gram of water requires 1 calorie of energy to
    raise temp by 1oC (i.e. specific heat 1
    cal/(K.g) 4186 J/kgºC))
  • 1 gram of oil requires 0.5 calorie of energy to
    raise temp by 1oC (i.e. specific heat 0.5
    cal/(K.g) 2093 J/kgºC)
  • 1 gram of iron requires 0.125 calorie of energy
    to raise temp by 1oC (i.e. specific heat 0.125
    J/(K.g) 523.25 J/kgºC)
  • Water is a good cooling agent (in cars, engines)
  • Once heated, water stays warm for long time
    (hot-water bottles on cold nights)
  • Why will a watermelon stay cool for a longer time
    than sandwiches when both are removed from a
    cooler on a hot day?
  • Water has a high specific heat capacity, so takes
    a long time to heat up or cool down. The water in
    the watermelon resists changes in temp, so once
    cooled will stay cooler longer than sandwiches or
    other non-watery substances.

16
The Specific Heat of Water Climate
  • Water moderates the climate more energy needed
    to warm water than to warm land
  • islands/peninsulas dont have extreme temps like
    interior lands do
  • Europe is at about the same latitude as parts of
    northeastern Canada but is not so cold. Why?
  • The Gulf Stream carries warm water northeast from
    the Caribbean, remaining warm, even up to coast
    of Europe. Here it cools, releasing energy into
    the air goes into westerly winds to warm
    Europe.
  • If water didnt have such a high specific heat,
    Europe would be as cold as northeastern Canada!
  • Ocean doesnt vary its temperature much from
    summer to winter, because of high specific heat
  • In the winter, it warms the air (air does change
    temp more, small specific heat),
  • In the summer, it cools the air
  • Westerly winds keep San Francisco warmer in
    winter, and cooler in summer than Washington DC
    even though they are at the same latitude.
  • The air moves from San Francisco to DC across
    land. Land has a lower specific heat capacity
    than water.

17
Thermal Expansion
  • Matter expands when heated and contracts when
    cooled can understand in terms of increased
    (heated) or decreased (cooling) jiggling motion
    of molecules.
  • Telephone wires become longer and sag on hot day.
  • Opening a stiff metal lid on glass jar easier
    to do if hold under hot water for a while since
    metal expands more than the glass.
  • Golden Gate bridge in San Francisco contracts
    more than a meter in cold weather.
  • Generally liquids expand more than solids
  • glass thermometer filled with mercury liquid
    mercury expands more than the glass. If not, it
    wouldnt increase height with increasing
    temperature
  • Important to account for expansion in building
    and construction.
  • Filling material for tooth cavities has same rate
    of expansion as teeth.
  • Concrete roads or bridges are intersected by gaps
    (often with tar) so concrete can freely expand in
    summer, contract in winter.

18
Thermal Expansion
  • Railroad tracks
  • No gaps in tracks in picture here, so tracks
    buckled on a very hot day.
  • Generally, they have gaps that make a
    clickety-clack sound.
  • Now instead they are welded together to
    eliminate the sound and are laid down on
    hottest days to avoid buckling due to heat.
  • On cooler days, the tracks contract, but that
    just stretches the tracks, not distorting them
  • Different materials expand at different rates
  • Generally, something that expands more when
    heated, also contracts more when cooled.
  • Bimetallic strip (two strips of different
    metals) brass expands and contracts more than
    iron.

19
Thermal Expansion
  • A thermostat is an application of a bimetallic
    strip
  • The back and forth bending of the strip opens and
    closes an electric circuit
  • When a room becomes too coldthe coil bends
    toward the brass side, closing the circuit,
    turning on the heat
  • When a room becomes too warm, the coil bends
    toward the iron side, opening the thermostat,
    turning off the heat
  • The amount of expansion of a substance depends on
    its change in temperature
  • Liquids expand appreciably with increases in
    temperature

20
Thermal Expansion
  • When a metal ball is heated in a Bunsen flame,
    which undergoes a change volume, mass, or
    density?
  • Volume and density. Mass remains the same.
  • (2) Why is it advisable not to completely fill
    the gas tank in a car that may sit in sunlight in
    a hot day after being filled?
  • As it warms, it expands, overflowing and causing
    a hazard.
  • (3) Place a dented ping-pong ball in boiling
    water, the dent is removed. Why?
  • Because the ball expands as its temperature
    rises, so it pops back out into a sphere.

21
Thermal Expansion
  • Linear Expansion
  • Ernesto is knitting his wife a sweater in his
    18C air-conditioned living room with 0.30 m long
    aluminum knitting needles, when he decides to
    knit outside in the 27C air. How much will the
    knitting needles expand when Ernesto takes them
    outside? ( 24 x 10-6 C-1)
  • Area Expansion
  • Volume Expansion

22
Expansion of Water
  • Almost all liquids expand when they are heated.
  • Ice-cold water contracts when the temperature is
    increased
  • Water contracts from 0 4 degrees Celsius
  • At 4 degrees, it begins to expand
  • At what temp does water have its greatest
    density?
  • At 4oC, smallest volume

23
Expansion of Water
  • Will a sample of 4ºC water expand, contract, or
    remain unchanged in volume when heated?
  • Expand
  • Will a sample of 4ºC water expand, contract, or
    remain unchanged when it is cooled?
  • Expand
  • Why would water, instead of mercury or alcohol,
    be a poor liquid for a thermometer when
    near-freezing temperatures are to be measured?
  • The column height would be ambiguous for 0 8ºC.
    You couldnt distinguish between temperatures
    below and above 4ºC.

24
Expansion of Water
  • Ice has crystalline structure open-structured
    crystals due to angular shape of water molecules.
  • In ice-cold water, most molecules are in liquid
    phase (water) but also a few ice-crystals here
    and there.
  • Water molecules in this open structure occupy a
    greater volume than they do in the liquid state ?
    ice is less dense than water (it floats)

25
Expansion of Water
  • Understanding the dip in the volume curve
  • Two competing effects as you add heat to ice-cold
    water
  • (i) (spaced-out) ice-crystals collapsing (ii)
    faster molecular motion

26
Why can fish exist in ponds in the winter?
  • The dip in the curve!

Consider if there was no dip so water would
continue getting denser through to freezing point
(like most liquids). Then coldest water would be
at bottom of pond, since it is densest. Organisms
would be killed in winter ?
Fortunately, the densest water is at 4oC, so this
is the temp at bottom of a pond in winter.
Instead, ice (water at freezing point, 0oC) is
less dense so floats to the top, leading to happy
fish at 4oC ?
Ponds freeze from surface downward. As it cools,
water sinks until all pond is 4oC. After that,
lower temperatures can be reached and this floats
on top and freezes right at top of water is ice
at 0oC.
This, together with waters high specific heat,
means that very deep bodies of water are not
ice-covered even in the coldest winter need to
get whole body to 4oC first, not just the upper
part.
Write a Comment
User Comments (0)
About PowerShow.com
