Aortic Dissection

1
Aortic Dissection

• Jason S. Finkelstein, M.D.
• Cardiology Fellow
• Tulane University
• 8/11/03

2
Overview

• Incidence of aortic dissection is at least 2000
  new cases per year
• Peak incidence is in the sixth to seventh decade
• Men are affected twice as commonly as women
• Mortality in the first 48 hours is 1 per hour
• Early diagnosis is essential

3
Pathophysiology

• The chief predisposing factor is degeneration of
  collagen and elastin in the aortic intima media
• Blood passes through the tear into the aortic
  media, separating the media from the intima and
  creating a false lumen
• Dissection can occur both distal and proximal to
  the tear

4
Classification

• Debakey system
• Type I
• Originates in the ascending aorta, propagates to
  the aortic arch and beyond it distally
• Type II
• Confined to the ascending aorta
• Type III
• Confined to the descending aorta, and extends
  distally, or rarely retrograde into the aortic
  arch

5
Classification

• The Stanford system
• Type A
• All dissections involving the ascending aorta
• Type B
• All other dissections regardless of the site of
  the primary intimal tear
• Ascending aortic dissections are twice as common
  as descending

6
(No Transcript)
7
Predisposing factors

• Age, 60-80 yrs old
• Long standing history of hypertension
• 80 of cases have co-existing HTN
• Takayasus arteritis
• Giant cell arteritis
• Syphilis
• Collagen disorders
• Marfan syndrome (6-9 of aortic dissections)
• Ehlers-Danlos syndrome

8
Other Risk Factors

• Congenital Cardiac Anomalies
• Bicuspid aortic valve (7-14 of cases)
• Coarctation of the aorta
• Cocaine
• Abrupt HTN, due to catecholamine release
• Trauma
• Pregnancy (50 of dissections in women lt40 yrs)
• Iatrogenic (cardiac cath, IABP, cardiac surgery,
  s/p valve replacement)

9
Clinical Symptoms

• Severe, sharp, tearing posterior chest pain or
  back pain (occurs in 74-90 of pts)
• Pain may be associated with syncope, CVA, MI, or
  CHF
• Painless dissection relatively uncommon
• Chest pain is more common with Type A dissections
• Back or abdominal pain is more common with Type B
  dissections

10
Physical Exam

• Pulse deficit
• Weak or absent carotid, brachial, or femoral
  pulses
• these patients have a higher rate of mortality
• Acute Aortic Insufficiency
• Diastolic decrescendo murmur
• Best heard along the right sternal border

11
Clinical signs

• Acute MI
• RCA most commonly involved
• Cardiac tamponade
• Pleural effusions
• Hypertension or hypotension
• Hemothorax
• Variation in BP between the arms (gt30mmHg)
• Neurologic deficits
• Stroke or decreased consciousness

12
Clinical Signs

• Involvement of the descending aorta
• Splanchnic ischemia
• Renal insufficiency
• Lower extremity ischemia
• Spinal cord ischemia

13
Diagnosis

• Generally suspected from the history and PE
• In a recent study in 2000, 96 of acute
  dissection patients could be identified based
  upon a combination of three clinical features
• Immediate onset of chest pain
• Mediastinal widening on CXR
• A variation in pulse and/or blood pressure (gt20
  mmHg difference between R L arm
• Incidence gt83 when any combination of all three
  variables occurred

14
Differential Diagnosis

• Acute Coronary Syndrome
• Pericarditis
• Pulmonary embolus
• Pleuritis
• Cholecystitis
• Perforating ulcer

15
Diagnostic Tests

• EKG
• Absence of EKG changes usually helps distinguish
  dissection from angina
• Usually non-specific ST-T wave changes seen
• CXR
• Cardiac Enzymes

16
Chest X-Ray

• May show widening of the aorta with ascending
  aorta dissections
• Present in 63 of patients with Type A
  dissections

17
Diagnostic Imaging

• Not performed until the patient is medically
  stable
• Has been a dramatic shift from invasive to
  non-invasive diagnostic strategy
• Spiral CT scan
• TEE
• MRI
• Angiography

18
Imaging

• Can identify aortic dissection and other features
  such as
• Involvement of the ascending aorta
• Extent of dissection
• Thrombus in the false lumen
• Branch vessel or coronary artery involvement
• Aortic insufficiency
• Pericardial effusion with or without tamponade
• Sites of entry and re-entry

19
(No Transcript)
20
Angiography

• First definitive test for aortic dissection
• Traditionally considered the gold standard
• Involves injection of contrast media into the
  aorta
• Identifies the site of the dissection
• Major branches of the aorta
• Communication site between true false lumen
• Can detect thrombus in the false lumen
• Disadvantages
• Not very practical in critically ill patients
• Nephrotoxic contrast
• Risks of an invasive procedure

21
(No Transcript)
22
Spiral CT

• Sensitivity 83
• Specificity 90 - 100
• Two distinct lumens with a visible intimal flap
  can be identified
• Advantages
• Noninvasive
• Readily available at most hospitals on an
  emergency basis
• Can differentiate dissection from other causes of
  aortic widening (tumor, periaortic hematoma, fat)
• Disadvantages
• Sensitivity lower than TEE and MRI
• Intimal flap is seen lt 75 of cases
• Nephrotoxic contrast is required
• Cannot reliably detect AI, or delineate branch
  vessels

23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
TTE

• First used to diagnose aortic dissections in the
  70s
• Sensitivity 59-85, specificity 63-96
• Image quality limited by obesity, lung disease,
  and chest wall deformities

27
(No Transcript)
28
TEE

• Sensitivity 98 Specificity 95
• Advantages
• Close proximity of the esophagus to the thoracic
  aorta
• Portable procedure
• Yields diagnosis in lt 5 minutes
• Useful in patients too unstable for MRI
• True and false lumens can be identified
• Thrombosis, pericardial effusion, AI, and
  proximal coronary arteries can be readily
  visualized

29
TEE

• Lower specificity attributed to reverberations
  atherosclerotic vessels or calcified aortic
  disease producing echo images that resemble an
  aortic flap
• Disadvantages
• Contraindicated in patients with esophageal
  varices, tumors, or strictures
• Potential complications bradycardia,
  hypotension, bronchospasm

30
(No Transcript)
31
(No Transcript)
32
MRI

• Most accurate noninvasive for evaluating the
  thoracic aorta
• Sensitivity 98
• Specificity 98
• Advantages
• Safe
• Can visualize the whole extent of the aorta in
  multiple planes
• Ability to assess branch vessels, AI, and
  pericardial effusion
• No contrast or radiation
• Disadvantages
• Not readily available on an emergency basis
• Time consuming
• Limited applicability in pts with pacemakers or
  metallic clips

33
(No Transcript)
34
Conclusions

• Conventional TTE is of limited diagnostic value
  in assessment of the thoracic aorta
• Both TEE and MRI have excellent sensitivity,
  however MRI is more specific
• MRI is the study of choice for stable patients
• TEE is the study of choice for unstable patients

35
Treatment

• Acute dissections involving the ascending aorta
  are considered surgical emergencies
• Dissections confined to the descending aorta are
  treated medically
• Unless patient demonstrates continued hemorrhage
  into the pleural or retroperitoneal space

36
Surgical Options

• Excision of the intimal tear
• Obliteration of entry into the false lumen
  proximally
• Reconstitution of the aorta with interposition of
  a synthetic vascular graft

37
Type A Dissections

• Operative mortality varies from 7-35
• 27 post-op mortality
• Patients who died had a higher rate of
  in-hospital complications such as strokes, renal
  failure, limb ischemia, mesenteric ischemia

38
Poor prognostic factors

• Hypotension or shock
• Renal failure
• Agegt 70 yrs
• Pulse deficit
• Prior MI
• Underlying pulmonary disease
• Preoperative neurologic impairment
• Renal and/or visceral ischemia
• Abnormal EKG, particularly ST elevation

39
Medical therapy

• Reduce systolic BP to 100 to 120 mmHg or the
  lowest level that is tolerated
• IV Beta blockers
• Propanolol (1-10 mg load, 3mg/hr)
• Labetalol (20 mg bolus, 0.5 to 2 mg/min)
• If SBP remains gt100mmHg, nitroprusside should be
  added
• Do not use without beta blockade
• Avoid hydralazine
• Surgical intervention for Type B dissections
  reserved for patients with a complicated course

40
Long Term Outcome

• Type A
• Survival at 5 yrs 68
• Survival at 10 yrs 52
• Type B
• 5 yrs 60 - 80
• 10 yrs 40 80
• Spontaneous healing of dissection is uncommon

41
Long-Term Management

• Medical therapy
• Oral Beta-blockers (reduces aortic wall stress)
• Keep BP lt 135/80 mmHg (combination therapy)
• Avoidance of strenuous physical activity
• Serial imaging
• Thoracic MR scan prior to discharge
• f/u scans at 3, 6, and 12 months
• Subsequent screening studies done every 1-2 yrs
  if no evidence of progression
